LCD Display
2
Locking Screw
3
mm/in Switch Button
4
Data Output Port
5
0/ABS Switch Button
6
Depth Measurement
Technical Specifications
• Resolution: 0.01mm /.0005"
• Power: Battery 3V, CR2032
• Measuring speed: Unlimited
• Working temperature: 0~+40℃
• Relative humidity: <80%
Specifications:
Range
Resolution
0~150mm / 0~6"
0.01mm
0~200mm / 0~8"
/.0005"
0~300mm / 0~12"
ABSOLUTE DIGITAL CALIPERS
7
Origin Button
8
ON/OFF Button
9
Step Measuring Faces
10
Outside Measuring Faces
11
Inside Measuring Faces
12
Main Scale
Battery installation: CR2032 Lithium
Accuracy +/-
0.02mm/.001"
0.03mm/0.0015"
0.03mm/0.0015"
ABSOLUTE DIGITAL CALIPERS
OPERATION MANUAL
SPI 30G04
IMPORTANT NOTICE
Avoid exerting excessive force
when measuring as it may cause
an incorrect reading and
deformation of the measuring
jaws.
swissprec.com
