Senco FramePro 601 Specifications

Fastening Solutions
Best Value in the Industry!
Clipped head nailers provide all the important features you want at an
affordable price. These compact framers are easy to handle, and easy
on the arm. Their 30˚ short, in-line magazines provide excellent
maneuverability and line of sight. These powerful framers drive a
wide range of fasteners in four gauges (.113 – .148) from 2" to 3-
handle virtually any job.
Applications:
Framing, truss building, subflooring, sheathing, decking, siding,
fencing, pallets and crate assembly
.
Features and Benefits:
• Sawtooth safety that digs in for precision toenailing
• Shorter, straight-line 30˚ magazine for better line of sight
and superior maneuverability
• Drives ring and smooth shank nails in four gauges (.113 –.148)
from 2" to 3- ⁄ "
1
2
• Reliable internal design with full round driver
• Adjustable exhaust
• Lightweight and powerful
• Adjustable depth-of-drive control
• Soft comfort grip handle reduces fatigue
• One-year warranty
Tool Specifications:
FramePro 601
Power: 884 in/lbs
Tool Weight: 8 lbs (3.6 kg)
Height: 13 .5" (343 mm)
Length: 14.8" (376 mm)
Nail Capacity: 65
Reg. Operating Pressure: 70-120 psig
Mode of Operation: Available with either Dual Action or Restrictive
Trigger activating mechanisms.
•
©2005 SENCO Products, Inc.
Clipped Head Framing/Sheathing Nailer
™
⁄ " to
1
2
www.senco.com
FramePro
Fastener Specifications:
The 601 nailers drive 2" – 3-
1
or plain) and 2"– 3" ring shank nails. Shank diameters include
.113, .120, and .131.
Sequential Actuation Trigger (also known as restrictive trigger or trigger fire) operates
in the following a sequence - depress the safety element at the nose of tool against the
work surface then pull the trigger. After each fastener is driven, release the trigger and
lift the tool off the work surface before starting the sequence again. This trigger is
recommended and acceptable for most applications.
Contact Actuation Trigger (also known as dual action, bounce or bottom fire)
operates in the following sequence- pull the trigger first and keep the trigger pulled
while moving the tool along the work surface with a bouncing motion, depressing the
safety element at the nose of the tool against the work surface where the fastener is to
be driven. This trigger is recommended for use by trained professionals only in high
production or volume applications.
Always read the Operators Manual and Safety Instructions with all tools to ensure
proper use and safety precautions or contact SENCO for more information on our
trigger systems. Choose the right trigger system for your specific needs!
For additional information on how SENCO Fastening Solutions will save you time,
reduce costs, and increase quality, call our toll-free Action Line: 1-800-543-4596 to
find your nearest Authorized Senco Dealer or Distributor.
Visit our web site at: www.senco.com
601
®
⁄ " smooth shank nails (Sencote
2
Safety First. The only way to work.
®
®
