VAMPIRE NIGHT SD
OPERATORS MANUAL
I
T IS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY
,
AT ALL TIMES
AND IT IS IMPERATIVE THAT THE DETAILS SET OUT IN THIS MANUAL
ARE FOLLOWED PRECISELY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vampire Night SD and is the answer not in the manual?

Questions and answers

Related Manuals for NAMCO Vampire Night SD

Summary of Contents for NAMCO Vampire Night SD

  • Page 1 VAMPIRE NIGHT SD OPERATORS MANUAL T IS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY AT ALL TIMES AND IT IS IMPERATIVE THAT THE DETAILS SET OUT IN THIS MANUAL ARE FOLLOWED PRECISELY...
  • Page 3 is a copyrighted anti-copying technology created by Sony Corp. This mark does not necessarily imply compatibility with other products bearing the “MAGICGATE” trademark. is a trademark of Sony Corporation. Le présent document vous informe que ce produit peut être soumis à la législation de contrôle des exportations nationales.
  • Page 4 Contents ΕΞΕΤΑΣΗ ΓΕΝΙΚΗΣ ΑΣΦΑΛΕΙΑΣ ....................

  • Page 6: Safety Notes

    SAFETY NOTES...
  • Page 7 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...
  • Page 8 SICHERHEITSHINWEISE...
  • Page 9 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...
  • Page 11 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...
  • Page 13 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...

  • Page 14: Mesures De Securite

    MESURES DE SECURITE...
  • Page 15 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...
  • Page 16 Καθώς αυτές οι πληροφορίες σε αυτ το εγχειρίδιο έχουν δοθεί µε καλή πίστη και ακριβώς την ώρα της τύπωσης , η εταιρεία NAMCO EUROPE LIMITED κρατάει το δικαίωµα να κάνει οποιεσδήποτε αλλαγές χωρίς ειδοποίηση. Τα µηχανήµατα έχουν κατασκευαστεί σύµφωνα µε τους ρους της Ευρωπαϊκής Κοιν τητας , και έχουν ελεγχθεί σύµφωνα µε τους ν µους...
  • Page 17 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...
  • Page 19 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...
  • Page 21 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...
  • Page 23 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...

  • Page 24: Avisos De Segurança

    AVISOS DE SEGURANÇA...
  • Page 25 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...
  • Page 27 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...
  • Page 29 1 m 90 cm or more 50 cm or more 50 cm or more Play zone Aisle...

  • Page 30: Specifications

    1. SPECIFICATIONS POWER SUPPLY:- AMBIENT OPERATING TEMPERATURE MONITOR:- COIN ACCEPTOR:- DIMENSIONS:- WEIGHT:- ACCESSORIES:-...

  • Page 31: How To Play

    2. HOW TO PLAY • • • • • • • • • • • • •...
  • Page 32 3. MAJOR COMPONENNTS Header Assy Gun Assy Play panel Assy Monitor Cabinet Camera Assy Mains-In Assy Game PCB Assy...

  • Page 33: Moving The Machine

    4. MOVING THE MACHINE 5. INSTALLATION...
  • Page 35 ΤΟ ΜΗΧΑΝΗΜΑ ΕΙΝΑΙ ΣΧΕ∆ΙΑΣΜΕΝΟ ΓΙΑ ΧΡΗΣΗ ΣΕ ΕΣΩΤΕΡΙΚΟ ΧΩΡΟ ΜΟΝΟ ΜΗΝ ΤΟΠΟΘΕΤΗΣΕΤΕ ΤΟ ΜΗΧΑΝΗΜΑ ΣΤΟΥΣ ΑΚΟΛΟΥΘΟΥΣ ΧΩΡΟΥΣ Εξωτερικά Απευθείας στον ήλιο,σε µέρη που υπάρχει υγρασία ή σκ νη,µέρη που υπάρχει άφθονο νερ ,κοντά σε air-condition ή άλλου είδους θέρµανση,µέρη µε υπερβολική υψηλή...
  • Page 37 × Pozi head screws (M5 Connector × Pozi head screw (M5 Header Assy Monitor cabinet...
  • Page 38 Approx. 5mm Castor Level adjuster Note: If the site of this game has a smooth or polished floor, it is recommended that rubber pads are fitted under the Level Adjusters to prevent the game sliding on the floor when in use.
  • Page 39 • • • CD-ROM tray Operating lamp EJECT button Game PCB Assy CD-ROM Tray...
  • Page 40 6 ADJUSTMENTS Μετατροπές ή επιδιορθώσεις στα µηχανήµατα πρέπει να γίνονται µ νο απ εξουσιοδοτηµένα άτοµα.
  • Page 41 COIN COUNTER 2 Amp Q/B (Coin Fuse) PLAYER 1 SELECT DOWN ENTER TEST SERVICE...
  • Page 42 The Test Switch must always be in the “OFF” position for normal game mode. MENU Used to set the price of play COIN OPTIONS Used to set the game options GAME OPTIONS Used for testing switches etc. I/O TEST MONITOR TEST Used to adjust the monitor Used to set sound levels SOUND TEST...

  • Page 43: Coin Options

    Note:- The price of play on this machine is set within the Cashflow Coin Mech. Ensure that the Game Cost is set to 1 Coin 1 Credit. COIN OPTIONS [DEFAULT IN GREEN] GAME COST 1 COIN/S 1 CREDIT CONTINUE COST 1 COIN 1 CREDIT FREE PLAY EXIT...

  • Page 44: Game Options

    GAME OPTIONS [DEFAULT IN GREEN] PLAYER'S LIFE MAX LIFE DIFFICULTY E(NORMAL-NORMAL) HIT COLOR HI-SCORE INIT EXIT SELECT SW:CHOOSE ENTER SW:ENTER...
  • Page 45 I/O TEST GUN INITIALIZE SWITCH TEST EXIT SELECT SW:CHOOSE ENTER SW:ENTER...
  • Page 46 GUN INITIALIZE OUT OF SCREEN 1P OUT OF SCREEN 2P (1P Gun crosshair) Appears when the gun is pointed at the screen. The 1P sight is red. CAMERA PARAMETER (2P Gun crosshair) AIM AT SCREEN Appears when the TO CHECK GUN ACCURACY gun is pointed at the screen.
  • Page 47 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER...
  • Page 48 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER...
  • Page 49 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER 1P GUN INITIALIZE SIGHT ALIGNMENT AIM AT CENRE OF THE CROSS AND PULL 1P GUN TRIGGER...

  • Page 50: Switch Test

    I/O TEST SWITCH TEST COIN SERVICE TEST UP SELECT DOWN SELECT ENTER START 1P BUTTON START 2P BUTTON GUN 1P TRIGGER GUN 2P TRIGGER SENSOR UP SELECT SW+ENTER SW:EXIT...

  • Page 51: Monitor Test

    MONITOR TEST GRADATION PATTERN CROSSHATCH PATTERN (CRT) CROSSHATCH PATTERN (PROJECTOR) WHITE WINDOW (H) WHITE WINDOW (M) WHITE WINDOW (L) INTERLACE PATTERN VIEW ANGLE ADJUST (CRT) VIEW ANGLE ADJUST (PROJECTOR) FULL WHITE EXIT SELECT SW:CHOOSE ENTER SW:ENTER...

  • Page 52: Sound Test

    SOUND TEST [DEFAULT IN GREEN] VOLUME ALL SP [0∼64] 14 ATTRACT [0∼64] 14 REQUEST BGM VOICE MESSAGE: EXIT SELECT SW :CHOOSE ENTER SW :ENTER SERVICE SW :REQUEST ON/OFF...
  • Page 53 ADS DATA GAME REPORT GAME HISTOGRAM ADS INITIALIZE EXIT SELECT SW :CHOOSE ENTER SW :ENTER...
  • Page 54 GAME REPORT TOTAL COINS 00000000 TOTAL SERVICES 00000000 POWER ON TIME 000d00h00m00s TOTAL PLAY 00000000 000d00h00m00s FIRST PLAY 00000000 000d00h00m00s CONTINUE PLAY 00000000 000D00h00m00s FIRST CONTINUE 00000000 AVERAGE PLAY 00m00s LONGEST PLAY 00m00s SHORTEST PLAY 00m00s...
  • Page 55 GAME HISTOGRAM 0M 00S 0M 29S 0000 0M 30S 0M 59S 0000 1M 00S 1M 29S 0000 1M 30S 1M 59S 0000 2M 00S 1M 29S 0000 2M 30S 2M 59S 0000 3M 00S 3M 29S 0000 3M 30S 3M 59S 0000 4M 00S 4M 29S 0000 4M 30S...
  • Page 56 ADS INITIALIZE ADS INITIALIZE EXIT SELECT SW :CHOOSE ENTER SW :ENTER...
  • Page 57 OTHERS ROM1 Ver .00/12/09 SAT 02:27:14 CLOCK .00/12/22 FRI 16:05:54 123456-123456 BACKUP MEMORY INITIALIZE NO EXIT SELECT SW :CHOOSE ENTERSW :ENTER...

  • Page 58: Maintenance

    7. MAINTENANCE Μετατροπές ή επιδιορθώσεις στα µηχανήµατα πρέπει να γίνονται µ νο απ εξουσιοδοτηµένα άτοµα. Να είναι σίγουρα κλειστ το ρεύµα πριν οποιαδήποτε δουλειά στο µηχάνηµα.
  • Page 60 Front glass Retaining bracket Pozi head screw × × Security screw (M5 Control panel Assy...
  • Page 61 Mirror Fit the mirror with the label in this position (upper face). Mirror stopper Pozi head screws (with flat and spring washers) × Note: When refitting the Mirror ensure that the mirror is fitted the correct way round, label on top.
  • Page 62 × Pozi head screws (M5 Retaining bracket Header acrylic Starter Fluorescent lamp...
  • Page 63 × Pozi head screws (M5 Camera Assy Connectors CCD camera (Note direction) Pozi head screws × Connector Camera filter (Note direction) Note: Always reinitialize the guns if the camera has been removed or replaced. (see 6-2-3-1 page 46)
  • Page 64 × Security screws (M5 Flat washer (M5) Play panel × Security screws (M5 Flat washer (M5) Play panel Connector...
  • Page 65 Play panel back 1P side Microswitch Violet 2P side Black Microswitch Faston terminals Whi/Vio Black Faston terminals When replacing the switch, note which wires are on which terminals.
  • Page 66 Note: There is a star washer and Earth terminal fitted on the 1P position. Gun Assy Connector cover Rope hoop Play panel Star washer Connector (1P only) Ground terminal (1P only) Whizz nut (M6) Whizz nut (M4) Play panel underside Note: Always reinitialize the guns if the guns has been removed or replaced.
  • Page 67 Dome nut (M4) Socket cap screw (M3x10) Gun cover (L) Socket head screw (M4x25) Socket cap screw Gun cover (R) (M3x10)
  • Page 68 Dome nut (M4) Socket head screw (M4x25) Lens Gun Body (L) NF-Gun (DX) PC Board Socket head screw Gun Body (R) (M4x10) Socket cap screw Socket head screw (M3x10) (M4x10) Note: When reassembling the Gun Body ensure that the Lens is fitted correctly, (Curved face of lens faces forward.).
  • Page 69 Trigger switch (Yellow) N.O. terminal (Black) COM. terminal Note: Ensure that the correct wires are fitted to the correct switch terminals when refitting the Trigger Microswitch. Note: Always reinitialize the guns if the gun has been removed or replaced. (see 6-2-3-1 page 46)
  • Page 70 Fast-On terminals Socket head screw Earth terminal (M4x10) Socket head screw PCB connector (M4x10) Connector cover Gun body (L) Gun cable Connector Note: When refitting the Gun Cable, ensure that the Earth terminal is refitted securely. Note: Always reinitialize the guns if the gun has been removed or replaced. (see 6-2-3-1 page 46)
  • Page 71 Monitor mask Pozi head screws (M6x16), with flat and spring washers. Monitor...
  • Page 72 8. PARTS (Opposite side (Opposite side 26 25...
  • Page 73 e l l r r i e l l r r i " 8 c t i c t i l i h p i l...
  • Page 74 c t i d i l c t i c t i t l i c t i c t i...
  • Page 75 c i l c i l t t i...
  • Page 76 a l l t l i a l l...
  • Page 79 d i l d i l d i l c t i i l e...
  • Page 80 9. SCHEMATIC pBASS AMP J105 D-sub PCB Assy V RED MOTHER GREEN V GREEN BLUE V BLUE PCB Assy AMP MINI 6P J9 BLACK J10 AMP MINI 2P V GND YELLOW CLEAR/YEL (COPPER) WHITE +12v SP1 OUT + V SYNC BLACK CLEAR/YEL (TIN) SP1 OUT -...
