Assembly Instructions
Storage Rack / Workbench
Model: GR 2440-B
Dimensions ( D x W x H ) :
Storage Rack - 18Ó x 36Ó x 72Ó
Workbench - 18Ó x 72Ó x 36Ó
F o r I n s t r u c t i o n A s s i s t a n c e
(800) 637-9508
WEEKDAYS: 8:00 a.m. - 5:00 p.m. Pacific Standard Time
visit us on the web
www.theshelvingstore.com
Model: GR 2560-B
Dimensions ( D x W x H ) :
Storage Rack - 24Ó x 48Ó x 72Ó
Workbench - 24Ó x 9 6 Ó x 36Ó
Gorilla Rack Products is a division of
Rapid Rack Industries, Inc.
14421 Bonelli Street
City of Industry, CA 91746
Advertisement
Summary of Contents for Gorilla GR 2560-B
- Page 1 F o r I n s t r u c t i o n A s s i s t a n c e (800) 637-9508 WEEKDAYS: 8:00 a.m. - 5:00 p.m. Pacific Standard Time visit us on the web Gorilla Rack Products is a division of Rapid Rack Industries, Inc. www.theshelvingstore.com 14421 Bonelli Street...
- Page 2 Warranty LIFETIME LIMITED WARRANTY This Gorilla Rack¨ product ( e x c lusive of shelves) is warranted to the original purchaser against defects in material and workmanship. If there are failur e of product, Rapid Rack will without charge and upon proof of purchase, repair/ replace at our own discretion.
- Page 3 GR 2440-B OVERVIEW WORKBENCH To facilitate assembly we recommend having two persons assemble the workbench. Tool required: Rubber Mallet / Hammer Please read and follow instructions to avoid injuries. Contents Item Description Qty. Angle Post 36Ó Long Double Rivet Beam Short Double Rivet Beam Shelf Deck Post Caps...
-
Page 4: Work Bench
PRIMARY END ASSEMBLY WORK BENCH Step 1 - End Assembly Start bottom of frame assembly by joining an Short Double Rivet Beam ( I tem 3) into the two bottom keyholes of a 36" Angle Post ( I tem 1) . Be sure that the flange is up and drive the rivets to the bottom of the key hole by hitting the beam with a rubber mallet. - Page 5 PRIMARY END ASSEMBLY WORK BENCH Step 3 - Adding top beams Add the Short Double Rivet Beams to the top two key holes of each angle post (refer to detail). Be sure all flanges are Hit the beam near the joints with a rub- ber mallet to lock pieces together.
- Page 6 ADD ON UNIT WORKBENCH Step 6 - Completing the Add-On Unit Assemble the top Long Double Rivet Beams to the top two keyholes of the Angle Post. Assemble the two Long Double Rivet Beams at the 7 th -8 th to keyhole. Hit all Beams to lock.
-
Page 7: Parts Overview
PARTS OVERVIEW STORAGE RACK To facilitate assembly we recommend having two persons assemble the storage rack. Tool required: Rubber Mallet / Hammer Please read and follow instructions to avoid injuries. Contents Item Description Qty. Angle Post 36Ó Long Double Rivet Beam Short Double Rivet Beam Shelf Deck Post Caps... -
Page 8: Bottom Assembly
BOTTOM ASSEMBLY STORAGE RACK Step 1 - End Assembly Start bottom of frame assembly by joining an Short Double Rivet Beam ( I tem 3) into the two bottom keyholes of a 36" Angle Post ( I tem 1) . Be sure that the flange is up and drive the rivets to the bottom of the key hole by hitting the beam with a rubber mallet. -
Page 9: Top Assembly
TOP ASSEMBLY STORAGE RACK DO NOT USE BOTTOM RIV E T Step 3 - Top End Assembly Start the top end assembly by joining an Short Double Rivet Beam into the top keyholes of a 36" Angle Post (detail A). Add the second 36" Angle Post. - Page 10 REINFORCING STORAGE RACK Step 5- Reinforcing Mid Section Add two Long Double Rivet Beams to mid section as shown. Be sure to use the bottom key hole of the top assembly angle post and top key hole of the bottom assembly. Follow the proper key- holes as shown in the detail illustration.
- Page 11 COMPLETION STORAGE RACK Step 7 - Shelves Step 8 - Post Caps Assemble the remaining Short and Long Double Add the Post Caps (Item 5) to the top of the 4 Rivet Beams to your desired location on the corner Angle Posts as shown in the detail. angle post.
