- Page 1 ASWipLL 900 MHz Wireless IP-Based Local Loop System Quick Installation & Configuration Guide Leading the World in Wireless DSL...
- Page 2 Airspan Networks Inc. rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of Airspan Networks Inc.
- Page 3 - Consult the dealer or an experienced radio/TV technician for help. The ASWipLL system must be installed by professional and experienced technicians who are familiar with radio frequency (RF) issues such as gains and losses, as well as local building and safety codes. Failure to do so will void the product warranty and may expose the end user to excessive RF hazard.
-
Page 4: Table Of Contents
Q u i c k I n s t a l l a t i o n & C o n f i g u r a t i o n G u i d e AS W i p L L 9 0 0 M H z Contents Preface ................................v Basic Design of ASWipLL Radios ........................6 1.1. BSR..................................6 1.2. SPR..................................6 1.3. IDR ..................................7 Site Preparation and Planning ..........................8... -
Page 5: Preface
(For establishing a link in a routing mode, refer to the ASWipLL Commissioning Manual.) Scope This quick guide provides a summary of how to setup an ASWipLL link in transparent bridge mode. The flowchart below lists the main steps in setting up this link:... -
Page 6: Basic Design Of Aswipll Radios
Q u i c k I n s t a l l a t i o n & C o n f i g u r a t i o n G u i d e AS W i p L L 9 0 0 M H z Basic Design of ASWipLL Radios This chapter describes the basic design and physical dimensions of the ASWipLL BSR, SPR, and IDR devices. 1.1. BSR The BSR, installed at the Base Station, is an encased outdoor radio module providing a 9 pin D-type port for RS-232 serial interface and a 15 pin D-type port for data, synchronization, and power interfaces. -
Page 7: Idr
For IDR antenna alignment, the IDR provides LEDs that indicate received signal strength (RSS). These LEDs are described in the table below: RSS level Color Status (ASWipLL Release 4.2B and later) RSSI LEDs Green All LEDs on RSSI ≥ -60 dBm (LO, MED, HI) Two LEDs (LO;... -
Page 8: Site Preparation And Planning
Maximum received signal strength (RSS) at CPE by antenna alignment: For the IDR, RSS can be measured by the IDR's built-in RSS LEDs; for the SPR, RSS can be measured by Airspan’s WipConfig program or by connecting Airspan's RSS LED Plug Adapter. -
Page 9: External Antenna Considerations
3.2. Antenna Polarization The performance of ASWipLL 900 may vary dramatically depending on the polarization of antennas, i.e. vertical or horizontal. Therefore, it is recommended that the operator, during installation, compare the performance between horizontal and vertical polarization of external antennas, and use the polarization providing the best performance. -
Page 10: Transmit Power And Cable Loss
EIRP (i.e. of less than or equal to 36 dBm). 2) ASWipLL 900 MHz is capable of transmitting at up to 30 dBm. However, in accordance with FCC regulations, transmit power is limited to 23 dBm in the 4 Mbps mode, and 18 dBm in the 3 Mbps mode. -
Page 11: Mounting The Outdoor Radio Units
5. Adjust the BSR/SPR horizontal position by rotating the BSR/SPR about the pole, and then tighten the U- bolt. BSR/SPR positioning is obtained in two planes by adjustment of the mounting bracket assembly as shown in the figure below. 13070311-02 Airspan Networks Inc. -
Page 12: Wall Mounting
Note: Airspan does not provide screws for attaching the mounting bracket to the wall. The screw size depends on the structure of the building to which the bracket is to be attached. When selecting screw sizes, consideration must be given to the weight of the BSR/SPR and load that may be induced in windy conditions. -
Page 13: Cabling
1. Connect the 15-pin D-type male connector to the BSR’s 15-pin port. 2. Connect the 15-pin D-type male connector, at the other end of the CAT 5 cable, to one of the BSDU’s 15-pin D-type ports labeled BSR, located on the BSDU’s rear panel. 13070311-02 Airspan Networks Inc. -
Page 14: Spr-To-Sda Cabling
1. Connect the 15-pin D-type male connector, at one end of the CAT 5 cable, to the SPR’s 15-pin port. 2. Connect the 15-pin D-type male connector, at the other end of the CAT 5 cable, to the SDA’s 15-pin D-type port. Airspan Networks Inc. 13070311-02... -
Page 15: Bsr Serial Cabling
1. Connect the 9-pin D-type male connector, at one end of the serial cable, to the BSR’s serial port, labeled Serial. 2. Connect the 9-pin D-type female connector, at the other end of the serial cable, to the PC’s serial port. 13070311-02 Airspan Networks Inc. -
Page 16: Spr Serial Cabling
2. Connect the 15-pin D-type male connector, at the other end of the Y-cable, to the SDA. 3. Connect the 9-pin D-type female (RS232) connector, at the other end of the Y-cable, to the PC’s serial port. Airspan Networks Inc. 13070311-02... -
Page 17: Idr Serial Cabling
1. Connect the 6-pin RJ-11 connector, at one end of the crossover cable, to the IDR’s RJ-11 port labeled Serial. 2. Connect the 9-pin D-type female connector, at the other end of the crossover cable, to the PC’s serial port. 13070311-02 Airspan Networks Inc. -
Page 18: Software Installation
Q u i c k I n s t a l l a t i o n & C o n f i g u r a t i o n G u i d e AS W i p L L 9 0 0 M H z Software Installation ASWipLL provides two main configuration and management tools: WipManage and WipConfig. Before installing these tools, ensure that the following system requirements are fulfilled: Hardware requirements:... -
Page 19: Installing Wipmanage
6. Click Next to install WipManage in the default directory C:\WipMng. 7. Click Next to add WipManage to the “Airspan” Program Manager Group. 8. If Microsoft Access is not installed on your PC, select the Add MS-Access ODBC Drivers check box. -
Page 20: Initial Configuration
1) For establishing a link in bridge mode, ensure IP addressing scheme enables IP connectivity between PC and devices. 2) For establishing a link in router mode, refer to the ASWipLL Commissioning Manual. 8.1. Default Settings Airspan’s factory default settings for the ASWipLL devices are listed in the following table:... - Page 21 Air MAC Address: enter the BSR’s Air MAC address (0x0000 through 0xFFFF), e.g. 0x1200 Notes: 1) For the Air MAC address, Airspan recommends using only the most significant bytes (MSB), e.g. the two left-most bytes, and not the least significant bytes (LSB), e.g. the right-most bytes. For example, a typical Air MAC address would be “AB00”, where the zeros represent the LSB.
-
Page 22: Spr/Idr Initialization
Reset button to reset the SPR/IDR. A Warning message box appears. 10. Click Yes to confirm resetting the SPR/IDR. The figure below displays the SPR/IDR configured in the bridge mode. “Bridge” mode selected Airspan Networks Inc. 13070311-02... -
Page 23: Analyzing The Rf Spectrum
Notes: 1) Airspan’s Spectrum Analyzer feature, which plugs into WipConfig, is license-dependant. 2) Ensure all other ASWipLL devices are powered off, except the device whose spectrum you are analyzing. 3) Mount the ASWipLL device prior to commencing the spectrum analysis. -
Page 24: Starting The Spectrum Analyzer
This is displayed in the TxRxOffset field. 9.5. Quitting the Spectrum Analyzer The main issue after quitting the Spectrum Analyzer is to reset the ASWipLL device To quit the Spectrum Analyzer: 1. From the File menu, choose Exit to close the Spectrum Analyzer. -
Page 25: Configuring Pc's Ip Address
Configuring PC’s IP Address To establish IP network connectivity between your PC running the NMS (WipConfig or WipManage) and the ASWipLL devices, you need to configure your PC's TCP/IP address settings in accordance with your ASWipLL network's IP addressing scheme: Define PC’s (i.e. -
Page 26: Establishing Link Using Wipmanage
2. In the BSs Map view (in the right pane), right-click an empty area, and then from the shortcut menu, choose Add BS; The BS Add dialog box appears. 3. In the BS Name field, enter a name for the BS, e.g. “Times Square”, and then click OK. Airspan Networks Inc. 13070311-02... -
Page 27: Adding A Bsr
After you have added a BSR, you can add an SPR/IDR. The SPR/IDR (10.0.0.20) must be added to the SPR index #2 that you assigned the SPR/IDR when initializing the SPR/IDR using WipConfig (see Section 8.3, "SPR/IDR Initialization"). 13070311-02 Airspan Networks Inc. -
Page 28: Testing Bsr-Spr/Idr Network Link
1) Static routing is not used in bridging; therefore, you can ignore routing procedures (i.e. Route button). 2) For establishing a link in router mode, refer to the ASWipLL Commissioning Manual. 3. Click OK; The SPR index #2 icon appears green, as shown below, indicating that a viable air and network link exists with the SPR/IDR. -
Page 29: Receiving Traps
As an SNMP-based application, the WipManage management station can receive traps generated internally by WipManage and generated by ASWipLL devices. To receive these traps you need to perform the following: Define management stations (by IP address) for receiving device-generated traps Enable WipManage to receive (and display) traps 12.1. -
Page 30: Enabling Trap Display In Wipmanage
DB appear with a number sign (#) alongside the index number, e.g. "#2"; traps from a previous WipManage session and not saved in the DB appear with "Old" alongside the index number, e.g. "Old 2". Airspan Networks Inc. 13070311-02... -
Page 31: Building Frequency Table Based On Spectrum Analyzer Results
8, 4, and 2 level FSK (4 Mbps/3 Mbps, 2 Mbps, and 1.33 Mbps/1 Mbps), respectively. ASWipLL can operate in 2, 4, and 8 level FSK with signal strengths greater than -90, -83, and -75 dBm, respectively. -
Page 32: Copying Bsr Frequency Table To Sprs/Idrs
The Multi SPRs Frequency Tables dialog box appears. 2. Click Refresh to ensure that recently added BSR frequency tables have been updated. 3. Select all the SPRs/IDRs (for which you want to communicate with the BSR) by clicking the Select All. Airspan Networks Inc. 13070311-02... -
Page 33: Selecting The Frequency Table For Communication
BSR using WipConfig (see Section 8.2, "BSR Initialization"). 3. Click Apply; A message appears informing you change will take affect only after resetting the BSR. 4. Click OK, and then click Close to close the Hopping Configuration dialog box. 5. Reset the BSR. 13070311-02 Airspan Networks Inc. -
Page 34: Testing Link Quality
#2001). During the test, record the RSS and BER levels for the BSR and SPR/IDR. This information is useful to Airspan’s technical support team for future diagnosis. Using the Iperf application (free download at http://dast.nlanr.net/Projects/Iperf/). A simple batch file can be made for the client side (behind the CPE) and for the BS side (behind the BSR) to ease the throughput measurement procedure. -
Page 35: Troubleshooting
• Check PC’s routing table for correct routes from BSR to SPR/IDR (MS-DOS command: route print): • For ASWipLL in the transparent bridge mode, check PC’s routing table for correct routes from BSR to SPR/IDR (MS- DOS command: tracert <SPR’s/IDR's IP address>. - Page 36 Cambridge House 777 Yamato Road Oxford Road Suite 105 Uxbridge Boca Raton, FL 33431 Middlesex UB8 1UN Tel: (+1) 561 893 8670 United Kingdom Fax: (+1) 561 893 8671 Tel: (44) 895 467100 Airspan Networks Web site: http//www.Airspan.com Cat. No. 73000006...
