Chapter 1:About ADVENTURER 3
Chapter 1:About ADVENTURER 3
Chapter 1:About ADVENTURER 3
Chapter 1:About ADVENTURER 3
Chapter 1:About ADVENTURER 3
Chapter 2: ADVENTURER 3 Operating
Chapter 2: ADVENTURER 3 Operating
Chapter 2: ADVENTURER 3 Operating
Chapter 2: ADVENTURER 3 Operating
Chapter 2: ADVENTURER 3 Operating
Chapter 2: ADVENTURER 3 Operating
Unpacking / Accessories / First Print
Load Filament / Communication / Model Print / Model Remove /
Replace Filament / Interface Menus Introduction
Chapter 3: Q&A
Chapter 3: Q&A
Chapter 3: Q&A
Chapter 3: Q&A
Chapter 3: Q&A
Chapter 4: Supports and Service
Chapter 4: Supports and Service
Chapter 4: Supports and Service
Chapter 4: Supports and Service
Chapter 4: Supports and Service
Content
01
06
07
28
31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADVENTURER 3 and is the answer not in the manual?

Questions and answers

Related Manuals for Flashforge ADVENTURER 3

Summary of Contents for Flashforge ADVENTURER 3

  • Page 1 Chapter 1:About ADVENTURER 3 Chapter 1:About ADVENTURER 3 Chapter 1:About ADVENTURER 3 Components Introduce / Reference Chapter 2: ADVENTURER 3 Operating Chapter 2: ADVENTURER 3 Operating Chapter 2: ADVENTURER 3 Operating Chapter 2: ADVENTURER 3 Operating Chapter 2: ADVENTURER 3 Operating...
  • Page 2 3D printing technology, we still recommend that please read this guide, as there is lots of important information about the ADVENTURER 3 for you to get a better 3D experience. For a better and more successful printing experience, you can refer to the following materials: Quick Start Guide: Users will find the Quick Start Guide together with the printer accessories.
  • Page 3 SAFETY WARNINGS AND NOTICE BELOW. Work Environment Safety Keep your work place tidy. Do not operate ADVENTURER 3 in the presence of flammable liquids, gases or dust. Keep ADVENTURER 3 out of children and untrained people’s reach. Electrical Safety Always use the Finder with a properly grounded outlet. Do not refit Finder plug.
  • Page 4 35cm. Device storage temperature: RT 0-40℃ Filament Requirements Do not abuse the filament. Please make sure you use the FlashForge filament or the filament from the brands accepted by FlashForge. Nozzle clogging and damage may be caused by non-FlashForge filament due to inappropriate material properties.
  • Page 5 Terms The surface on which the ADVENTURER 3 builds an object. Build Plate The blue tape that covers ADVENTURER 3 ’s build plate so that Build Tape the object can stick to the build plate well. The three dimensional amount of space that an object will use once it is completed.
  • Page 6 Chapter 1:About ADVENTURER 3 Chapter 1:About ADVENTURER 3 Chapter 1:About ADVENTURER 3 Chapter 1:About ADVENTURER 3 1.1 Components Introduce 1. Filament guide tube 2. Filament guide tube joint 3. Extruder base 4.Cooling Fan 5. Removable nozzle 6. Extruder cables 7. Clip 8.
  • Page 7 1.2 Reference Name ADVENTURER 3 1, Removable Number of Extruder Fused Filament Fabrication (FFF) Print Technology 2.8" color IPS Touch Screen Screen Size 150×150×150mm Build Volume 0.05-0.4mm Layer Resolution ±0.2mm Build Accuracy Z axis 0.0025mm; XY axis 0.011mm Positioning Accuracy 1.75mm (±0.07mm)
  • Page 8 Chapter 2: Operating 2.1 Unpacking The People's The People's Insuranc e Compan Insuranc e Compan y of China y of China KEEP DRY KEEP DRY HANDL E HAND LE WITH CARE FRAGI LE WITH CARE FRAGI LE FR AG HA ND CA RE WI TH DR Y...
  • Page 9 2.2 Accessories 3D Printer Filament Power Cable After-sales service card User Guide Screwdriver Unclogging Pin Tool Allen Wrench Grease...
  • Page 10 2.3 First Print Plug the power cable into the input on the back and turn on the power switch, the touch screen is turned on. Power Switch Load Filament 1. Open the filament cover, insert the filament into the filament intake, push filament into the feeding wheel until some resistance is sensed.
  • Page 11 /220℃ Build Load Extruder heating on... Tools Replace Filament Cancel 2. Tap [Filament]--Tap [Load]--After Load completed--Tap [OK] /220℃ /220℃ Preheating completed, when filament load the extruder steadily, replace completed. Load begins. 3. Load completed when you see filament come out of extruder, Tap [OK]. Put a spool of filament on the spool holder, close the filament cover.
  • Page 12 Communication After generating the Gcode file, you can transfer it to your ADVENTURER 3 with different communication methods. If use USB stick to print, please insert your USB stick with target .g/.gx file to your ADVENTURER 3, there will be no need to set new communication.
  • Page 13 Cloud Connection Cloud connecting Preheat WiFi Hotspot Communication Printer Name: Registration Coad: JMTGZS Setting About Cloud Ethernet 1. Turn on the WiFi or Ethernet connection, connect the printer to internet. 2. Tap[Tools]-Tap[Communication]-Tap[Cloud] on the printer; 3. Turn on the Cloud Connection function; 4.
  • Page 14 Model Print 6.62GB Build Not Available Tools No task Filament 1 . Tap [Build], choose the file path: SD card, USB stick, Cloud. Backkom.g Christmas stocking.g Christmas.g Christmas stocking(1).g < < 2 . Choose the model file, tap on its right to start printing; or tap model picture or model name to enterdetail page, tap to start printing.
  • Page 15 Model Remove Take out the removable build plate. Notices When printing completed, extruder and build plate may still hot, please start operating after cooling down! 2 . Bend the build plate, the plate will produce certain deformation, seperating the plate away from the bottom of model (Please use a scraper to assist removing when model is too small or big).
  • Page 16 Replace filament /220℃ Load Extruder heating on... Replace Cancel 1 . Tap [Filament]--Tap [Replace], extruder will start preheating. 2 . Pull out the filament as the picture 3 . Insert new filament into the filament intake showed above. and push the filament into the feeding wheel until resistance is sensed.
  • Page 17 Interface Menus Introduction Build 6.62GB Read the print file from: Build The local memory card The USB stick Not Available Tools The Cloud No task Filament Back: Back to upper interface 1 . Tap [Print]. 2 . Choose the read path of the print file File list. check all Backkom.g Christmas stocking.g...
  • Page 18 F-40mm_Box.gx File details: Including file picture, time needed, filament needed. 7.49 Build: To begin printing the file. Copy: To copy the files to the local memory card from the USB stick. Delete: To delete the print file. Print interface Cancel: To cancel the print job. F-40mm_Box.gx Pause/Resume: To suspend or resume the print job.
  • Page 19 Current task pavilion.gx warrior.gx warrior.gx Cloud task downloading... basket.gx < < Print from USB stick is the same from SD card. Cloud printing shows the current tasks. When cloud initiate print order, printer will receive the order, start downloading model files. Past task If cloud is showed in task list, printer will only show current pavilion.gx...
  • Page 20 Filament Tools interface Preheat: To preheat the extruder and build plate. Preheat: To preheat the extruder and build plate. Setting: To implement relevant function setups. About: Information about the printer. WiFi Flashforge WiFi Hotspot Choose a network ChinaNet-AnCr TP-LINK_EDC2 Cloud...
  • Page 21 Setup WLan hotspot WLan hotspot SSID: WiFi Hotspot SSID: Password: Password: Setup hotspot Cloud Ethernet Save Hotspot: To set your printer as a WLAN hotspot. Turn on/off the WLAN hotspot. Hotspot setting: To set the hotspot name and password. Input hotspot name with numbers, characters and symbols.
  • Page 22 Extruder ℃ Preheat Communication Platform ℃ Setting About Start Preheat setting ON/OFF: Turn ON/OFF the extruder or platform preheat; symbol, you could set preheat temperature; Long press symbol, set preheat temperature rapidly; Extruder Extruder /220℃ ℃ Platform /100℃ Abort Abort Extruder/Platform preheat interface It contains actual temperature, target temperature and heating progress.
  • Page 23 Preheat Communication Setting About < < < < 1/ 2 2 / 2 Setting interface Status language Filament Check Factory Reset Calibration Home Door Open Check Door open check Manual Update Light ℃ ℃ Load Closed X: 20.00 Y: 45.00 Z: 36.00 <...
  • Page 24 < < < < < < Language setting: Include Chinese, English, Japanese, Deutsch, French and Español. Calibration Click the arrow to adjust the nozzle so that it just touches To calibrate the initial distance the platform between extruderand platform. 0.00 Z axis , after homing Extruder...
  • Page 25 X: 20.00 Y: 45.00 Z: 36.00 < < 1/ 2 Manual: To manually adjust the positions of X, Y and Z axes. Extruder moves to the right; Extruder moves to the left; Extruder moves to the front; Extruder moves to the back; Extruder moves upward;...
  • Page 26 Door open check: To turn on/off the door open check, notice will pop out when door is open when the check is turned on. Light: To turn on/off the light. Light: To turn on/off the light. Machine Type: Build Volume: ADVENTURER 3 150 x 150 x 150 Serial No: Usage counter: 123456 12 hours...
  • Page 27 Filament /220℃ /220℃ /220℃ Load Extruder heating on... Preheating completed, When filament load the extruder Load begins. steadily, replace completed. Replace Cancel Load • The extruder is heated up to 220℃. • After heat completed, insert the filament into the extruder at an upright angle until some resistance is sensed(as the filament is pushed through the feeding wheel).
  • Page 28 Chapter 3: Q&A Q1. How to solve if the nozzle is clogged？ Method 1: Tap [Preheat], heat up the extruder to 200℃, after heating completed, press the air tube joint and pull out the filament guide tube. Check to see whether the filament is bended or filament tip is not smooth, cut filament tip smooth and flat, install the guide tube and filament back, Tap [Load] .
  • Page 29 Q9: Can we use other brand filament which is not produced by Flashforge ? ADVENTURER 3 support normal ABS and PLA filament but different brand filament has different ingredients. ADVENTURER 3 tests out default settings according to the properties of Flashforge ABS and PLA filament.
  • Page 30 ADVENTERUR 3 ADVENTERUR 3 Yes, ADVENTURER 3 interface is open up to all other cloud platforms. Q14. Is the ABS printing safe? ABS filament will give off certain poisonous gas when heated up, please put the printer in well ventilated condition when printing ABS. We suggest printing non-toxic PLA filament when printer is used in children activity places.
  • Page 31 FlashForge team is on standby and ready to help you with any challenges you may have with your ADVENTURER 3. If the issues or questions are not covered in this User Guide, you can seek for solutions on our official website or contact us via telephone.
  • Page 32           FCC Statement    Any Changes or modifications not expressly approved by the party responsible    for compliance could void the user’s authority to operate the equipment.  This device complies with part 15 of the FCC Rules. Operation is subject to the    following two conditions:    (1) This device may not cause harmful interference, and      (2) This device must accept any interference received, including interference that    may cause undesired operation.    FCC Radiation Exposure Statement:  This equipment complies with FCC radiation exposure limits set forth for an    uncontrolled environment .This equipment should be installed and operated    with minimum distance 20cm between the radiator& your body.          Note: This equipment has been tested and found to comply with the limits for a    Class B digital device, pursuant to part 15 of the FCC Rules. These limits are    designed to provide reasonable protection against harmful interference in    a residential installation. This equipment generates, uses and can radiate    radio frequency energy and, if not installed and used in accordance with the    instructions, may cause harmful interference to radio communications. ...
