SGS STC1000 Owner's Manual page 2

ASSEMBLY INSTRUCTIONS
1. REMOVE SIDE PANEL
Remove screws with a screwdriver.
3. CASTER ASSEMBLY
If caster assembly is loose, using a screwdriver slightly spread apart the split bearing
on the shaft. If caster is tight, crimp split bearing with pliers. Make only small adjust-
ments until caster fits.
WWW.SGS-ENGINEERING.COM
2. REMOVE CHEST
Place cabinet on a level surface. Slowly
remove chest from the cabinet.
PAGE 2
WARNING
1. Lubricate the top and the bottom channels of the drawer slides at least twice a year.
2. Do not open more than one loaded drawer at a time.
3. The maximum loading capacity is 70kgs (154 lbs).
DRAWER SLIDERS
If it becomes necessary to remove drawers:
1. Pull drawer all the way out, then push back a fraction of an inch.
2. Insert a screwdriver into slot in the slide and push in on the stop until it clears
the lance. Repeat the procedure on the other slide and remove drawer.
3. To re-install drawer, pry stop far enough out to engage lances (3/16" to 1/4")
and push drawer onto slide until stops engage lances.
PAGE 3
