This INSTALLATION AND OPERATION
MANUAL explains the proper use of your new
Sharp Air Conditioner. Read these instructions
carefully before installing or operating your air
conditioner. The INSTALLATION AND OP-
ERATION MANUAL should be kept in a safe
place for handy reference.
As an ENERGY STAR Partner, Sharp Electronics has determined that this product (AF-S100DX, AF-
S120DX) meets the ENERGY STAR guidelines for energy efficient air conditioners. To meet these
guidelines, air conditioners must be at least 10% more efficient than the minimum Federal standard.
AF-S100DX
AF-S120DX
AF-R100DX
AF-R120DX
AF-R140DX
ROOM AIR CONDITIONER
INSTALLATION AND OPERATION
MANUAL
CONTENTS
FOR YOUR PROTECTION ....................
• CHECK WINDOW AREA ........................ 4
• LOCATlON .............................................. 4
• ITEMS PACKED WITH THlS UNIT ......... 5
• SUGGESTED TOOLS ............................ 5
• INSTALLATION ....................................... 5
• CAUTION FOR USE ............................ 8
• GROUNDING INSTRUCTIONS ........... 8
• NOTES ON OPERATION .................... 9
• ENERGY EFFICIENCY TIPS ............... 9
• PARTS NAMES ................................... 10
• COOLING OPERATION ...................... 11
• TO CHANGE TEMPERATURE SETTING .......... 11
• ENERGY SAVER ................................. 13
• TO CHANGE AIR FLOW DIRECTION ....... 13
• EXHAUST ............................................ 13
• ON TIMER OPERATION ..................... 14
• OFF TIMER OPERATION .................... 15
• USING THE REMOTE CONTROL ....... 16
CLEANING AND MAINTENANCE ........ 18
BEFORE CALLING FOR SERVlCE ...... 19
PAGE
2
3
Advertisement
Table of Contents
Related Manuals for Sharp AF-100DX
Summary of Contents for Sharp AF-100DX
-
Page 1: Table Of Contents
ERATION MANUAL should be kept in a safe place for handy reference. As an ENERGY STAR Partner, Sharp Electronics has determined that this product (AF-S100DX, AF- S120DX) meets the ENERGY STAR guidelines for energy efficient air conditioners. To meet these guidelines, air conditioners must be at least 10% more efficient than the minimum Federal standard. -
Page 2: For Your Protection
Address City State Telephone TO PHONE: Dial 1-800-BE-SHARP (237-4277) for: SERVICE (for your nearest Sharp Authorized Servicer) PARTS (for your Authorized Parts Distributor) ACCESSORIES ADDITIONAL CUSTOMER INFORMATION TO WRITE: For service problems, warranty information, missing items and other assistance: Sharp Electronics Corporation... -
Page 3: Consumer Limited Warranty
Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. -
Page 4: Installation Instructions
For safe installation, repairs, replacement and secure positioning, make sure foundation is solid and level. The room air conditioner must be installed in an area within reach of a properly rated grounded outlet. Use of extension cords of any kind is not recommended. -
Page 5: Items Packed With Thls Unit
These models can also be installed through the wall with the optional through the wall mounting kit, model AZ-80WK. To order this kit either contact your dealer or call 1-800-BE-SHARP. The wall opening dimensions for through the wall installation are: 25"... - Page 6 1 cm (3/8”) to the back. If the cabinet is not properly inclined, the water collected in the bottom tray during operation will not drain properly and may flow into the room where the air conditioner is installed. Front panel Front panel...
- Page 7 Insert the closure assemblies on both sides into the rails of the jamb. Closure assembly (Left) Sill Stool Secure the cabinet to the window stool with 3 screws (L=1", 25.4 mm), working from the inside of the cabinet. Secure the top angle and the closure assemblies to the window sash with 3 screws (L=1", 25.4 mm).
-
Page 8: Precautions
CAUTION FOR USE IMPORTANT: Points to keep in mind when using your air conditioner. • Install the air conditioner by following the installation instructions given in the previous section of this manua • Make sure the unit is the correct capacity for the area you want to cool. -
Page 9: Notes On Operation
• If a power failure occurs during use, allow 3 minutes before restarting the unit. After power is reinstated, restart the air conditioner. If the power was off for less than three minutes, be sure to wait at least three minutes before restarting the unit. If you restart the air conditioner within three minutes, a protective device in the unit may cause the compressor to shut off. -
Page 10: How To Operate
HOW TO OPERATE PARTS NAMES UNIT Front panel Air inlet (Indoor side) Louvers " Air outlet (Indoor side) Exhaust lever Control panel CONTROL PANEL Receiver window for remote control signal Display SELECTOR indicator " SELECTOR pad TEMPERATURE setting pad Lower temp. ---- Raise temp. -
Page 11: Cooling Operation
COOLING OPERATION TO CHANGE TEMPERATURE SETTING NOTE: • The latest temperature setting will be memorized and will appear on the display the next time the unit is turned on. • In cases of power outages or when the unit is disconnected; when the power is restored or the unit is plugged in, the unit and display will return to the preset conditions of 74°F and HIGH COOL. -
Page 12: To Change Fan Speed And Operation Mode
HOW TO OPERATE TO CHANGE FAN SPEED AND OPERATION MODE NOTES ON OPERATION MODE: MODE SELECTOR HIGH COOL COOL COOL MED COOL LOW COOL COOL HIGH FAN MED FAN LOW FAN • The latest operation mode will be memorized and the selector indicator and display will light when the unit is turned on. -
Page 13: Energy Saver
ENERGY SAVER During normal operation, the thermostat automatically controls cooling and the fan runs continu- ously. When the ENERGY SAVER is selected, the thermostat automatically controls cooling and the fan automatically stops when the compressor is not operating. (Fan will stop 30 seconds after the compressor stops. -
Page 14: On Timer Operation
HOW TO OPERATE ON TIMER OPERATION • This unit has a built-in timer that can be programmed to start the unit up to 12 hours in advance. You can set the timer to start in increments of 30 minutes (0.5 hours) up to 9.5 hours in advance of the start time, or in 1 hour increments from 10 to 12 hours in advance of the start time. -
Page 15: Off Timer Operation
OFF TIMER OPERATION • This unit has a built-in timer that can be programmed to shut the unit off up to 12 hours in advance. You can set the timer to stop in increments of 30 minutes (0.5 hours) up to 9.5 hours in advance of the stop time, or in 1 hour increments from 10 to 12 hours in advance of the stop time. -
Page 16: Using The Remote Control
HOW TO OPERATE USING THE REMOTE CONTROL INSTALLING BATTERIES Use two size-AAA (R03) batteries. Remove the battery compartment cover. Insert the batteries in the compartment, making sure the are properly aligned. Replace the cover. NOTES: • The battery life is approximately one year with normal use. •... - Page 17 OPERATING WITH THE REMOTE CONTROL POWER ON/OFF TEMP. TEMP. SELECTOR SET TIMER/OFF To change temperature setting when ON/OFF timer is in use 1. Push a TEMPERATURE setting button. The current set temperature will be recalled on the unit's display. 2. Use the TEMPERATURE setting buttons to set the new temperature. The new set temperature will show on the display for 5 seconds and return to the time display.
-
Page 18: Cleaning And Maintenance
ENERGY EFFICIENCY TIPS CLEANING AND MAINTENANCE CLEANING THE FILTER If the filter is clogged with dust, the amount of air flow will be reduced, resulting in poor cooling performance. The filter should be cleaned every10 days. At the beginning of every cooling season or after a long period of inactivity, clean the filter before starting the unit. -
Page 19: Before Calling For Servlce
• Did you restart the unit within 3 minutes after a power failure? If the power was off for less than 3 minutes, and you restarted the air conditioner within 3 minutes, a protective device may cause the compressor to shut off, preventing cooling for about 5 minutes. - Page 20 SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07430-2135 SHARP CORPORATION Osaka, Japan Printed in Thailand...
