- Page 1 USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. Ver.
- Page 2 Thank you for your purchase of the SWAGTRON® T380 Hoverboard by SWAGTRON®! You’re about to take the next step in the evolution of transportation. The SWAGTRON® takes the fun of a skateboard, the ease of an electric scooter, and tops it off with an extra bit of swag.
-
Page 3: Table Of Contents
SWAGTRON® T380 User manual Contents I - GENERAL INFORMATION —— 1.1 ABOUT THE SWAGTRON ® —— 6 1.2 WHAT’S IN THE BOX? —— 1.3 WHAT’S NEW? —— 1.4 SAFETY NOTICE —— 1.5 IMPORTANT INFORMATION —— 1.6 DISPOSAL AT END-OF-LIFE ——... - Page 4 3.2 DIAGRAM OF OPERATION —— 20 3.3 CALIBRATION —— IV – SAFE RIDING TECHNIQUES —— 23 V – BATTERY INFORMATION —— 5.1 CHARGING THE SWAGTRON ® —— 5.2 BATTERY LEVEL INDICATOR —— 5.3 RANGE PER CHARGE —— 5.4 SAFETY WARNINGS ——...
-
Page 5: I - General Information
I - GENERAL INFORMATION This user manual will guide you through the functions and usage of your SWAGTRON®. Before operating this vehicle, read all the instructions for safe assembly, charging and operation. Please inspect the SWAGTRON® hoverboard upon unpacking for any signs of physical damage or defects. -
Page 6: What's In The Box
+ Charging Adapter + User Manual + Rubber Bumpers 1.3 WHAT’S NEW? The SWAGTRON® Hoverboard contains the latest technology from SWAGTRON®, including all new features that make riding safer and more fun. + New proprietary custom-designed hard polycarbonate shell casing with matte fi nish. -
Page 7: Safety Notice
+ Open wheel well design allows for better wheel rotation clearance and maintenance. 1.4 SAFETY NOTICE The SWAGTRON® has been designed with the utmost safety in mind for its riders. Through our meticulous design and engineering, extra precautions have been taken to protect the user from product hardware malfunctions. - Page 8 By riding the SWAGTRON®, the user acknowledges and accepts personal responsibility of all risks associated with the use of the SWAGTRON® Hoverboard, which may include, but are not limited to, muscle injuries, broken bones, lacerations, or other serious injuries that may be sustained while using the SWAGTRON®.
-
Page 9: Important Information
English Swagtron T380 Hoverboard... -
Page 10: Disposal At End-Of-Life
The substances contained inside the battery present chemical risks to the environment. The recommended disposal for any SWAGTRON® T380 at its end-of-life is to dispose of the entire unit at or through an e-waste recycling center, program, or facility. Local regulations and laws pertaining to the recycling and disposal of lithium ion batteries and/or products containing them will vary according to country, state, and local governments. -
Page 11: Product Features
Upgraded Motor and Stabilizers with Enhanced Gear Technology with Enhanced Gear Technology Wider, Anti-slip Foot Pedals Wider, Anti-slip Foot Pedals *Rubber bumper guards are included Power Button LED Movement Indicators Battery Level Indicators System Status Indicators Charging Port English Swagtron T380 Hoverboard... -
Page 12: Swagtron Sentryshield® - Patented Multilayered Protection
® – PATENTED MULTILAYERED PROTECTION Your safety is our top priority. That’s why the SWAGTRON® utilizes a premium quality lithium-ion battery pack that is specifi cally designed with your well-being in mind. The battery housing used in SWAGTRON® SentryShield® technology is made of aluminum, which provides an airtight seal enclosing the battery. -
Page 13: Learning Mode / Standard Mode / Advanced Mode
For more information on the battery specifi cations, see SECTION V. 2.3 LEARNING MODE / STANDARD MODE / ADVANCED MODE The SWAGTRON® T380 includes three riding modes in order to provide all kinds of riders with the best experience possible. -
Page 14: Movement Indicators
2.4 MOVEMENT INDICATORS The SWAGTRON® includes new movement indicators to let others know when you’re on the move. Always keep a safe distance from other riders and use notifi cations to avoid unnecessary accidents! Movement Indicator Color Action BRAKING – Red lights indicate slowing/stopping, unexpected pauses, or sudden movements. -
Page 15: Using Bluetooth
Using your mobile device, turn on Bluetooth®, make it “discoverable” if needed, then search. The device names “Swagtron” & “Swagtron music” should appear. Select “Swagtron music” to begin connecting if you would like to play music on your T380. Connect to “Swagtron” through your SWAGTRON app with default password (000000) to switch modes and monitor your SWAGTRON T380 battery status. - Page 16 2.) Connection/pairing successful 3.) Connection terminated + Powering on the SWAGTRON® will automatically enable Bluetooth® i.e. Bluetooth® will become enabled and stay enabled as long as the SWAGTRON® is powered on. + Some mobile devices immediately become “discoverable” once Bluetooth® is activated. Please check the instructions of your Bluetooth®-enabled device for any trouble with this feature.
-
Page 17: How To Ride
Before you begin operation, charge your SWAGTRON® hoverboard with the included charging adapter. Charge time can take up to 2-3 hours. For detailed information on how to charge your SWAGTRON®, see Section 5.1 Press the POWER BUTTON to turn on your SWAGTRON®... - Page 18 The SWAGTRON® has 4 sensors below the pedals. When the rider steps on a pedal, the SWAGTRON® will adjust itself to balance automatically. If the SWAGTRON® does not enter self-balancing mode when triggering the sensors, the System Indicators will light up to indicate an error.
-
Page 19: Diagram Of Operation
+ Avoid uneven or rocky surfaces as the SWAGTRON® may not function properly. + Avoid hills or slopes with inclines over 30 degrees. + When the operator exceeds the maximum speed, a warning alarm will emit from the speaker. 3.2 DIAGRAM OF OPERATION The SWAGTRON®... - Page 20 + Avoid riding sideways or turning on slopes. The self-balancing sensors may malfunction and may require recalibration. + Do not step on the center pivot point of the T380. Doing so may cause severe damage to the unit’s internal parts.
-
Page 21: Calibration
3.3 CALIBRATION If your T380 seems to pull to the left or right during your ride, you may need to recalibrate its sensors. The process requires a fl at stable surface and optionally a level (available at any hardware store.) Power your T380 off. -
Page 22: Safe Riding Techniques
IV – SAFE RIDING TECHNIQUES We sincerely hope every operator can ride the SWAGTRON® T380 safely. Think back to when you fi rst learned to ride a bike, drive a car, or skateboard. Although the T380 is designed with gyroscopic balancing technology in order to maintain maximum stability, it is still possible to “override”... - Page 23 + Before riding in a new area, check for obstacles. Before moving backwards, check for obstacles or pedestrians behind you. + The SWAGTRON® can only support the weight of one person at a time. The rider must meet the minimum weight requirement of 44 lbs in order to safely ride the SWAGTRON®.
-
Page 24: Battery Information
Plug the charger into a grounded wall outlet (100V-240V; 50-60Hz). Verify that the green light is on, then plug the other end of the charging unit into the T380. If charging while the hoverboard is on, all fi ve lights of the battery indicator will turn blue when... - Page 25 + Please keep your charging environment clean and dry. + If the charging port is damp or has any liquid on it, DO NOT charge your SWAGTRON®. + In order for the battery to operate at maximum effi ciency, avoid charging your SWAGTRON® in extremely hot or extremely cold environments.
-
Page 26: Battery Level Indicator
5.2 BATTERY LEVEL INDICATOR The SWAGTRON® T380 includes a new LED indicator system so you never have to guess how much power is left in your ride. There are 5 levels of power that you can monitor right at your feet. -
Page 27: Range Per Charge
5.3 RANGE PER CHARGE The average distance for which you can ride your SWAGTRON® T380 on a full charge is between 7 to 12 miles. However, many factors need to be considered when determining the actual range per charge. Factor... - Page 28 Rinse well with water and immediately seek medical care. If left untreated, the battery fl uid could cause damage to the eye. 5.4.2 While Charging (1) Be sure to follow the rules listed below while charging the battery. Failure to do so may cause the battery to Swagtron T380 Hoverboard English...
- Page 29 The temperature range within which the battery can be discharged is -4°F ~ 131°F (-20°C to 55°C). Use of the battery outside of this temperature range may damage the performance of CAUTION the battery or reduce its life expectancy. English Swagtron T380 Hoverboard...
-
Page 30: Maintenance
VI – MAINTENANCE Your SWAGTRON® needs to be maintained in order to always have the best riding experience. Follow the below tips and reminders to keep your SWAGTRON® running in top condition. NOTE: + Always ensure the POWER is OFF and the hoverboard is not being charged during maintenance. -
Page 31: Storage
+ Before storing your SWAGTRON®, fully charge the battery to avoid over discharging due to non-use. + Discharge and recharge the battery every three months. + Store your SWAGTRON® indoors in a location with stable temperate. Do not store in an unheated garage or shed. -
Page 32: Swagtron T380 Specifications
Battery Shielding ADC10 Aluminum Alloy Casing Charger Voltage 42Vdc, 2A Model SPS-T844202000-C8 manufactured by SHENZHEN DOKOCOM ENERGY TECHNOLOGY CO LTD (E307126) Input:100-240Vac,50/60Hz, Output:42Vdc,2A Model AOI-08420200DD1 manufactured by DONGGUAN AOI ELECTRONIC TECHNOLOGY CO LTD (E361957) Input:100-240Vac,50/60Hz Output:42Vdc,2A Swagtron T380 Hoverboard English... -
Page 33: Year Limited Hardware Warranty
This Warranty is for one replacement only of like-items and does not cover items out of production if the product is no longer made or stocked. This Warranty is not assignable or transferable. The original purchaser may call SWAGTRON’s toll-free number at 1-844-299-0625 for service request. - Page 34 LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THE DURATION AND REMEDIES OF ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANTY. Swagtron T380 Hoverboard English...
- Page 35 COPYRIGHT © 2017 SWAGTRON. ALL RIGHTS RESERVED.
