UMG MODULAR 300
USER MEDIA GATEWAY E1, VOIP, GSM, FXS AND FXO
Main Characteristics
Modular, according to the scenary which will be used
2 Ethernet Giga ports
VoIP channels: 1 SIP channel for each TDM channel
adding up to the maximum of 46 SIP channels.
Modularity: 3 slots for the desired combination, not
exceeding 46 channels:
•
1 E1 (30 channels)
•
2 GSM (up to 6 GSM channels) 2G or 3G
•
4 FXO (up to 12 FXO)
•
8 FXS (up to 24 FXS)
Overview
UMG Modular 300 is an user media gateway of the Khomp gateway lineup. This intermediate device is able to
translate the telephony signaling protocols E1 (ISDN and R2) and SIP while supporting the GSM, FXS and FXO technologies,
thus interconnecting the digital, analogical, mobile and IP networks to the telephony and communication unified platforms,
based on SIP.
Developed to be used in small-sized scenarios in the expansion process, with high-performance assurance, this
modular equipment makes available 46 channels, divided in 3 slots in order to combine the interfaces which are more
convenient to the model of business in which it will be applied. Moreover, its has a size that makes it easy to install as well as
an user friendly web interface for its configuration and monitoring
With a robust architecture based on DSP dedicated to handling telephony critical tasks, as well as features for
signaling and cancelling echoes, resulting in high quality audio, the UMG Modular 300 can be seen as an extremely effective
gateway. It also features transcoding support in all channels as well as support to the main signaling and CODEC system in the
industry, in addition to providing call control and routing, according to the programmed rules.
Rua Joe Collaço, 253, Florianópolis, SC | CEP 88037-010 | Brazil
Typical Applications
Gateway and routing between the TDM and SIP
interfaces.
Ideal for VoIP carriers in the process of expansion.
Application for the corporate market.
Ideal for call routing between branch and headquarter
via IP network.
Ideal for VoIP operators selling minutes for professional
services.
(+55 48) 3722.2900 | comercial@khomp.com
Advertisement
Summary of Contents for Khomp UMG MODULAR 300
- Page 1 With a robust architecture based on DSP dedicated to handling telephony critical tasks, as well as features for signaling and cancelling echoes, resulting in high quality audio, the UMG Modular 300 can be seen as an extremely effective gateway. It also features transcoding support in all channels as well as support to the main signaling and CODEC system in the industry, in addition to providing call control and routing, according to the programmed rules.
- Page 2 Factory warranty 3 years Voice quality ISO 9001:2008-certified company o Echo canceling o SIP-dedicated processing Support to FAX in pass-through mode Rua Joe Collaço, 253, Florianópolis, SC | CEP 88037-010 | Brasil (+55 48) 3722.2900 | comercial@khomp.com...
- Page 3 Fitting your business With UMG Modular 300 you can decide which technologies will be part of your composition, according to the business the device will be applied to, with a limit of 46 SIP channels. There are 3 available slots. Considering that, for instance, 1 slot is used for E1 (30 channels), the two remaining ones can be used for the GSM technology (with 4 channels), or they can also be used for FXO (with 8 channels), or 2 FXS (adding up to16 channels).
- Page 4 UMG MODULAR 300 Rear view without telephony interfaces. Rear view with 1 E1, 8 FXS, and 4 FXO. Examples of system screens Monitoring screen. Rua Joe Collaço, 253, Florianópolis, SC | CEP 88037-010 | Brasil (+55 48) 3722.2900 | comercial@khomp.com...
- Page 5 UMG MODULAR 300 Diagnostics screen Configuration screen Rua Joe Collaço, 253, Florianópolis, SC | CEP 88037-010 | Brasil (+55 48) 3722.2900 | comercial@khomp.com...
