Qualcast XSS41A Quick Start Manual

ASSEMBLY
Unpack the lawn mower ensuring all parts are present
(see parts list overleaf) before discarding the packaging.
1
Align the lower handle
with the holes in the
deck. Fix the lower
handle using the 4 handle
fixing bolts onto the deck
firmly with supplied
wrench.
Locate upper handle
2
bar on lower with the
bolts. Secure the left
bolt using plastic
tightening knob
ensuring cables are
not twisted.
MOWING THE LAWN
Fill the petrol tank with 0.8l of normal 95 Octane petrol
(standard unleaded) using a funnel and measuring jug.
9
When starting a cold
engine, press down the
primer fully 3~5 times.
When starting a warm
engine, the primer
does not need to be
used.
10
Hold the stop/start bar
firmly to the handle to
Engine start
disengage the motor
Engine stop
brake and automatic
cut out.
3
Locate the rope guide
over the right hand
bolt so the 90° bend
sits on top of the
handle bar and secure
using the plastic knob.
4
Using the cable
clamp provided,
secure the cables to
the handle without
trapping them.
11 To start the engine slowly
pull the start cord out
until resistance is felt
(approx 10-15cm) then
start the engine with a
sharp vigorous pull.
To stop the mower release the stop/start
bar.
PREPARING TO MOW
Follow these steps to ensure quick and easy set up
5
Lift the flap and
hook the grass bag
over the plastic
hooks on the rear
of the mower.
6
Adjust the cutting
height via the lever
located by the rear
2
right hand wheel.
1

IMPORTANT INFORMATION!

Always read the instruction manual thoroughly
before starting the lawnmower.
In cold weather it may be necessary to repeat the cold engine starting
process.
Never allow the starter cord to snap back.
Check the oil level before every use. Always use high quality detergent oil classified
SAE30 oil (or equivalent eg 5W 30, often termed as 4 Stroke lawn mower oil).
If you have any difficulties please contact the
helpline on 01904 727500
email support@gardenservicecentre.co.uk
or visit www.gardenservicecentre.co.uk
every time.
7
The engine does not
come with oil. Add
0.5 litres of oil.
Add Full
CHECK THE OIL LEVEL
BEFORE EVERY USE.
8
Slowly pull out starter
cord & hook it through
the eye of rope guide.
You should ALWAYS
start your mower
from this position.
