- Page 1 7X52 GPS SOLAR 基本操作マニュアル Basic Manual...
-
Page 2: Table Of Contents
READ FIRST CONTENTS １． READ FIRST Features… ………………………………………………………………………………………………………………………… 32 The…following…functions…are…included… …………………………………………………………………………………… 33 ２． BEFORE USE Names…of…the…parts…………………………………………………………………………………………………………… 34 Indicator…hand…display…and…reception…result…display…………………………………………………………………… 35 Check…the…charging…status…………………………………………………………………………………………………… 36 About…charging… ………………………………………………………………………………………………………………… 37 Place…where…GPS…signals…can…be…easily…received/Place…where…GPS…signals…cannot…be…received… …… 38 ３． BASIC OPERATION Time…Zone…Adjustment…(When…the…region…or…time…zone…where…the…watch…is…used…is…changed…)… 39〜40 Set…Daylight…Saving…Time…(DST)… ………………………………………………………………………………………… 41 In-flight…mode…( )…(When…boarding)… … …………………………………………………………………………………… 42 Manual…time…zone…setting…(To…set…the…watch…to…the…local…time…of…the…destination…in…an…airplane,…etc.)…... -
Page 3: Features
READ FIRST Features …This is a GPS* solar watch. This watch has the following features. ＊ GPS…is…an…abbreviation…for…Global…Positioning…System.… This watch operates by solar This watch can be set to the This watch automatically precise local time by just one adjusts the time in accordance charging. - Page 4 READ FIRST The following functions are included When the region or time zone where the watch To set only the time is used is changed Adjust the time zone. The watch displays the precise time of the time The watch displays the precise local time. zone that is set by operation of “manual time adjustment.”...
-
Page 5: ２． Before Use
BEFORE USE Names of the parts Main-Dial Button B Hour Minute Second Date hand hand hand Button A Crown Indicator hand （Screw lock type） ※ Keep…the…crown…locked…while… you…are…wearing…the…watch. Sub-dial Button C Continued on the following page... - Page 6 BEFORE USE Indicator hand display and reception result display Display of receiving process 4+…(time…zone… Receiving…leap… Receiving… 1…(time… process adjustment) adjustment) second…data Display of charging status Display Level…position… Hand… F…(full) E…(low) position (middle) …Check…the…reception…result…→…P.47 …Automatic…time…adjustment…→…P.46 …Manual…time…adjustment…→…P.44〜45 …Receive…leap…second…data…→…P.48 Display …Time…zone…adjustment…→…P.39〜40 …Check…the…charging…status.…→…P.36 …How…to…charge…the…watch…→…P.37 Display of Display of in-flight mode( reception result...
- Page 7 BEFORE USE Check the charging status The indicator hand position shows whether this watch is able or unable to receive GPS signals. In addition, for the low charging state, the movement of the second hand shows the energy depletion state in further detail. ＊GPS…radio…signal…reception…requires…a…lot…of…energy.……Keep…in…mind…to…regularly…charge…the…watch…by…expose…to…light.
- Page 8 BEFORE USE About charging …How to charge the watch Expose the dial to light to charge the watch. Under the following situations, the energy of the watch is likely to To ensure optimal be depleted, resulting in stoppage of the watch. performance ・...
- Page 9 BEFORE USE Place where GPS signals can be easily received/Place where GPS signals cannot be received There are places where GPS signals can be easily received and places where GPS signals cannot be received. Easy to receive Difficult to receive Cannot receive ・…...
- Page 10 BASIC OPERATION Time Zone Adjustment （ When the region or time zone where the watch is used is changed） …Time zone adjustment The time zone where you are is localized to adjust the watch to the precise current time by receiving GPS signals. →…How…to…adjust…the…time…zone… P.40 ※…...
-
Page 11: Check
BASIC OPERATION …How to adjust the time zone Continue to press Button B (6 sec), and then release it when the second hand moves to the 30-sec position. ※ While… the… indicator… hand… points… to… “ E” … Move…to…the… ※ Although…the…second…hand…moves…to… or…... - Page 12 BASIC OPERATION Set Daylight Saving Time (DST) …Daylight Saving Time (DST) Depending on the area, Daylight Saving Time (DST) is individually set. Daylight Saving Time means summer time, which is a system to lengthen daylight time by advancing 1 hour when daylight time is long in summer. Daylight saving time has been adopted in about 80 countries, mainly in Europe and North America.
- Page 13 BASIC OPERATION In-flight mode ( ) (When boarding) …In-flight mode （ ） Set to the in-flight mode（ ）where the reception may influence ＜ In-flight…mode（ ）＞ The…indicator…hand…points… operation of other electronics devices in an airplane, etc. to… In the in-flight mode（ ）the GPS signal reception (time zone adjustment, manual time adjustment, and automatic time ※...
- Page 14 BASIC OPERATION Manual time zone setting (To set the watch to the local time of the destination in an airplane, etc.) …Manual time zone setting In places where the time zone cannot be adjusted, the time zone can be set manually. ※…Refer…to…...
-
Page 15: Place
BASIC OPERATION Manual time adjustment (To set only the time) …Manual time adjustment The watch can be set to the precise current time of the currently set time zone. (The time zone is not changed.) →…How…to…manually…adjust…the…time P.45 → Check…the…time…zone…setting P.40 ※ In…the…manual…time…adjustment,…the…precise…time…of…the…currently…set…time…zone…is…displayed. When…the…region…or…time…zone…where…the…watch…is…used…is…changed,…adjust…the…time…zone. -
Page 16: Time
BASIC OPERATION …How to manually adjust the time Continue to press Button B (3 sec), When the second hand Direct the watch face and then release it when the second points to “Y” or “N,” upward and wait hand moves to the 0-sec position. reception is completed. - Page 17 BASIC OPERATION Automatic time adjustment This watch can be set to the precise current time by automatically receiving GPS signals by exposure to bright light outdoors under an open sky to adjust the time. In addition, when the watch is concealed under a sleeve and the dial is not exposed to sufficient light even if outdoors under an open sky, the watch stores the time of the previous successful manual time adjustment (or time zone adjustment), and automatically starts time...
- Page 18 BASIC OPERATION …Reception result display (Check that reception was successful) The type of reception and reception result (success or failure) of the last GPS signal reception is displayed for 5 seconds. When the reception Press Button B once result is Y Check that reception was successful (within 5 sec) and then release it ・...
-
Page 19: Set
DETAILED INFORMATION Leap second (Automatic leap second reception function) …Leap second …Reception of leap second data ＜Ready for leap second data reception＞ The leap second is The indicator hand displays as shown at to compensate for the right when GPS signals are received deviations from the (time zone adjustment or time adjustment) universal time (UT) - Page 20 IN CASE OF AN UNUSUAL MOVEMENT OF THE SECOND HAND Energy depletion forewarning function (Second hand movement and watch state) Movement of the second hand shows the state of the watch (working functions). …2-sec interval movement/5-sec interval movement are brought about When the energy stored in the watch runs low, the energy depletion forewarning function will work.
-
Page 21: Automatic
IN CASE OF AN UNUSUAL MOVEMENT OF THE SECOND HAND Power save function (The second hand stops at the 15-sec position/45-sec position) When the watch is not exposed to light for a long time, the power save function will work. Power…Save…1 Power…Save…2 The…second…hand…stops…... -
Page 22: When
TROUBLESHOOTING When the watch is unable to receive GPS signals …Points to be checked When the watch does not start receiving or is unable to receive GPS signals even with operation of GPS signal reception, the following can be considered. ●... -
Page 23: Manual
TROUBLESHOOTING …How to manually set the time Unlock the crown Pull out the crown to the second click Unlock…the…crown The…second…hand…moves…to…the…13-sec… position…and…stops. 0 1 2 Unscrew Pull out to the 2nd click Continue to press Button A (3 sec) and then release it Press Button B or Button C to set the time when the hand moves to the 0-sec position The…second…hand…moves…to…... -
Page 24: When
TROUBLESHOOTING …How to manually set the date When the date is not automatically changed under a condition in which the watch is unable to receive GPS signals (when changing from months with 30 days or less to months with 31 days), set the date manually. ・…... - Page 25 TROUBLESHOOTING When the time/date or indicator hand position is misaligned …Points to be checked ● Reception was successful (the reception result is displayed as “Y” ), but time has gained or lost. ・Check the time zone setting. → P.40 … I f…the…currently…set…time…zone…does…not…correspond…to…the…region…where… you…are,…set…the…time…zone…by…either…of…the…following…operations.
- Page 26 TROUBLESHOOTING …Preliminary position of this watch The preliminary position of the date is “1” (1st). The preliminary position of the indicator hand is between “E” (low) and . The preliminary position of the hour/minute hands is “0:00 am.” …Adjust the preliminary position of the date, indicator hand, and hour/minute hands Continue to press Button A Continue to press Button B and C simultaneously Press Button B or C to...
- Page 27 TROUBLESHOOTING Continue to press Button A Press Button B or C W h e n o p e r a t i o n i s (2 seconds) and release it to adjust the indicator Press Button B once c o m p l e t e d , p r e s s when the second hand hand as shown in the and then release it...
- Page 28 TROUBLESHOOTING In case of an abnormal movement (resetting the built-in IC) …Reset the system ( ② 〜 ④ ) In the case that the watch moves abnormally or that the watch does not move at 1-sec intervals even after Continue to press Button When the hands stop fully charging the battery, Pull out the crown...
- Page 29 TROUBLESHOOTING …Set the date to “1” (1st) ( ⑤ , ⑥ ) ※ … I f … t h e … d a t e … i s … s t o p p e d… Continue to press Button B and C simultaneously Press Button B or C to set the continuously…...
-
Page 30: Specifications
SPECIFICATIONS SPECIFICATIONS 1.Basic function ･･････････････････････ Main-dial ; three hands (hour/minute/second hands), date display, indicator hand, sub-dial ; two hands (hour/minute hands) 2.Frequency of crystal oscillato ････････32,768 Hz (Hz = Hertz ... Cycles per second) 3.Loss/gain (monthly rate) ･･････････ Loss / gain ± 15 seconds on a monthly rate (Except the case when the watch is used without an automatic time setting by receiving GP S signal and when it is worn on the wrist within a normal temperature range between 5℃... - Page 31 CSB7X52-1208 Printed in Japan...
