OWNER'S MANUAL

Instructions for

JUGS Pro-Sports

™

Digital Radar

Part No. R2000

SAVE THIS MANUAL

Table of Contents

Need help?

Do you have a question about the Pro-Sports R2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for JUGS Pro-Sports R2000

Page 1 OWNER’S MANUAL Instructions for JUGS Pro-Sports ™ Digital Radar Part No. R2000 SAVE THIS MANUAL...
Page 2 (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by JUGS SPORTS could void the user’s authority to operate the JUGS PRO-SPORTS RADAR. Not intended for Law Enforcement use.
Page 3: Table Of Contents
Table of Contents Introduction ......... . 2 Package Contents .
Page 4: Introduction
(about 1/200th of a watt) and is completely safe for close and continuous operation. The JUGS PRO-SPORTS radar is a true digital system. The JUGS PRO- SPORTS radar converts the reflected microwave signals into a digital stream of data.
Page 5: Package Contents
Package Contents The components included with your JUGS Pro-Sports radar are listed below. If you are missing any parts, or if you would like to upgrade your package, contact JUGS Sports at 1-800-547-6843. JUGS Pro-Sports Radar K-Band Radar Gun R2000...
Page 6: Quick-Start Instructions
Quick-Start Instructions For first-time usage or to charge the batteries, remove the clip at the end of the handle and insert the six, NiMH batteries into the chamber. Connect the 9-pin port end of the wall charger to the gun and plug into AC power for 12 hours. With a fully charged set of batteries inserted in the gun, simply do the following: 1.
Page 7: Operator Menu
Operator Menu MENU BUTTON The Menu button is used to change the Range setting, turn the Roll-down feature on or off, or to toggle the unit of measure from MPH to KPH. The Range Setting Press the menu button and you will enter the range setting. Changing the range has to do with increasing or decreasing the gun’s sensitivity.
Page 8 TRIG Press the select button to toggle between PEAK On and Off. Unit of Measure The JUGS Sports Radar is equipped with both the English (MPH) and metric (KPH) ROLL units of measure. When you pull the trigger, AUTO TRIG...
Page 9 RECALL BUTTON The JUGS Pro-Sports radar allows you to recall the last five speed-readings that were measured, by pressing the RECALL button. Speeds are added to the recall queue when a new speed is acquired. The stored peak and roll-down speeds in...
Page 10: Target Types
Target Types Ball Sports When you press the ON/OFF button, your BALL JUGS Pro-Sports radar default settings ROLL are for ball sports as indicated in the box AUTO TRIG to the right. PEAK BALL = Ball Sports TRIG = Trigger Mode PEAK = Maximum speed Most activities will be able to utilize this target type.
Page 11 Tennis The JUGS Pro-Sports Radar includes a special setting for tennis. The parameters for this target type are unique to tennis and, therefore, should be utilized for optimum performance. To set the target type for tennis, do the following: •...
Page 12: Radar Gun Placement
Radar Gun Placement The most common mistake made with all radar guns is trying to clock targets at angles. All radar guns work on the Doppler principle and need to clock objects moving directly at or away from the gun. Clocking at an angle with a stationary radar gun results in angle error, and the gun displays a speed that is LOWER than the actual speed.
Page 13 JUGS Pro-Sports Radar WARNING Do not attempt to catch a thrown or struck ball and clock with the JUGS Pro-Sports radar simultaneously. This may result in personal injury or damage to your radar gun.
Page 14: Calculating Angle Errors
80 and divide by the cosine of 30 degrees (0.866) to get a true speed of 92 mph. NOTE: You can configure the JUGS Pro-Sports radar to automatically adjust for angle error by changing the Cosine Angle setting in the Option MENU. In the above example, if the Cosine Angle setting is 30, the gun will display 92 MPH, and no manual calculations are necessary.
Page 15: Controls And Indicators
Controls and Indicators BALL ROLL AUTO TRIG PEAK MENU RECALL SELECT MODE ON / OFF LCD Display Icons BALL – Upper left window displays target type (bALL/cARN), unit of measure (MPH/KPH) when operating, or Range (3, 2, 1) when in menu. ROLL –...
Page 16: 9-Pin Port Connector
Controls and Indicators Rear Panel Buttons MENU – This button enters the MENU mode to select a feature to be changed. SELECT – Once the MENU button has selected a feature, use the select button to change the setting for that feature. MODE –...
Page 17: Option Menu
Stopwatch Mode STOP 0 - 45 Cosine Angle ANGLE 12, 24, 48, 96, 192, 384 Serial Port Speed BAUD JUGS, A, bE, - Serial Port Format rOLL, PEA Format A Speed A SPD 2Ero, SPAC, nonE Leading Zero LEAD0 Cr, CrLF, u Cr, u CL...
Page 18 Option Menu Enter Option Menu Press the MENU button to enter the OPERATOR MENU. Press the MENU and MODE buttons simultaneously to enter the OPTION MENU. All 8’s will briefly flash in the message and main windows to indicate the change of menu.
Page 19 Resolution: Select onES to display speed in whole units, as 25 MPH, or tnth to display speed with tenths, as 25.4 MPH. Target Type: The target types available on the JUGS Pro-Sports radar are BALL for ball sports, CARN for Carnival, and TENN for Tennis.
Page 20 Serial Port Speed: 1200, 2400, 4800, 9600, 19200, or 38400. Serial Port Format: Jugs is the default. The “-“ (dash) is for no serial output, the A format is for Selected Target Speed, and the bE format is for multiple speeds.
Page 21: Stopwatch Feature
Stopwatch Feature The JUGS Pro-Sports radar may be used as a stopwatch. You will need to purchase the Optional Stopwatch Cable if you do not already own one. Operation Plug in the cable’s 9 pin port connector to the radar gun.
Page 22: Recommended Settings
Recommended Settings Settings for Ball Sports It is important that the gun is set correctly when measuring ball sports. Check these settings: Menu Target Type Ball Option Low Speed 30 MPH (50 KPH) Option Range 3 – maximum sensitivity Operator *Roll-down For first and last speeds.
Page 23: Power Information
Using alkaline batteries may damage the JUGS Pro-Sports radar and will void the warranty. External - To power the JUGS Pro-Sports radar continuously, you will need the optional 12V DC Cigar Cable and either the optional 1 amp AC/DC adapter or some other external 12VDC power source.
Page 24 The JUGS Pro-Sports radar draws the most current when it is transmitting, so the run time depends upon how often the gun is transmitting. The JUGS Pro- Sports radar also has a sleep mode to conserve battery life when it is not being operated.
Page 25: Interference Problems
Interference Problems The JUGS Pro-Sports radar transmits at a frequency of 24.125 GHz (24,125,000,000 Hz), using a K-Band Transmitter. The receiver is designed to read the Doppler frequency (the change in frequency) between 360 Hz and just over 43 kHz. There are very few devices other than another radar gun that could cause interference in a radar gun’s transmission frequency range.
Page 26: Radar Accessories
(often interference from nearby motors). Radar Accessories Optional accessories are available for the JUGS Pro-Sports radar to assist you with all your radar needs. • PS Radar Wall Charger ........R2001 (replacement) •...
Page 27: Service Information
• JUGS Display - 7” Numbers ....... .R2020 2.5 digit display with 7” numbers.
Page 28: Diagnostics
Diagnostics Version Check Enter the Diagnostic mode by pressing the 0.0.0 MENU and RECALL keys simultaneously. JU9S The first diagnostic screen shows the AUTO LOBATRIG version of code loaded into the gun. If PEAK no action is taken within two seconds, the version screen clears, and the gun reverts to radar mode.
Page 29: Warranty Information
Pull the trigger while in any diagnostic mode to exit all diagnostics and return to radar operation. Warranty Information The JUGS Pro-Sports radar is covered for Two (2) Full Years, Parts and Labor, against defects in workmanship, parts, or materials, and is guaranteed to operate within specifications for that period.
Page 30: Product Specifications
Power Output ....... 5 Milliwatts Nominal The JUGS Pro-Sports radar complies with Part 15 of the FCC rules.
Page 31: Serial Communications Protocol
Serial Communications Protocol An RS-232 or RS-485 Serial Cable is required for data communications to speed display boards, computers, and other electronic devices. The data connector is on the side of the unit. Serial Port Connector ....9-PIN D-CONN Mating Connector .
Page 32: Serial Port Message Format
Serial Port Message Format Serial Port Format: The A format reports a single speed (peak or roll-down), and the bE format reports both. A Format (Roll or Peak) – Resolution = ones Byte# Description Speed hundreds digit (ASCII) Speed tens digit (ASCII) Speed ones digit (ASCII) 4(+) Carriage Return (0x0D) or alternate termination string...
Page 33 The Leading Zero setting affects format A : • When set to SPAC (default setting), ASCII spaces are used for leading zeros: “500” “500.0” “ 50” “ 50.0” “ 5” “ 5.0” • When set to 2Ero, ASCII zeros are used for leading zeros: “500”...
Page 34 Operator Notes...
Page 35 Operator Notes...
Page 36 If you need more information about this product or any other JUGS product or service, please contact the manufacturer: In the USA and Canada, call toll-free: 1-800-547-6843. For International Orders, call collect: 0-503-692-1635. Our fax number is 1-503-691-1100. Visit our website at www.jugssports.com.
