Summary of Contents for Samsung YH-J70
-
Page 2: Features
The built-in rechargeable lithium battery provides up to 25 hours of music and 7 hours of video files. (According to company measurement) Playback Speed Control Function You can adjust the playback speed of music or voice files. Upgradable You can upgrade the built-in programs when available. Please check the home page (www.samsung.com) for upgrades. Features... -
Page 3: Table Of Contents
...64 Connecting an External Device System Settings ...83 Transferring Files from External Device ...83 Languages ...65 to the Player File Language ...66 YH-J70 USB HOST Compatible ...84 Play Speed ...84 Resume ...67 Clear Screen PC Connect Mode ...68 Othello Motion Sensor ...69... -
Page 4: Safety Instructions
Safety Instructions Please read and understand all the instructions to avoid injury to yourself and damage to the device Do not expose to extreme temperatures (above 95°F or below 23°F). Do not expose to moisture. Do not let any foreign matter spill into the device. -
Page 5: Battery Charger Safety
Battery Charger Safety CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN The uninsulated parts inside the charger could cause electric shock. For your safety, do not open the case of the charger. Read this User Manual to prevent any problems that may occur while using the charger. -
Page 6: Components
Earphones Line-In Cable USB Host Adaptor User Manual Charger Model YH-J70 SB/SW YH-J70 LB/LW Built-in memory 20GB 30GB The capacity of the useable built-in memory is less than indicated as the internal firmware uses a part of the memory as well. -
Page 7: Display
Location of Controls Docking Cradle Front USB Cable Connection Port You can listen to music by putting the player on the cradle and connecting earphones or speakers via LINE OUT jack. Rear EQ/SRS Indicator Volume Indicator LINE OUT jack Play/Pause Indicator Play Time Indicator - The screen pictures are for illustration purposes only. -
Page 8: Connecting The Player To Your Pc
Connecting the player to your PC System Requirements. Install Samsung Media Studio prior before connecting The PC system must meet the the player to PC. following specifications: Pentium 200MHz or greater Installing Software Windows XP 50MB of available hard disk Insert the Installation CD into CD-ROM drive. -
Page 9: Connecting The Player To Your Pc With A Usb Cable
You may not see the display screen during installation. Go to the device manager to check that installation has been successfully completed. Upon installation of the USB driver "Samsung YH-J70 USB Device" will appear in the [Device Manager]. -
Page 10: Manual Installation Of The Usb Driver
Manual Installation of the USB Driver Follow these steps if the USB driver is not installed : If an error occurs during installation of the USB driver Check the device manager. Windows XP : Control Panel System Hardware Device Manager Check if there is a device listed with an exclamation point or a question mark (displayed as unknown device or USB... -
Page 11: Using The Player As A Removable Disk
Using the Player as a Removable Disk You need to select PC connection mode before using the removable disk. Press the MENU buton and select [Settings] [PC Connect Mode] from the menu. Downloading Files Connect the player to PC. Right click on the Start button, then choose Explore to Open Windows Explorer on PC. -
Page 12: Using Media Studio
Using Media Studio Media Studio is the program that enables you to download music files to the player, and play back music files on your PC. Click Media Studio icon from the Desktop. Downloading Music Files Connect the player to PC. A device connection window will appear on the right side of the screen. -
Page 13: Sending Playlist
Using Media Studio Sending Playlist Connect the player to PC. Press the [File] [Add Playlist] at the top of the screen. Enter the name of Playlist folder when input screen appears. Select the folder with the file(s) you want to transfer from the [Library] window. The music files within the folder appear on the center of the screen. -
Page 14: Formattimg The Player
Using Media Studio Formattimg the Player Connect the player to PC. Press the [Device] [Format] at the top of the screen. Press the [Start] button when the Format screen appears. The memory of the player is formatted and all the saved files will be deleted. - Refer to [Help] for more detailed information. -
Page 15: Creating A Folder
Using Media Studio Creating a Folder Connect the player to PC. Press the [Create Folder] button at the bottom of device connection window. Enter the name of the new folder when an input screen appears. A new folder is created. If you open a new folder and transfer a file, the file is transferred to the newly created folder. -
Page 16: To View Help On Media Studio
Using Media Studio To View Help on Media Studio Press F1 after starting Media Studio. Help window will appear. Click on [Help] at the top of the screen. Click on [Help] and the Help window will appear. - Music recognition technology and related data are provided by Gracenote and Gracenote CDDB®... -
Page 17: Using Multimedia Studio
Installing Multimedia Studio Follow the instructions in the window to complete the installation. Using Multimedia Studio Run Multimedia Studio from on the Desktop. Editing Images Select the folder containing images to edit from the directory window at the upper left-hand section of Multimedia Studio. The saved files will be displayed in the file list window on the right. -
Page 18: Sending Images
Using Multimedia Studio Select PC connection mode before transferring image files or video files through Multimedia Studio. Press the MENU buton and select [Settings] [Removable Disk] from the menu. Sending images Connect the player to PC. Select the image(s) to send to the player. Select [File] [Export images to device] at the top of Multimedia Studio. -
Page 19: Sending Videos
Using Multimedia Studio Select PC connection mode before transferring image files or video files through Multimedia Press the MENU buton and select [Settings] Studio. [Removable Disk] from the menu. Sending Videos Connect the player to PC. Select the video(s) to send to the player. Select [File] [Export videos to device] at the top of Multimedia Studio. -
Page 20: Capturing Video
Using Multimedia Studio Capturing Video Press the [Capture] button at the top of the Multimedia Studio menu. The Media Player screen will be displayed. Click [Menu] [Open] on your PC and select the video to play. The selected video will be played. Using Multimedia Studio Press the [Capture] button and then press the... -
Page 21: To View Help On Multimedia Studio
Using Multimedia Studio Select the directory to save to from the [Save As] window and press the [Save] button. The selected image will be saved. - Video playback and conversion codecs are not provided. It is recommended that you use codecs of latest versions. -
Page 22: Playing Music
Playing Music Make sure the player is fully charged and the earphones are connected. Power On: Press and hold the √» button to turn on the power. Power Off: Press and hold the √» button to turn off the power. Playing Music Press and hold the √»... -
Page 23: Searching For Music/Voice Files
Searching for Music/Voice Files To Search for Specific Parts During Play Press and hold the button during playback to search for the part you want to listen to. Release the button to resume play normally. To Change Tracks During Play Press the button briefly during playback to play the next track. -
Page 24: Eq Srs
Setting Main Functions in Music Mode Press the TOOL button in music mode. Music Tool screen appears. Press the SELECT button after moving to [SRS]. Press the SELECT button after moving to the desired SRS mode. Normal TruBass SRS: You will hear 3D Streo sound. TruBass: This is bass boost feature that adds fillness to the sound. -
Page 25: Menu Options
MENU Options Press the MENU button to switch to Menu mode. Use the SELECT button to select the menu item you want, and then briefly press the SELECT button. Music FM Radio Navigation Photo/Video USB Host Games Now playing : To display the song currently playing. FM Radio : To listen to FM radio. -
Page 26: Setting Main Functions In Fm Mode
Setting Main Functions in FM Mode You can move and select using the SELECT button Press the button to move to the previous screen. Mono / Stereo Press the TOOL button in FM Mode. FM Tool Screen appears. Press the SELECT button after moving to [Mono/Stereo]. -
Page 27: Recording Voice
Recording Voice Press and hold the REC button. Recording screen appears. Press the REC button to start voice recording. Press the REC button again. Recording stops and the file is created. Files are recorded and renamed V001.mp3, V002.mp3, and so on. MP3 files are added to [Navigation] [File Search] Press the √»... -
Page 28: Recording Mp3S
Recording MP3s Connect the Audio Output port on the external audio source (or the Line Out port) to the LINE IN port on the device with the Line cable. Press the play button on the external device to play the music to record. Press and hold the REC button. -
Page 29: Go To Top
Setting Main Functions in Navigation You can move and select using the SELECT button. Press the button to display the previous screen. Go to Top Press the TOOL button in Navigation Mode. Navigation Tool screen appears. Press the SELECT button after moving to [Go to Top]. Move to the File Navigation screen. -
Page 30: Viewing Text
Viewing Text Text Viewer allows you to read text files that were created on your PC. Text files must have a .txt extension to be viewed by Text Viewer. You can select an text file to view while listening to the music. Press the MENU button to move to menu, and then select Text. -
Page 31: Go To Page
Setting Main Functions in Text Go to page Press the TOOL button while viewing text. Text Tool screen appears. Press the SELECT button after moving to [Go to page]. Press the SELECT button after selecting the desired page. Move to the selected page. SELECT: Select page. -
Page 32: Viewing Image Files
Viewing Image Files Press the MENU button to move to menu, and then select Photo/Video. Photo/Video screen appears. Press the SELECT button after selecting [Photo] folder. Move to the image you want to view, and then press the MENU button. The selected image file will be displayed. -
Page 33: Using Usb Host
01-Don’t Know Why. Select all 01-Politik.mp3 01-Politik.mp3 Copy 01-Solsbury Hill.mp3 01-Solsbury Hill.mp3 Iltans Of Swing.mp3 Iltans Of Swing.mp3 Paste 02-Come with Me.mp 02-Come with Me.mp USB disconnect 02-Hollywood.mp3 02-Hollywood.mp3 button to move to [YH-J70], and then press the SELECT button. Continued... -
Page 34: Yh-J70 Usb Host Compatible
YH-J70 USB HOST Compatible You can transfer images from the cameras listed below to your YH-J70 for storage. The following is a list of cameras that are compatible with YH-J70 USB Host function. This list may change with firmware upgrade. -
Page 35: Playing Games
Playing Games Othello Press the [START] to start game START HELP EXIT [Game Method] - When you place your stones in horizontal, vertical or diagonal direction, the stones inside become yours. The side with the most stones after the game wins. ,SELECT: Move Up, Down and Select : Move Left and Right TOOL: Restart, Exit... -
Page 36: Tetris
Playing Games Tetris Press the [START] to start game START HELP EXIT Select level using the SELECT button when level screen appears. LINES : SCORE : [Game Method] - The objective of the game is to eliminate rows by stacking various shaped blocks. - SELECT : Change block shapes : Move Left and Right : Pull down... -
Page 37: Setting The Advanced Functions
Setting the Advanced Functions Press the MENU button to move to menu, and then select Settings. Settings In Settings, move to the function you want and press the SELECT button to select. Press the button to move to the previous menu. Settings Settings Settings... -
Page 38: Lcd Off Time
Screen Display Settings Lcd Off Time Use the SELECT button to set the LCD off Time. LCD Off time can be set to 10 seconds, 20 seconds, 30 seconds or Always On. When set to Always On, the Light stays on continuously. The screen switches off after the set time. -
Page 39: Auto Eq
Sound Effect Settings Auto EQ User the SELECT button to select Automatic EQ On/Off. On : EQ is automatically selected from Jazz, Classic, Pop or Rock according to the music file's ID3 tag information. Off : Music file is played in the current EQ mode chosen. EQ MODE TAG INFO CLASSIC ROCK, CHRISTIAN ROCK, ROCK,... -
Page 40: Time/Schedule Settings
Time/Schedule Settings Press the MENU button to move to menu, and then select [Settings] Memo Select [New Memo] when memo screen appears. Enter desired contents. Input Procedure , and Move to a desired key by using buttons and press the SELECT button. Press the SELECT button twice to enter the second letter of the key. -
Page 41: Sleep
Time/Schedule Settings Sleep Use the button to set sleep time. Sleep time can be set to Off, 10~120 minutes. The player will automatically turn off after the time you set. When sleep time set to Off, the function is disabled. After setting is complete, move to OK and then press the SELECT button. -
Page 42: Recording Settings
Recording Settings Press the MENU button to move to menu, and then select [Settings] Bit Rate Use the SELECT button to select the desired recording bit rate. Recording bit rate can be set to 40kbps, 64kbps, 96kbps, 128kbps or 196kbps. Auto Sync Use the SELECT button to set the Auto Sync Time. -
Page 43: Play Speed
System Settings Play Speed Use the SELECT button to select the desired play speed. Play speed can be set to 0.8x, 1x, 1.2x, 1.4x or 1.6x. The larger the number, the faster the speed of play, and the smaller the number, the slower the speed of play. -
Page 44: Default Set
System Settings Default Set Use the SELECT button to select default set Yes or No. If you select [Yes], a popup window will be displayed. If you select [OK], all selected settings will be restored to the default setting. Default Set Volume = 40 Repeat = OFF Sound Effects Settings = OFF... -
Page 45: Troubleshooting
Troubleshooting "System Fail Need Firmware Upgrade” message appears: File search does not work properly in the Menu Navigation. After connecting the player to PC, run Media Studio, and then select [Device] [Reconstruct Library]. The player doesn't work. There is nothing showing on the display panel. Reset the Player. -
Page 46: Specifications
Specifications Model YH-J70 Internal Memory Capacity YH-J70 SB/SW(20GB) / YH-J70 LB/LW(30GB) Built-in Rechargeable Battery Capacity 950mAh Voltage 4.5V (Li-ion Rechargeable Battery) Dimensions/Weight 62 X 99.8 X 16.4mm/135g Case Plastic Signal to Noise Ratio 90dB with 20KHz LPF(based on 1KHz OdB)
