Luxna Lighting LXFRD10/RC Operation Instructions

Remote Control Handset
Operation Instructions
Please read these instructions carefully before use
Leave a copy for the user/maintenance engineer for future reference

Main Functions

• This Remote Control handset is for use with LUXNA Lighting
APP LED Downlights.
• The user can control light intensity with a standard dimming
range from 100% to 5%. The Night Light mode provides
2% of the maximum intensity.
• Light colour temperature can be selected from: Warm White
(WW) 3000K through to Cool White (CW) 6000K

Button Functions

Master ON ALL lights will switch on.
Master OFF ALL lights will switch off.
Dim+ Increases the light intensity.
Dim _
Decreases the light intensity.
CT WW Adjusts the light to a warmer colour temperature.
CT CW Adjusts the light to a cooler colour temperature.
ON
Channel
Individual control of channels 1, 2, 3 & 4
OFF
Part No. Description
Remote Control Handset
LXFRD10/RC
Issue: LXFRDRCV1.616
• Group settings up to four selectable channels.
• Transfer frequency 2.4GHz.
• Maximum sensing range = 10 metres.
• Optional wall mounting bracket included.
2x AAA
2 Year
Warranty
Batteries
www.luxna-lighting.com
