Parts Diagram - Dremel WORKSTATION 220 Owner's Manual

DM 2610921728 12-05E
1
2
Ref. Part No.
1 2610921769
2 2610929316
3 2610928604
4 2610930418
5 2610928594
6 2610933097
7 2610928605
8 2610928596
9 2610928607
10 2610921755
11 2610921738
12 2610921768
13 2610921767
14 2610921766
15 2610933108
16 2610928717
17 2610928598
18 2610933939
19 2610933107
20 2610928597
21 2610921716
22 2610923737
23 2610929317
24 2610921756
12/4/07 11:08 AM

Parts Diagram

3
6 7
4
5
6
16
6
6
8
15
6
9
10
11
Description
Screw (6)
Outer Shell-Left
Housing Cover
Pinion
Torsion Spring
Small Set Screw (6)
Main Housing
Rack
Tool Holder
Washer
Hex Bolt
Hex Nut
Washer
Depth Rod
Knob
Stop piece
Depth Gauge
Screw
Washer
Handle Assembly
Angle Lock Knob
Square Nut
Outer Shell Right
Screw
Page 10
28
27
26
32
25
39
24
25
22
6
23
20
17
19
18
14
13
12
38
Ref. Part No.
25 2610921980
26 2610921749
27 2610921722
28 2610917207
29 2615297527
30 2615297529
31 2610923471
32 2610921746
33 2610921747
34 2610921719
35 2610921736
36 2610921732
37 2610921731
38 2610921710
39 2610921745
10 10 10
29
30
31
33
34
21
35
36
37
Description
Washer (2)
Wing Knob
Crow's Nest
Wrench
Grommet
Hanger
Cord Holder
Pin
Square Nut
Height Adjustment
Assembly
Extension Tube
Assembly
Hex Bolt
Square Nut
Base Assembly
Shaft Support
