To adjust:
1. Remove the battery pack.
2. Remove the throat plate.
3. Install the blade.
4. Install the riving knife or riving knife with guard.
NOTE: Recheck and adjust for each change in
riving knife or blade.
5. Loosen the riving knife adjustment screws
(4 mm hex).
Riving Knife
Adjustment
Screws
6. Tighten or loosen the 3 riving knife set screws
(2.5 mm hex) as needed.
7. Tighten the riving knife adjustment screws.
8. Recheck both sides of the blade/riving knife.
9. Repeat until riving knife is properly adjusted to
the blade.
10. Once adjusted, remove the riving knife, reinstall
the throat plate, then reinstall the riving knife
and anti-kickback pawls (if appropriate for the
operation).
ONE-KEY™
Chemical Burn Hazard.
WARNING
This device contains a
lithium button/coin cell battery. A new
or used battery can cause severe in-
ternal burns and lead to death in as
little as 2 hours if swallowed or enters the body.
Always secure the battery cover. If it does not
close securely, stop using the device, remove the
batteries, and keep it away from children. If you
think batteries may have been swallowed or
entered the body, seek immediate medical atten-
tion.
Riving Knife
Set Screws

Internal Battery

An internal battery is used to facilitate full ONE-KEY™
functionality. Turn the saw over to access the battery
door.
To replace the battery:
1. Remove the battery pack.
2. Remove the screw and open the battery door.
3. Remove the old battery, keep it away from children,
and dispose of it properly.
4. Insert the new battery (3V CR2032), with the posi-
tive side facing up.
5. Close the battery door and tighten the screw
securely.
To reduce the risk of personal in-
WARNING
jury and damage, never immerse
your tool, battery pack or charger in liquid or
Clean dust and debris from vents. Keep handles
clean, dry and free of oil or grease. Use only mild
soap and a damp cloth to clean, since certain clean-
ing agents and solvents are harmful to plastics and
other insulated parts. Some of these include gasoline,
turpentine, lacquer thinner, paint thinner, chlorinated
cleaning solvents, ammonia and household deter-
combustible solvents around tools.
For repairs, return the tool, battery pack and charger
to the nearest service centre.
ACCESSORIES
Use only recommended accesso-
WARNING
ries. Others may be hazardous.
For a complete listing of accessories, go online to
www.milwaukeetools.com.au/
www.milwaukeetools.co.nz or contact a distributor.
21
Cleaning
Repairs
