Warning And Error Message; Using The Charge Control Software "Charge Master - Skyrc e660 Instruction Manual

Warning and Error Message

In case of an error the screen will display the cause of error and emit an
audible sound.
Incorrect polarity connected.
The battery is interrupted.
C O N N E C T E R R O R
The
battery connection is wrong.
C H E C K M A I N P O R T
B A L A N C E C O N N E C T
The
balance
connect
is
wrong.
E R R O R
D C I N T O O L O W
Input voltage less than 11V.
D C I N T O O H I G H
Input voltage higher than 18V.
C E L L E R R O R
Voltage of one cell in the battery pack is too low.
L O W V O L T A G E
C E L L E R R O R
Voltage of one cell in the battery pack is too high.
H I G H V O L T A G E
C E L L E R R O R
Voltage of one cell in the battery pack is invalid.
V O L T A G E - I N V A L I D
C E L L N U M B E R
The cell number is wrong.
I N C O R R E C T
I N T . T E M P . T O O H I
The internal temperature of the unit goes too high.
The external temperature of the battery goes
E X T . T E M P . T O O H I
too high.
The battery capacity is more than the maximum
O V E R C H A R G E
C A P A C I T Y L I M I T capacity which the user sets.
· 34

Using the Charge Control Software "Charge Master"

O V E R T I M E L I M I T
B A T T E R Y W A S F U L L
N O B A L A N C E C A B L E
D E T E C T E D
N O P O W E R
D I S T R I B U T E D
Using the Charge Control Software
"Charge Master"
The free "Charge Master" software gives you unparalleled ability to
operate the charger through the computer. You can monitor pack
voltage, cell voltage and other data during the charging, view charge
date in real-time graphs. And you can initiate, control charging and
update firmware from "Charge Master".
In order to connect the charger to the computer and use the "Charge
Master", you are required to use a USB cable which is not included in
this package. The cable must be terminated on one end with "A" plug
and the opposite end is terminated with "micro-B" plug which can
connect to charger directly.
The "Charge Master" can be download from www.skyrc.com.
e660 e660
The charging time is longer than the maximum
charging time which the user sets.
The battery voltage is higher than the maximum
voltage which the user sets when charging in
balance mode.
Balance connection is suggested for all lithium
process (charge/discharge/storage/fast
charge/balance charge), if your battery comes
without balance lead, push enter to start.
No power allocate to the charger.
