1. Introduction

Thank you for choosing a quality instrument from Swema.
SwemaFlow 125D measures air flow directly in l/s, m3/h or cfm
(when set to US units). The instrument is turned on and off with the
red button next to the display. When the instrument is turned on the
display shows first the firmware version then the voltage of the bat-
tery. After a few seconds the instrument is ready for measurement.
The instrument is automatically turned off after ten minutes.
The measuring equipment includes:
• Flow capture instrument
• Flow hood 300x300mm for exhaust flow (Some valves also supply)
• Carrying case, USB-cable, charger, Operating instructions
• Calibration certificate
Accessories:
Supply / Exhaust Flow hood 650 x 650 mm, h = 800 mm, Part.no: 758950
Cross for Swirl diffusers, Part no. 769650
Supply / Exhaust Flow hood 250 x 650 mm, h = 800 mm, Part.no: 760740
Exhaust Flow hood 300 x 300 mm, h = 130 mm, Part.no: 761550

2. Technical data

Measuring range:
Air Flow: 1,5... 125 l/s, 5,4... 450 m3/h, 3.2... 260 cfm
Temperature: 0...+50°C, 32...122°F
Barometer: 600... 1200 hPa, 18...35 inHg
Measurement uncertainty:
Air Flow: ±3% read value, min 0,5 l/s
Temperature: ±0,5°C
Barometer: ±3,5 hPa
Back-pressure method uncertainty: ±10% min 1 l/s
At 95% coverage probability in non condensing, non moist air, <80
% RH, non aggressive gases
Measuring method:
Mass flow, net of hot wires
Weight:
1,975 kg (including capture hood 300x300mm and throttle ring )
