Summary of Contents for Extech Instruments 40180
- Page 1 User's Guide Tone Generator and Amplifier Probe Model 40180 contact: www.ponpe.com sale@ponpe.com...
- Page 2 Introduction Congratulations on your purchase of Extech’s Model 40180. This tone generator and amplifier probe set is used to quickly trace and identify cables or wires within a group and also check the operation of phone lines. With proper use and care, this meter will provide many years of reliable service.
-
Page 3: Operating Instructions
Connect the red test lead to the RING side and the black test lead to the TIP side. The LED will indicate line condition by: GREEN = CLEAR , OFF = BUSY, Flickering YELLOW = RINGING Switch the tone generator power switch to CONT to terminate the call. 40180-EU-EN-V2.4-4/12 contact: www.ponpe.com sale@ponpe.com... -
Page 4: Battery Replacement
Generator: 63.5 x 63.5 x 38.1mm (2.5 x 2.5 x 1.5”) Weight 272g (0.6lb) Copyright © 2012 Extech Instruments Corporation (a FLIR company) All rights reserved including the right of reproduction in whole or in part in any form. www.extech.com 40180-EU-EN-V2.4-4/12...
