Part : AB68-00509B(02)
Printed in China
220X POWER ZOOM WDR CAMERA
SCC-C4205(P)/C4305(P)
Owner's Instructions
Gebrauchsanleitung
Guide d'utilisation
Guía del usuario
Istruzioni per l'uso
✽ Be sure to read the "Safety Precautions" in this manual
to ensure correct use and operation of this product.
E
D
F
Es
I
Advertisement
Table of Contents
Related Manuals for Samsung SCC-C4305(P)
Summary of Contents for Samsung SCC-C4305(P)
- Page 1 Part : AB68-00509B(02) Printed in China 220X POWER ZOOM WDR CAMERA SCC-C4205(P)/C4305(P) Owner’s Instructions Gebrauchsanleitung Guide d’utilisation Guía del usuario Istruzioni per l’uso ✽ Be sure to read the "Safety Precautions" in this manual to ensure correct use and operation of this product.
-
Page 2: Important Safety Instructions
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings, Install in accordance with the manufacturer's instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers) that produce heat. - Page 3 4. Securely plug the power cord into the power receptacle. (A loose connection may result in fire.) 5. When mounting the camera on a wall or ceiling, fasten it safely and securely. (A falling camera may cause personal injury.) 6. Do not place conductive objects (e.g., screwdrivers, coins, and metal things) or containers filled with water on top of the camera.
-
Page 4: Table Of Contents
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of... -
Page 5: Overview
Overview This is a state-of-art WDR zoom camera which employed the x22 zoom lens and digital zoom IC to monitor up to 22 times as large as an original image. SCC-C4205(P)/C4305(P) has the following functions. WDR for distinct photographing of both bright and dark parts of an image. - Page 6 ✔ In Setup Menu Mode - UP/ DOWN buttons: Use to move the cursor up or down. - LEFT/ RIGHT buttons: Use to move the cursor left or right, or to sequentially view the values that can be assigned to a parameter. - ENTER button: Use to select a Sub Menu item, and to accept the current value.
-
Page 7: Installation
Installation Before Installation Checking the Package Contents Make sure that the following accessories are included in the package. SCC-C4205(P)/4305(P) User's Guide Mount Adapter Screw (2) Terminal Block Preparing the Cables To install and use the camera, first prepare the following cables. -
Page 8: Connecting The Cables
6. The requirements for RS485 control is as follows : Signaling Speed: 9600 bps Data Bit : 8 bits Stop Bit : 1 bit Parity Bit : none POWER DC12V 600mA PROTOCOL SAMSUNG ADDRESS TYPE RS-485, HALF BAUD RATE 9600 LENS EEP VER... -
Page 9: Navigating The Setup Menu
Navigating the Setup Menu In this chapter, we will take a look at the menu system of the SCC-C4205(P),C4305(P). First, we will take a look at the structure of the Setup Menu and then describe the functions of each menu item in the menu. Structure of the Setup Menu Structure of the Setup Menu of the SCC-C4205(P) CAMERA ID... -
Page 10: Camera Id
❙ CAMERA ID In the CAMERA ID menu, you may designate the CAMERA ID to be displayed in the monitor connected to a camera. Set the CAMERA ID menu to ON... and press [ENTER] and the CAMERA ID setup submenu will appear. The CAMERA ID may be created by up to 20 digits by using alphabets, numbers, and some special texts served by the submenu screen. -
Page 11: Shutter
❙ SHUTTER In the SHUTTER menu, you may determine the fast electronic shutter speed or slow AUTO shutter speed. The fast electronic shutter supports 7 speeds from 1/100(1/120) sec. to 1/10K sec. to photograph a bright and quick moving image. The slow AUTO shutter supports about 10 speed from x2 to x160 to make an image projected to the screen more distinct and brighter by selecting the slow shutter speed. -
Page 12: White Bal
❙ WHITE BAL You can select one of four modes for white balance adjustment as follows: - ATW1/ATW2(Auto-Tracing White Balance Mode): In these modes, the color temperature is monitored continuously and thereby white balance is set automatically. The following are the approximate supported color temperature ranges in these modes. -
Page 13: Color / Bw
CAMERA ID (MOTION DET) IRIS ALC... SHUTTER WHITE BAL ATW1 Press the FOCUS MODE MOTION DET ON... ENTER COLOR/BW COLOR button. PRIVACY SPECIAL AREA PRESET SENSITIVITY EXIT QUIT If you select ON and press the ENTER button, the MOTION DET screen will come up. -
Page 14: Privacy
✔ AUTO... Depending on illumination, it is automatically switched to the COLOR or BW mode. In the poor illumination environment, turns IR Filter off to convert to the Black-and- White mode for better sensitivity and in the good illumination environment, turns it on to convert to the COLOR mode for worse sensitivity. -
Page 15: Special
PRIVACY NO. 0 POSITION SET ON... SIZE … Press the LOCATION … ENTER button. EXIT QUIT You shall set up the position of ZOOM/FOCUS in the PRIVACY ZONE area from the POSITION SET menu. Press UP/DOWN/LEFT/RIGHT key to size the PRIVACY ZONE area from the SIZE menu. -
Page 16: Preset
❙ PRESET Select the PRESET menu and press [ENTER] and the PRESET MAP submenu screen will appear. (PRESET MAP) 0 H 1 SAMSUNG 9600 HOME RETURN OFF EXIT QUIT Select the PRESET number and press [ENTER] and the above screen will appear. -
Page 17: Exit
❙ EXIT The EXIT menu is used to terminate the CAMERA SETUP menu. ✔ QUIT : Select to ignore any changes you have made and restore the previously saved settings. ✔ SAVE : Select to save the settings that have been changed so far. - Page 18 SCC-C4205P/C4305P Item Description Product Type Zoom Lens Built-in WDR Color Camera(PAL TYPE) - SCC-C4205P : DC 12V±10% Power Supply - SCC-C4305P : DC 12V±10% Voltage AC 24V±10% (50Hz±0.3Hz) - SCC-C4205P : 5.7W Power Consumption - SCC-C4305P : 6W Broadcast System - PAL Standard Color System Imaging Device - 1/4 inch WDR compatible Exview HAD CCD...
