Colour Television
Contents
Wiring Diagram 32"
A01 715G4545 PSU 32"
Adapter
Inverter
Power
Inverter
POWER-1
POWER-2
CI CARD/MT5135
MT5395 BYPASS/TRAP.
MT5395 PERI/USB2.0
DDR3 MEMORY
GPIO
FLASH/JTAG/UART/IR/RS232
SCART1/Monitor OUT
YPBPR/VGA IN/SPDIF OUT
HDMI1/HDMI2/HDMI3 INPUT
©
