- 1 Table of Contents
- 1 1 Specifications
- 2 2 Exploded View
- 3 3 Block Diagrams
-
4
4 Diagrams
- 4.1 Printed Wiring Board (PM-41 (-21/-31) Board)
- 4.2 Schematic Diagram (PM-41 (-21/-31) Board (1/6))
- 4.3 Schematic Diagram (PM-41 (-21/-31) Board (2/6))
- 4.4 Schematic Diagram (PM-41 (-21/-31) Board (3/6))
- 4.5 Schematic Diagram (PM-41 (-21/-31) Board (4/6))
- 4.6 Schematic Diagram (PM-41 (-21/-31) Board (5/6))
- 4.7 Schematic Diagram (PM-41 (-21/-31) Board (6/6))
- 5 5 Electrical Parts List
- Download this manual
See also:
Service Manual
Advertisement
Table of Contents
Related Manuals for Sony PS one Series
Summary of Contents for Sony PS one Series
-
Page 2: Table Of Contents
Reproduction prohibited TABLE OF CONTENTS Notice This manual is copyrighted by Sony Computer Entertainment Inc. All rights Reserved. 1. SPECIFICATIONS ..................1-1 2. EXPLODED VIEW No re-produced or transferred required except permission by Sony Computer 2-1. Main Block ..................... 2-1 Entertainment Inc. -
Page 3: Specifications
Reproduction prohibited SECTION 1 SPECIFICATIONS SCPH-100 General Laser diode properties Outputs on the rear Supplied accessories • Material : GaAlAs Power requirements AV MULTI OUT connector (1) AC Adaptor (1) • Wavelength : l=780 nm DC IN 7.5 V AV Cable •... -
Page 4: Exploded View
Reproduction prohibited Reproduction prohibited SECTION 2 EXPLODED VIEW NOTE: Ref. No. Part No. Description Remark • The mechanical parts with no reference A-shield X-3950-906-1 SHIELD (A) ASSY NOTE: The components identified by number in the exploded views are not supplied. B-shield 3-063-429-01 SHIELD (B) -
Page 5: Block Diagrams
Reproduction prohibited SECTION 3 BLOCK DIAGRAMS THIS NOTE IS COMMON FOR PRINTED WIRING 3-1. OVERALL BLOCK DIAGRAM BOARDS AND SCHEMATIC DIAGRAMS. Note on Printed Wiring Boards : • Through hole is omitted. • b : Pattern on the side which is seen. PM-41 BOARD •... -
Page 6: Diagrams
Reproduction prohibited SECTION 4 DIAGRAMS 4-1. PRINTED WIRING BOARD (PM-41 (-21/-31) BOARD) PM-41 BOARD D003 CN102 CN101 S001 R150 D104 OPTICAL I/ / RESET FB118 DEVICE D103 C152 C742 Q003 L104 FB003 CN702 C130 S301 D101 RB123 CN701 R134 (CD DOOR OPEN/CLOSE DET) R745 R748 C605... -
Page 7: Schematic Diagram (Pm-41 (-21/-31) Board (1/6))
Reproduction prohibited 4-2. SCHEMATIC DIAGRAM (PM-41 (-21/-31) BOARD (1/6)) PM-41(-21/-31) BOARD (1/6) IC102 BOOT ROM 4MBIT IC102 MSM534031E-40GS-KPR2 (101) MSM534031E-41GS-KPR2 (102) IC103 IC106 DRAM 16MBIT... -
Page 8: Schematic Diagram (Pm-41 (-21/-31) Board (2/6))
Reproduction prohibited 4-3. SCHEMATIC DIAGRAM (PM-41 (-21/-31) BOARD (2/6)) PM-41(-21/-31) BOARD (2/6) IC201 SG-RAM IC203 X201 IC204 14.318182MHz (NTSC) 17.73447MHz (PAL) IC204 CY2081SL-500T (NTSC) CY2081SL-509T (PAL) -
Page 9: Schematic Diagram (Pm-41 (-21/-31) Board (3/6))
Reproduction prohibited 4-4. SCHEMATIC DIAGRAM (PM-41 (-21/-31) BOARD (3/6)) PM-41(-21/-31) BOARD (3/6) IC310 4M BIT DRAM CD DOOR IC304 OPEN/CLOSE IC304 MECHANISM CONTROL IC304 MC68HC05G6-SC430944PBEB1 (101) MC68HC05G6-SC430943PBEB1 (102) -
Page 10: Schematic Diagram (Pm-41 (-21/-31) Board (4/6))
Reproduction prohibited 4-5. SCHEMATIC DIAGRAM (PM-41 (-21/-31) BOARD (4/6)) PM-41(-21/-31) BOARD (4/6) IC405 AUDIO AMP AV MULTI OUT (101) (102) IC502 VDAC+ RGB ENCODER Q505 SWITCH 3.44 4-10... -
Page 11: Schematic Diagram (Pm-41 (-21/-31) Board (5/6))
Reproduction prohibited 4-6. SCHEMATIC DIAGRAM (PM-41 (-21/-31) BOARD (5/6)) PM-41(-21/-31) BOARD (5/6) Q602 3.5V REG /RESET (-21) (-31) DC IN 7.5V (101) (102) (-21) (-31) (-21) (-31) (-31) (-21) IC002 RESET IC606 IC607 IC003 3.5V REG 3.5V REG RESET LED DRIVE (-31) (-31) (-21) -
Page 12: Schematic Diagram (Pm-41 (-21/-31) Board (6/6))
Reproduction prohibited 4-7. SCHEMATIC DIAGRAM (PM-41 (-21/-31) BOARD (6/6)) PM-41(-21/-31) BOARD (6/6) Q701 LD DRIVE IC723 RF AMP OPTICAL DEVICE IC722 SPINDLE MOTOR FOCUS/TRACKING COIL DRIVE MOTOR DRIVE SLED MOTOR IC732 CD DSP+DIGITAL SERVO+ CD ROM DECODER+SPU 4-13 4-14... -
Page 13: Electrical Parts List
Reproduction prohibited Reproduction prohibited SECTION 5 ELECTRICAL PARTS LIST NOTE: SC Ref. No. Part No. Description Remark SC Ref. No. Part No. Description Remark • Due to standardization, replacements in • CAPACITORS C327 1-162-964-11 CERAMIC CHIP 0.001uF C663 1-126-209-11 ELECT CHIP 100uF The components identified by uF : µF... - Page 14 Reproduction prohibited Reproduction prohibited SC Ref. No. Part No. Description Remark SC Ref. No. Part No. Description Remark SC Ref. No. Part No. Description Remark SC Ref. No. Part No. Description Remark < CONNECTOR > < FERRITE BEAD > IC203 8-759-366-69 IC CXD8561Q L607 1-412-960-21 INDUCTOR...
- Page 15 Reproduction prohibited Reproduction prohibited SC Ref. No. Part No. Description Remark SC Ref. No. Part No. Description Remark SC Ref. No. Part No. Description Remark R204 1-216-801-11 METAL CHIP 1/16W R717 1-216-809-11 METAL CHIP 1/16W ACCESSORIES & PACKING MATERIALS R205 1-216-813-11 METAL CHIP 1/16W R723...
