Mr. Beams NetBright Installation Instructions

Installation Instructions
NetBright
MBN391
Thank you
for purchasing the Mr Beams
NetBright UltraBright Spotlight. We are
®
committed to eliminating darkness using the latest
in Light-Emitting Diodes (LEDs). LEDs are the most
efficient and durable light sources available. We
are certain that your light will contribute to a safer
environment and provide light where you need it at
a very reasonable cost.

What is included per light:

• 1 Wireless Spotlight
• 3 Screws
• 3 Anchors

What you need to install:

• 1 Small Screwdriver
• 4 D-Cell Alkaline Batteries

Spotlight Features:

Motion/Light Sensor: Light instantly turns on when it detects motion from
up to 25 feet away. The light sensor conserves battery life by preventing the
light from activating in daylight.
Auto Shut-off: Light shuts off automatically after 20
seconds if no motion is detected.
Fully Adjustable: Light can be rotated 360° as well as 170° up and down.
Bright LEDs: 450 lumens cover up to 675 sq. ft.
Durable, Weather Resistant: Tight seals and UV resistant material allow
the light to work in all weather conditions.
Networking: Spotlights will activate simultaneously when any spotlight
within the network detects motion. They will deactivate simultaneously if no
motion is detected in the group.
NOTE: Light sensor only allows light to activate in darkness. We recommend you test in a dark room or closet.
1. Remove front cover of spotlight
by rotating counterclockwise as
shown above. Pull face out from
cup to reveal battery holder.
6. Insert spotlight back into mounting base
positioned in the desired direction. Tighten
mounting base thumb screw.
Battery Caution:
1) Do not mix old and new batteries
2) Do not mix Alkaline, Standard (Carbon-Zinc) or Rechargeable (Nickel Cadmium)
or (Nickel Metal Hydride) batteries
3) Do not dispose of batteries in fire
4) Batteries should be recycled or disposed of as per state and local guidelines
www.mrbeams.com
UltraBright Spotlight
®
Tips:
®
•
•
•
•
•
2. Separate two parts by squeezing
tabs and pulling apart.
7. To pivot spotlight up and down, loosen
knuckle screw in the joint of the Spotlight
stem and adjust Spotlight head to desired
direction. Tighten knuckle screw.
Use only new alkaline D-Cell batteries with 1.5V rating.
Do not mix old and new batteries. If batteries are not new, it may cause the light to malfunction.
Install batteries with polarity in correct position.
Light may activate when batteries are inserted. Simply take light into a dark room, allow
batteries to settle up to ten minutes, then test activation.
If your light will not turn off, it means that it is time to replace the batteries.
LED Lights
Motion &
Light Sensor
Knuckle Screw
Mounting Base
Thumb Screw
3. Insert 4 D-Cell batteries into
spotlight. Attach holder by aligning
the grooves on the side and match
white arrows, snapping both tabs in
the holder.

Setting up Lights to a Network

After inserting the batteries, choose a group or channel
for your spotlights with the dipswitches next to the battery
compartment. Ensure all units are on the same channel by
matching the dipswitch positions.
* Spotlights set to the same group will activate together when they
are within 150 ft of each other.
Tips:
1. You may need to rotate the battery compartment to reveal the dipswitches.
2. Use a pencil or a small screwdriver to adjust the switch positions.
4. Remove mounting base by turning thumb
screw counterclockwise. Pull mounting base
off stem of light.
5. Drive three screws into three holes to
mount the mounting base. For drywall, drill
pilot holes first and insert anchors.
600 Beta Drive, Mayfield Village, Unit 100, Mayfield, OH 44143
Mounting Base
877.298.9082
