JAGER PRO M.I.N.E Operator's Manual

Hide thumbs Also See for M.I.N.E:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M.I.N.E and is the answer not in the manual?

Questions and answers

Related Manuals for JAGER PRO M.I.N.E

Summary of Contents for JAGER PRO M.I.N.E

  • Page 2 In no event will JAGER PRO™, LLC be liable to you, or any third party, for any damages in excess of the purchase price of the product. In addition, JAGER PRO™,LLC...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Camera Characteristics..........04 Quick Start Programming..........07 Main Menu Tabs............08 Camera Tab..............08 Trigger Tab..............10 System Tab..............11 Wireless Tab..............12 Test Manually Sending Photos........14 Registering Your Verizon Camera......... 14 Application Download............14 LOGIN Fail Corrective Action........15 Timing Camera Transmitter to Control Box Receiver..

  • Page 4: Camera Characteristics

    CAMERA CHARACTERISTICS This manual is intended to guide users through the individual steps to properly program, operate and maintain the AT&T version of our JAGER PRO™ M.I.N.E™ and I.C.E.™ Cameras on the data plan. Front View 1. Antenna: Standard antenna shown receives cell tower signals. Our 5 decibel booster antenna is available as an accessory for operation in low signal areas.
  • Page 5 Bottom Outside View 1. USB Port Plug: Waterproof seal to protect internal components when USB cable is not in use. 2. Mounting Port: 1/4 x 20 internal threads for securing camera to a T-Post mount. Only thread external devices two complete rotations into the camera mounting port then tighten using the mount’s adjusting nut.
  • Page 6 Inside View 1. Antenna Port: Attachment point to install various antennas depending on local cellular strength. Our 5 db booster antenna is available as an accessory for operation in low signal areas. 2. Display: A 2” screen to view menus, photos and settings. 3.

  • Page 7: Quick Start Programming

    QUICK START PROGRAMMING Begin programming the M.I.N.E™ Camera for operation by removing the red or yellow shipping plug and replacing the antenna seal if it came off with the shipping plug. Damage resulting from not having the antenna seal present is not covered under warranty.

  • Page 8: Main Menu Tabs

    cable is inserted into the camera battery port. The camera supports up to a 32 GB SD card. Insert an activated SIM card into SIM card port with the notch located in the top-right corner. Ensure SD card is not locked and insert it into the SD card port.
  • Page 9 • Photo Size: Choose the image size; 3MP, 5MP, or 8MP. • Video Size: Choose the video size; 720p, WVGA, QVGA, 1080p. • Photo Burst: Choose the number of pictures taken consecutively after each triggering. (Recommend 1 Photo), selecting 2 or 3 will take two or three photos but only send the last photo of the group taken.

  • Page 10: Trigger Tab

    Trigger Tab: • Sensitivity- Passive Infrared (PIR) Trigger Sensitivity High: The most sensitive setting and will trigger camera operation when any movement is detected. Low: The least sensitive setting used when foliage, wind or shadows trigger excessive photos. Normal: Average sensitivity. (Recommended) •...

  • Page 11: System Tab

    programmed. Could be used to avoid high traffic from non-target species during specified times. Since there are two Start- Stop times available, ensure the programmed times do not overlap. System Tab: • Set Clock: Enter correct Date and Time. Add in UTZ for proper updates NOTE: The camera will automatically update to your time zone once it is set up on our wireless website.

  • Page 12: Wireless Tab

    • Default: Restores camera back to factory settings. • Information: Displays model, hardware version, firmware version of camera and the IMEI number. Check our website for the latest firmware version and uploading instructions. • Password: The default password is 000000. Choose OFF to stop this function and ON to set a six digit password.
  • Page 13 The Max Num field indicates the maximum number of photos or texts allowed to be sent within 24 hours. Pressing the right arrow will open the keypad to make changes. Select SAVE to return to Max Num and OK to return to Instant.

  • Page 14: Test Manually Sending Photos

    • Premium Test: Once you input at least one recipient, this test will verify that it can contact the server and send a test email to each of your configured recipients. This only applies to email address’, not phone numbers. MANUALLY SENDING PHOTO Our AT&T camera is designed to test program settings and IMEI service by manually sending a photo.

  • Page 15: Login Fail Corrective Action

    Give your camera an Admin Access Code and a Guest Access Code, you will need these to authenticate your camera with your mobile app. For Android, visit your google play store and search for JAGER PRO™ Wireless. For Apple, visit your App Store and search for JAGER PRO™ Wireless.

  • Page 16: Timing Camera Transmitter To Control Box Receiver

    TRANSMITTER. The M.I.N.E.™ Camera has an internal transmitter on the circuit board and must be located within 50 meters of the M.I.N.E.™ Gate to operate correctly. Users must manually calibrate the camera transmitter signal to each control box receiver the first time they are paired together. One camera will operate multiple control box receivers to trigger multiple gates simultaneously at a trap enclosure.

  • Page 17: Camera Deployment

    T post with zip ties. Standing on a step ladder, align the M.I.N.E.™ Cam by loosening the ball head set screw and centering the camera’s view to the ground beneath the feeder legs.
  • Page 18 Fahrenheit. The battery symbol is “P5” which indicates the batteries are fully charged. The final step is to register your new equipment on the JAGER PRO™ website via the camera MEID number so we may provide appropriate firmware updates. These updates are necessary to ensure your equipment operates efficiently as network wireless technology changes.

  • Page 19: Care And Maintenance

    Firmware updates can be done on our JAGER PRO™ wireless website and will automatically download to your camera. Updating firmware on the M.I.N.E.™ Series cameras takes just a few seconds, and is well worth the effort to ensure your camera is performing at the highest level possible.
  • Page 20 Use only the recommended power sources. Any use of non- JAGER PRO™ power sources will void the warranty on your camera. • Do not mix battery types. We recommend Energizer Ultimate Lithium batteries for your camera.
  • Page 21 Exterior: 1. Inspect the outside of the camera body for any cracks which may cause water or moisture to damage electronics. 2. Check for condensation in the IR LED bank. 3. Ensure the antenna is not loose, bent, broken or cracked, and the antenna seal is present.

  • Page 22: Accessories

    CAMERA ACCESSORIES JAGER PRO™ offers several items for the M.I.N.E.™ Cam to increase the versatility and function of the camera. These items may be purchased from your local dealer or online at jagerpro.com. External 5 db Booster Antenna This antenna is designed for areas where cellular coverage is weak and enables users to expand the usable range of the M.I.N.E.™...

  • Page 23: Glossary

    GLOSSARY CDMA- Code Division Multiple Access is a competing cell phone service technology to GSM, which is the world’s most widely used cell phone standard. Sprint, Verizon, and Virgin Mobile use CDMA. GPRS- General Packet Radio Service was early technology to enable data communication on GSM networks.

  • Page 24: Command Code List

    COMMAND CODE LIST Ensure the REALTIME control is ON in order for the camera to receive commands. The M.I.N.E™ Cam is able to receive commands to perform these 11 different functions remotely. All recipients have the ability to send and receive commands to control the camera.
  • Page 25 JAGER PRO™ offers a complete line of Hog Control Products, Services and Education View our instructional video series online at: Like us on Facebook www.facebook.com/JAGERPROHCS 2900 Smith Road Fortson, GA 31808 Phone: 706-718-9789 Email: info@jagerpro.com Website: jagerpro.com...

This manual is also suitable for:

I.c.e
