20:1 Coffee/Tea Brewer Operation and Service Manual
Model
Height
20:1-LD
17.8
20:1-AP
19.3
20:1-TD
24.2
20:1-LP3
17.3
Model 20:1-AP
Airpot not Included
Width
Depth
8.5
19.8
8.5
19.8
8.5
19.8
15.5
18.4
1
Man PN 121751 Rev 20170617
US
Canada
120 V
120 V
1750W
1400W
14.6A
11.7A
1750W
1400W
14.6A
11.7A
1750W
1400W
14.6A
11.7A
1700W
1400W
14.2A
11.7A
240 V
3500W
14.6A
3500W
14.6A
3500W
14.6A
3800W
17.1
Advertisement
Related Manuals for Newco 20:1-LD
Summary of Contents for Newco 20:1-LD
- Page 1 Man PN 121751 Rev 20170617 20:1 Coffee/Tea Brewer Operation and Service Manual Model 20:1-AP Airpot not Included Model Height Width Depth Canada 240 V 120 V 120 V 20:1-LD 17.8 19.8 1750W 1400W 3500W 14.6A 11.7A 14.6A 20:1-AP 19.3 19.8...
- Page 2 Man PN 121751 Rev 20170617 20:1 INSTALLATION / SETUP INSTRUCTIONS WARNING: - Read and follow installation / setup instructions before plugging or wiring in machine to electrical circuit. Warranty will be void if machine is connected to any voltage other than that specified on the name plate. Plumber's Installation Instructions 1) Plumb brewer in to water supply using 1/4 inch copper tubing.
- Page 3 Man PN 121751 Rev 20170617 Service Mode is entered by holding any two of the buttons on the face of the machine while powering up the brewer. The brewer firmware revision number is displayed for a couple of seconds when entering this mode. The table below list the items that may be programmed along with available values or settings.
- Page 4 Man PN 121751 Rev 20170617 Service Data consist of the tank temperature as measured at two points in the tank and an indication as to which probe(s) are making contact with the water. To view data, enter the service mode as noted above and advance to the “Srv”...
- Page 5 Man PN 121751 Rev 20170617 OPERATION INSTRUCTIONS Coffee/Tea Preparation Procedures Place filter into brew basket. Put the proper amount of coffee or tea into the filter. Filter not required for filter pack coffee/tea. Slide the brew basket into holder. Place the appropriate empty decanter into position below the brew basket. For airpots first open lid and remove pump stem unless of a brew through design.
- Page 6 Man PN 121751 Rev 20170617 Replacement Parts: Electrical Components 121753 Board, main control 100731 Display board, red LED 121478 Display board, blue LED 105115 Transformer,120V primary, 24 VCT 40VA 119804 Pump assembly, gear water 109937 Pump only, gear water 121756 Valve assy, double solenoid 100255 Valve assy, solenoid...
- Page 7 Man PN 121751 Rev 20170617 Wiring Diagram...
-
Page 8: Warranty
AT NEWCO’S SOLE OPTION AS SPECIFIED HEREIN, TO REPAIR, REPLACEMENT OR REFUND. In no event shall Newco be liable for any other damage or loss, including, but not limited to, lost profits, lost sales, loss of use of equipment, claims of Buyer’s customers, cost of capital, cost of down time, cost of...
