- Page 1 R S-584WH HD SATELLITE RECEIVER WITH USB 2.0 PORT, SMART CARD READER, Wi-Fi AND ETHERNET INSTRUCTION MANUAL...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
DESCRIPTION - Receptor satélite HD. - DVB-S2/MPEG-4/MPEG-2. - Formatos de salida HD: 1080p, 1080i, 720p, 576p y 480p. - Videograbador personal (PVR con función time shift). - Reproductor multimedia. - Puerto USB 2.0. - Lector de tarjetas smart card de acceso condicional (CA). - Wi-Fi y ethernet. -
Page 5: Remote Control
REMOTE CONTROL 1.- POWER: on/standby mode. 2.- SETUP: accesses the configuration menu. 3.- MUTE: activates/deactivates the audio output. 4.- 0-9: number buttons. 5.- INFO: displays current channel information. 6.- FAV: displays favourite channel list. 7.- EPG: displays the Electronic Programme Guide. 8.- MENU: displays the main menu on the screen. - Page 6 CONNECTION Before making any connection, switch off all the devices and disconnect them from the mains. It is recommendable that you read the whole manual before connecting the devices. 1.- Install the parabollic aerial and point it towards the satellite. 2.- Connect the aerial to the receiver.
-
Page 7: System Options
PREFERENCES Press the arrow buttons on the remote control to select the following options: SYSTEM OPTIONS Allows configuration of parameters such as: menu language, OSD transparency, OSD time limit, audio or recall language. AV CONFIGURATION Allows configuration of the following options: screen format, screen mode, HD resolution, type of monitor and full screen signal. -
Page 8: Video Adjustment
VIDEO ADJUSTMENT Allows the following parameters to be configurated: brightness, contrast, saturation and tone. TIME CONFIGURATION Allows the date and time to be configurated. PROGRAMMER Allows configuration of channel changing or recording options to be configurated. To record, activate the PVR option - 8 -... -
Page 9: Parental Control
PARENTAL CONTROL This option allows the blocking and tuning of channels with a password to be activated to prevent children having acces to certain channels. The default password is 0000. It can be changed for a new one in this menu. -
Page 10: Installation
INSTALLATION Press the arrow buttons on the remote control to select the following options: AERIAL CONFIGURATION Allows satellite data and LNB information to be configurated for automatic, manual and blind channel searches. Use the arrow buttons and the colour buttons to reach the required option and press the OK button to confirm. -
Page 11: Manual Search
MANUAL SEARCH BLIND SEARCH DRIVER CONFIGURATION Allows configuation of the different options for the aerial driver: select the name of the satellite, aerial movement, etc. - 11 -... -
Page 12: Default Settings
DEFAULT SETTINGS Allows satellite receiver to be restored to the default settings. - 12 -... - Page 13 CHANNEL ADMINISTRATOR Allows the channels in the receiver to be sorted, edited, displayed in a list, moved, blocked, renamed or deleted. Press the arrow buttons and the colour buttons on the remote control to select the following options: Press the red button to access the list of satellites. Press the green button to sort the channels.
-
Page 14: System Updating
GAMES Allows games to be played with the remote control. SYSTEM UPDATING Allows the system to be updated via the USB port. MULTIMEDIA MENU Allows playback of audio, video and images contained in the storage device connected to the device’s USB port. -
Page 15: Programme Information
PROGRAMME INFORMATION Displays information about the TV or radio programme you are watching at that moment. In order to do so, press the INFO button on the remote control. LIST OF CHANNELS Press the OK button on the remote control to see the list of TV or radio channels. Use the arrow buttons and the colour buttons to access the different channel list options. -
Page 16: List Of Favourites
LIST OF FAVOURITES Press the FAV button on the remote control to access the list of favourite channels. Press the FAV button again to select the channel as a favourite. ZOOM This function allows an image to be enlarged. Press the ZOOM button on the remote control and then the OK button to enlarge the selected area with the frame. -
Page 17: Time Shift Function
Press the corresponding TS button on the remote control to activate the timeshift function. This function will only be activated if ti is connected to a USB storage device. TECHNICAL SPECIFICATIONS RDS-584WHD CHARACTERISTICS HD satellite receiver. -
Page 18: Declaration Of Conformity
DECLARATION OF CONFORMITY FONESTAR SISTEMAS, S.A. Polígono Trascueto, s/n 39600 Revilla de Camargo, Cantabria (Spain) This declaration of conformity is issued under the sole responsibility of the manufacturer. Description: HD satelite receiver Brand: FONESTAR Model: RDS-584WHD is in conformity with the relevant Community harmonisation legislation: Directive 2014/53/EU . -
Page 19: Warranty
2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it.. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out This document adds information, and never decreases the consumers’... - Page 20 www.fonestar.com...
