CONTOUR® Curved Cutter Stapler
Optimized Device Performance Guide
Retaining pin
Cartridge anvil
Proper reload selection
Tissue thickness should be carefully evaluated
prior to using the instrument. Refer to the
Instructions for Use for proper reload selection.
Cartridge module
Push rod
Curved head
Device
code
CS40B
CS40G
Reload
code
CR40B
CR40G
Retaining pin actuator
Firing
trigger
Staple
Tissue
rows
Regular
4
■
Thick
4
■
Closed
Tissue
staple height
Regular
1.5mm
■
Thick
2.0mm
■
Release button
Closure
trigger
Handle
Cut line
Staple
length
line length
40mm
51mm
40mm
51mm
Open
Wire
staple height
diameter
3.5mm
0.20mm
4.7mm
0.23mm
Max
firings
Qty/box
6
3
6
3
Qty/box
6
6
Advertisement
Related Manuals for Ethicon CONTOUR CS40B
Summary of Contents for Ethicon CONTOUR CS40B
- Page 1 CONTOUR® Curved Cutter Stapler Optimized Device Performance Guide Retaining pin Cartridge module Push rod Retaining pin actuator Release button Cartridge anvil Curved head Firing Closure trigger trigger Handle Proper reload selection Device Staple Cut line Staple code Tissue rows length line length firings Qty/box...
- Page 2 Device preparation and placement Remove the staple retainer from the instrument Position tissue to be cut and stapled between the anvil and the cartridge. If the tissue doesn’t fit comfortably by pushing on the pad labeled “Push to Remove.” within the jaws, you should consider two firings. Device is reloadable to complete a single transection with multiple firings when needed.
- Page 3 Device firing Completely fire the instrument by squeezing the firing trigger until it touches the closure trigger (plastic to plastic). CAUTION: To prevent bunching, stretching or overloading of tissue in the jaws of the device, multiple firings may be used to complete a single transection. If the closure trigger is diff...
- Page 4 Some situations may require multiple firings to complete a single transection. For complete product information, including full steps for use, indications, contraindications, warnings and precautions, please see Instructions for Use. ©2018 Ethicon US, LLC. All Rights Reserved. 029399-180607...
