Summary of Contents for Totally Wicked TORNADO EX
- Page 1 ELECTRONIC CIGARETTE KIT USER MANUAL...
- Page 2 CONGRATULATIONS ON PURCHASING YOUR TOTALLY WICKED TORNADO EX ELECTRONIC CIGARETTE KIT.
- Page 3 Power Button Tank Glass Tank Base Battery Mouthpiece Atomizer Head USB Port Tank Cap Airflow Adjuster...
- Page 4 Using Your Tornado EX Kit be gently pushed back on, ensuring Priming the Atomizer Head: the airflow adjuster has not lifted Ensure the tank remains attached and is properly seated. Prime the to the battery. Hold the tank base fitted atomizer head by dripping a...
- Page 6 Atomizer Head Lifespan: Filling the Tank Atomizer heads do not last forever Hold the tank top, and remove the and need to be replaced periodically. mouthpiece by unscrewing it. Fill Time in use before replacement the tank with E-liquid using one is required is generally from a few of the dedicated fill holes located days to several weeks, depending...
- Page 7 Filling the Tank...
- Page 8 Switching On and Off: depleted. Direct output produces To switch the Tornado EX on, quickly press the power button five times; more heat, power and vapour for a more satisfying vape experience, but...
- Page 9 mode. Switching the battery back on Adjusting Airflow: activates the selected mode. If you find air flow too airy or too tight, rotate the airflow adjuster Vaping: to expose fewer or more holes. Press and hold the power button as Experiment to find your preference.
- Page 10 The indicator light will never drops below the 4 fluid feed illuminate red while charging. Once holes around the bottom of the fully charged, the indicator light will atomizer head. switch off. The Tornado EX can be used normally while charging.
- Page 11 Battery Life Battery Life Indication: The indicator light will relight 2 seconds after vaping, and for the following 4 seconds will show the battery life remaining. Illumination will remain constant if the battery has full charge, and as the level of charge decreases the indicator light will flash faster.
- Page 12 Replacing the Atomizer Head airflow adjuster fully open (clockwise Important: The Tornado EX atomizer viewed from above), and holding the head cannot be changed without first emptying the Tank. adjuster down towards the battery, unscrew the atomizer head from the tank base.
- Page 14 Priming the Atomizer Head above. Atomizer head choice: Rotate the airflow adjuster to the The Tornado EX is fitted as standard fully closed position (anticlockwise with an EX 1.2 ohm Atomizer Head, viewed from above), then refit and and an EX 0.5 ohm Atomizer Head...
- Page 16 15 seconds while the indicator light will flash 40 times vaping, the indicator light will flash and the Tornado EX will switch off. 10 times and the Tornado EX will Charge the Tornado EX using the refuse to power or produce any...
- Page 17 If atomizer head resistance is below the indicator light will flash up 0.2ohm, the indicator light will 5 times and the Tornado EX will quickly flash 5 times when pressing switch off. Replace the atomizer the power button. If atomizer head...
- Page 18 Cleaning and Maintenance The Tornado EX battery and tank Note: To prevent damaging the connection can be cleaned by atomizer head, do not allow it to wiping down with tissue or a dry come into contact with water. cloth. The tank can be cleaned by...
- Page 19 Kit Contents 1 x Tornado EX Battery 1 x Tornado EX Tank 1 x EX Atomizer Head (1.2ohm Fitted) 1 x EX Atomizer Head (0.5ohm Spare) 1 x Glass Tube 4 x Silicone Rings 1 x USB Cable 1 x User Manual...
- Page 20 Specifications Dimensions: 19mm (diameter) 118mm (length) Battery: 1500mAh Integrated Battery Max Charging Current: 500mA Tank Capacity: 2.0ml Atomizer Head Type: EX Voltage Output: 4.2V - 3.3V (Direct output) 3.5V (Constant voltage) Resistance Range: 0.2 – 3.5ohm Maximum Filling Nozzle Diameter: 3.9mm...
- Page 21 Additional product information There are no reported medical side effects with this product. If you believe you experience a side effect, please contact the manufacturer.
- Page 22 • Do not charge the battery when temperatures are outside the range of 0°C – 45°C. • Do not attempt to repair a faulty Tornado EX as these are sealed units with no serviceable parts. Attempted repairs will void the warranty.
- Page 23 Warranty The Tornado EX kit components have a 28 day parts warranty, with the exception of Atomizer Heads, which are consumable items and covered by “dead on arrival” warranty only. The USB cable supplied has a 12-month warranty. If any parts are found to be faulty within this time please contact our customer service team, whose details are on the back page of this booklet and we will arrange for a replacement.
- Page 24 ELECTRONIC CIGARETTE KIT Tel 01254 692244 Manufactured in China www.totallywicked.co.uk under the authority of Pillbox38 UK Ltd, Tel 1(888) 761-9425 Stancliffe Street, www.totallywicked.com Blackburn, Lancashire, Tel 0941-78447082 BB2 2QR. www.totallywicked.de...
