4.13

Connecting the USB11A interface adapter

4.13.1 Part number
Interface adapter option USB11A: 08248311
4.13.2 Scope of Delivery
•
•
4.13.3 Connecting MOVIDRIVE
•
•
•
•
•
MOVIDRIVE
The scope of delivery for the USB11A includes:
– USB11A interface adapter
– USB connection cable PC – USB11A (type USB A-B)
– Connection cable for MOVIDRIVE
cable)
– CD-ROM with drivers and MOVITOOLS
The USB11A interface adapter supports USB 1.1 and USB 2.0.
®
-USB11A – PC
Use the connection cable [1] (RJ10 – RJ10) supplied to connect the USB11A op-
®
tion to MOVIDRIVE .
Plug the connection cable [1] into the XT slot of MOVIDRIVE
into the RS485 slot of the USB11A.
Note that the DBG60B keypad and the USB11A interface adapter cannot be con-
nected to the MOVIDRIVE
Use the supplied USB connection cable [2] (type USB A-B) to connect the US-
B11A to the PC.
The following figure shows the connection cable between MOVIDRIVE
MDX60B/61B and USB11A.
®
MDX60/61B
[1]
Connecting the USB11A interface adapter
®
MDX60B/61B – USB11A (RJ10 – RJ10
®
MotionStudio
®
at the same time.
[2]
USB11A
Operating Instructions – MOVIDRIVE
Installation
®
MDX60B/61B and
PC COM 1-4
1806016651
®
MDX60B/61B
