Robinson R66 Installation Instructions

R66 Aux Fuel Tank Installation Relay Upgrade Kit Instructions
Visit
Review instructions before installation; contact RHC Technical Support
with questions. Verify kit contents match list; contact RHC Customer
Service if parts are missing or damaged.
ITEM PART NUMBER
1 KI-239-4 Instr.
2 B158-10-SB-24
3 D835-4
4 XESR10-S01-FP-0787
5 MS21042L08
6 MS27039C0807
7 MS3367-3-9
8 MS3367-5-9+
9 MS3367-7-9+
10 NAS1149FN816P+

Kit Instructions

1. Remove aux tank per R66 Maintenance Manual (MM) § 28-51.
2. Remove aft, right seat back (back rest) assembly per MM § 25-22.
3. Refer to Figure 1. Locate G655-3 time delay connected to airframe harness plug labeled "AUX FUEL
TIME DLY". Disconnect aux fuel time delay and remove. Determine if (removed) time delay is affected
by R66 SB-24; discard if affected by SB-24, otherwise retain as spare, if desired.
Helicopters equipped with air conditioning have an additional G655-3
time delay installed. Ensure time delay removed is disconnected from
harness connector labeled "AUX FUEL TIME DLY".
4. Refer to Figure 3. Slide B158-10-SB-24 heat shrink over [removed time delay] airframe connector
(marked "AUX FUEL TIME DLY") so "SB-24" is visible and apply heat. Verify connector is insulated and
heat shrink is secure.
5. Refer to Figure 1. Remove ty-raps securing G656-1 module (generator-reset) to harness but do not
disconnect attached connector. If air conditioning (A/C) is installed, locate G655-3 time delay connected
to airframe harness plug labeled "A/C TIME DLY" and remove ty-raps securing time delay.
6 DEC 2018
(To comply with R66 Service Bulletin SB-24)
www.robinsonheli.com
Kit Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heat Shrink – 5/8-inch diameter, 1.50 inches long (marked "SB-24") . . . .
Harness Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Time Delay Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ty-rap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ty-rap (Note: "+" in contents part number indicates 20-qty pack) . . . . . . . .
Ty-rap (Note: "+" in contents part number indicates 10-qty pack) . . . . . . . .
Washer (Note: "+" in contents part number indicates 20-qty pack) . . . . . .
R66 Aux Fuel Tank Installation Time Delay Upgrade Kit
NOTE
to verify kit instructions are current revision.
KIT CONTENTS
CAUTION
KI-239-4 Revision B
QTY
1
2
1
1
2
2
5
1
1
1
Page 1 of 5
