Description of the product

4.1

4.2

Fig.4

MW-1001241-1

7701562 - v02 - 22052018

The outdoor unit produces heat or cold and transfers it to the indoor

module via the refrigerant in the plate exchanger.

The indoor module is equipped with a specific control system which is

used to adjust the temperature of the heating water to the needs of the

home.

1 Automatic air vent

2 Control panel

3 Location of the data plate

4 Description of the product

iHPI
