Page 1: Air Conditioner
Air Conditioner DB98-30410A user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/global/register AW07L1 Series AW09L1 Series... - Page 2 On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest. This summer, beat the heat with your own air conditioner.
-
Page 3: Safety Information
To prevent electric shock, disconnect the power before servicing, cleaning, and installing the unit. SAFETY INFORMATION Before using your new air conditioner, please read this manual thoroughly to ensure that you know how to safely and efficiently operate the extensive features and functions of your new appliance. - Page 4 Install the air conditioner with the support bracket securely fastened to use for an extended period of time. • If the air conditioner falls, it may cause personal injury or loss of property. Ensure the air conditioner is installed in compliance with current national safety standards.
- Page 5 Insert the dust filter before operating the air conditioner. • If there is no dust filter inside the air conditioner, accumulated dust may shorten the life of the air conditioner and cause electricity waste. Keep indoor temperatures stable and not extremely cold, especially where there are children, elderly or disabled people.
- Page 6 Do not use the air conditioner if damaged. If problems occur, immediately stop operation and disconnect the plug from the power supply. If the air conditioner will not be used for an extended period of time (for example, over several months), unplug the power from the wall.
-
Page 7: Table Of Contents
Vertical air flow Cleaning the exterior Cleaning the air filter Maintaining the air conditioner APPENDIX Troubleshooting Operation ranges Getting ready to install the air conditioner Checking included parts Selecting the best location Setting up the air conditioner Assembly for drainage contents _07... -
Page 8: Checking The Parts And The Control Panel
Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay cool with optimal efficiency. Please read the user manual to get started and to make the best use of the air conditioner. CHECKING THE PARTS AND THE CONTROL PANEL Carefully unpack your air conditioner, and check the unit to make sure it is not damaged. -
Page 9: Ventilation Lever
The ventilation lever is designed to help you get fresh air from outdoors. It can also help prevent strong outdoor odors from entering the room through the air conditioner. The lever is located on the lower right side of the air flow blades. -
Page 10: Operating Your Air Conditioner
Cooling Transform a hot and humid room into a cool haven quickly by closing all unnecessary openings such as fireplace dampers, doors, or windows in the room before running the air conditioner to increase efficiency and save energy. 1. Lightly grasp the Operation knob and turn to the right. -
Page 11: Air Circulation
SELECTING OPERATION MODE Air circulation If the room is stuffy and stale, operate your air conditioner in Fan mode. The air conditioner will reduce humidity without changing the inner temperature. We recommend using this mode during especially humid but cool springdays. -
Page 12: Adjusting The Air Flow Direction
1. Move the vertical air flow blades up or down to the desired direction with your fingers. While the air conditioner cools the room, operate the appliance with the blades pointing upwards. If the unit operates in Cool mode for an extended period of time with the blades pointing downward, moisture may generate from the temperature difference and thus carries the risk of electric shock or unit malfunction. -
Page 13: Cleaning The Exterior
MAINTAINING THE AIR CONDITIONER If the air conditioner will not be used for an extended period of time, dry it thoroughly and disconnect from the wall. There may be internal damage if moisture is left in its components. -
Page 14: Troubleshooting
TROUBLESHOOTING Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. PROBLEM SOLUTION • Because of the protective mechanism, the appliance does not start The air conditioner operating immediately to keep the unit from overloading. The air does not start operating conditioner will start in 3 minutes. -
Page 15: Getting Ready To Install The Air Conditioner
• adequate ventilation. • can easily connect to a power source. • can support the weight of the air conditioner and will not cause increased operating noise and vibration. • where there is no obstacles near the air inlet and outlet. -
Page 16: Setting Up The Air Conditioner
SETTING UP THE AIR CONDITINER The air conditioner must be installed horizontally or tilted slightly to the outside for proper water drainage. Assembly for drainage Once a location has been selected for installation, proper drainage should be established. If the drain tube and/or drain hose are not provided, call your nearest contact center. - Page 17 memo _17...
- Page 18 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 1-800-10-SAMSUNG(726-7864) PHILIPPINES 1-800-3-SAMSUNG(726-7864) www.samsung.com/ph 02-5805777...
