PETROL SELF PROPELLED MOWER
41CM
SPM41
Important
- Please read these instructions fully before operating or maintaining your petrol lawnmower
These instructions contain important information that will help you get the best
from your lawnmower, protecting your power tool investment.
ORIGINAL
INSTRUCTION
MANUAL
AFTERSALES SERVICE
01904 727505
MON-FRI 9am-5pm SAT/SUN 11am-4pm
www.spearandjackson-power.com
Advertisement
Table of Contents
Related Manuals for Spear & Jackson SPM41
Summary of Contents for Spear & Jackson SPM41
- Page 1 PETROL SELF PROPELLED MOWER AFTERSALES SERVICE 01904 727505 41CM MON-FRI 9am-5pm SAT/SUN 11am-4pm SPM41 www.spearandjackson-power.com Important - Please read these instructions fully before operating or maintaining your petrol lawnmower These instructions contain important information that will help you get the best...
-
Page 2: Table Of Contents
ThaNk yOu! CONTENTS Dear Customer, Safety Information....................04 Description of symbols..................... 04 Thank you for choosing a Spear and Jackson petrol lawnmower. General safety......................05 Spear and Jackson was founded in 1760 in the city of Sheffield, which is world Personal safety...................... -
Page 3: Description Of Symbols
SaFETy INFORMaTION SaFETy INFORMaTION Please read these instructions fully before operating or maintaining your machine. Please read these instructions fully before operating or maintaining your machine DESCRIPTION OF SyMBOLS GENERaL SaFETy The following warning symbols appear throughout this manual and indicate the appropriate Thoroughly inspect the area where the ■... -
Page 4: Maintenance And Storage Safety
SaFETy INFORMaTION SaFETy INFORMaTION Please read these instructions fully before operating or maintaining your machine Please read these instructions fully before operating or maintaining your machine OPERaTION SaFETy Never pick up or carry a lawnmower while ■ If the fuel tank has to be drained, this ■... -
Page 5: Unpacking
BOX CONTENTS aSSEMBLy PaRTS unpacking i. Unpack all parts and lay them on a flat, stable surface. Engine upper handle with soft grip ii. Remove all packing materials and shipping devices if Steel deck Start/Stop bar applicable. handle fixing bolts x 4 (on deck) handle tensioning knob with nut M8 iii. -
Page 6: Grass Bag Assembly
aSSEMBLy aSSEMBLy iii. Lift the upper handle, and lock in place using the ii. Raise the safety flap (6), and hook the collection bag handle tension knob (3), rope guide (13) and tensioning onto the mower. bolts. Ensure the lower and upper handles are firmly Release the safety flap. -
Page 7: Preparing To Operate The Lawnmower
PREPaRING TO OPERaTE ThE LaWNMOWER PREPaRING TO OPERaTE ThE LaWNMOWER Check the engine oil level with the engine stopped and the mower on a level surface. STOP! Remove the oil filler dipstick and wipe oil from it with a ■ Do not start the engine before putting 500Ml of clean cloth. -
Page 8: Operation
PREPaRING TO OPERaTE ThE LaWNMOWER OPERaTION Never mix oil with petrol. Setting the cutting height ■ Refuel carefully to avoid overfilling or spilling fuel to allow for ■ expansion. There should be no fuel in the filler neck. WaRNING! Clean up any overflow or splashes of petrol before starting ■... - Page 9 OPERaTION OPERaTION i. Starting procedure quick guide iv. With right hand, slowly but firmly pull the starter handle and rope from the pull cord guide until you feel resistance, then Before starting the engine, make sure that the spark plug cap pull briskly.
- Page 10 OPERaTION OPERaTION Mowing Emptying the grass bag WaRNING! i. Raise the safety flap with one hand and remove the grass Always observe the strictest safety procedures when bag using its handle with your other hand. To maintain using the lawnmower. Always fit the grass bag before safety, the safety flap will close back to cover the mulching mowing.
-
Page 11: Maintenance
MaINTENaNCE MaINTENaNCE Storing the lawnmower for short periods Empty the petrol tank with a petrol suction pump if available ■ or use the tipping method if a large quantity of fuel needs to be removed. After mowing, please follow the below actions prior to placing the To remove smaller quantities of fuel, simply start the engine lawnmower in storage. - Page 12 MaINTENaNCE MaINTENaNCE Never clean the lawn mower with a water jet or high- Maintenance schedule ■ pressure cleaner. The engine must remain dry. Do not use aggressive cleaning agents such as cold cleaner or Performing routine maintenance correctly on your lawnmower will petroleum ether.
- Page 13 MaINTENaNCE MaINTENaNCE • Clean the spark plug with a wire brush. Replacing cutting blade • Using a feeler gauge set the gap to 0.51mm. WaRNING! - Before you remove the grass collection bag, stop the engine and wait until the blade has come to a complete stop.
-
Page 14: Technical Data
MaINTENaNCE TEChNICaL DaTa Property Value Check the washer is still slightly domed to keep the Engine type Single cylinder 4-stroke pressure on the bold to stop it unwinding, keeping the blade Engine displacement 125cc firmly secure. Replace the washer (right way round!) and bolts. -
Page 15: Troubleshooting
TEChNICaL DaTa TROuBLEShOOTING Suspected malfunctions are often due to causes that the user can fix themselves. PART NUMBER ACCESSORIES Therefore, check the product using this section. In most cases the problem can be solved QC12YC Spark plug quickly. 916901 Collection grass bag 933206 Blade WaRNING! -
Page 16: Ec Declaration Of Conformity
1, from the retailer that it was originally Gasoline Lawn Mower Model no.: SPM41 bought from. Please keep your receipt safe or staple it to the back of this manual for future Certification no.: XSZ41D...
