Summary of Contents for Acorn 180
- Page 1 User Manual Acorn 180 Curved Stairlift T565 ENGLISH User Manual DEUTSCH Bedienungsanleitung ESPAÑOL Manual del Usuario FRANÇAIS Mode d’Emploi ITALIANO Manuale Utente...
- Page 2 IMPORTANT Ensure that only an authorized and qualified Acorn trained engineer installs and services the stairlift. Under no circumstance should anyone other than an engineer trained and authorized to install, adjust, service or modify any mechanical or electrical device on this product. Failure to follow this warning may result in safety system compromises which could result in serious injury or death.
- Page 3 To avoid injury do not make alert others in case you being used by others and is contact with moving parts. encounter difficulties when clear of articles or obstructions using the stairlift before using the stairlift. Acorn Stairlifts User Manual Acorn Stairlifts User Manual...
- Page 4 DANGER! WARNING! WARNING! Always consult your Acorn Do not operate the stairlift if Do not use the stairlift if you representative if the need under the influence of alcohol have not been given a for an authorized engineer or drugs.
- Page 5 YOUR STAIRLIFT Acorn Stairlifts User Manual...
-
Page 6: Charging Points
YOUR STAIRLIFT The Acorn 180 Curved Stairlift is an electrically powered stairlift designed for domestic use. If used correctly, it will provide many years of safe, reliable service. It is designed to carry one person weighing no more than 120kg (264lbs/18.8 stone). - Page 7 QUICK USER GUIDE This is a quick start reference guide to help get you started using your Acorn 180 curved stairlift. It is important for your safety that you study this manual to completely familiarise yourself with your stairlift. TURNING THE LIFT ON 1 Insert and turn key clockwise.
- Page 8 It is important that the stairlift is moved to the nearest charge point to ensure battery drain does not occur. Images shown for illustrative purposes only and may change. Before operating the powered hinge, ensure that the area is clear Acorn Stairlifts User Manual...
- Page 9 Make sure the seat is locked into position before getting on or off the stairlift. When not in use, please ensure that the seatbelt is kept clear of the stairlift rail. Acorn Stairlifts User Manual...
- Page 10 (E7) on the digital display, the stairlift will allow the user to bring the unit DOWN to the nearest charging station. The unit will LOW BATTERY not allow the user to travel in the UP direction until the batteries are sufficiently charged. Acorn Stairlifts User Manual...
- Page 11 1 & 2: Each side of the carriage. 3 & 4: Each side of the footrest. 5: Under the footrest. If these encounter any obstruction, the stairlift will stop immediately. Move the stairlift back in the opposite direction and remove the obstruction. Acorn Stairlifts User Manual...
- Page 12 The Acorn 180 Curved Stairlift is a modular system, designed for easy assembly and maintenance utilising the rack and pinion method of travel along the rail, which is still the most reliable system available. This method is used with customer safety paramount throughout design and manufacture.
- Page 13 Before operating the powered hinge, ensure that the area is clear Acorn Stairlifts User Manual...
- Page 14 Please ensure that the battery is connected correctly. If the battery is connected wrong it could damage the remote and may require replacing. Acorn Stairlifts User Manual...
- Page 15 Bring the unit down to the nearest charging station. If this symbol is displayed, DO NOT use the hand winder in the down direction as this could damage the stairlift. Contact your stairlift supplier immediately. Acorn Stairlifts User Manual...
- Page 16 Fit the hand winder onto the hexagonal spindle and follow the instructions on the label inside the round cover. Introducing Your St Main Components .. Description of Oper Charging Your St Safe Operation ..Acorn Stairlifts User Manual Using Your Stairlift.
- Page 17 Release the direction controller on the arm rest and press again in the DOWN direction. In the unlikely event that you need to disembark the stairlift mid travel, always attempt to swivel the seat towards the stairs. Acorn Stairlifts User Manual...
- Page 18 MAKE SURE THE SEAT IS LOCKED INTO POSITION BEFORE ATTEMPTING TO DISEMBARK THE STAIRLIFT IMPORTANT! IT IS IMPORTANT THAT THE SEATBELT IS UNDONE ONLY WHEN THE SEAT HAS BEEN FULLY SWIVELLED TO FACE THE STAIRCASE AND LOCKED INTO POSITION. Acorn Stairlifts User Manual...
- Page 19 The equipment has been tested and complies fully with Class A of 47CFR 2011 part 15 certification. If not installed correctly by an Acorn Qualified Technician there may be some interference with other household equipment (i.e TV and Radio reception). This can be rectified by moving this equipment to a different location.
- Page 20 Service Date: Next Service Due: Engineer Signature: Customer Signature: Service Date: Next Service Due: Engineer Signature: Customer Signature: Service Date: Next Service Due: Engineer Signature: Customer Signature: Service Date: Next Service Due: Engineer Signature: Customer Signature: Acorn Stairlifts User Manual...
- Page 21 WIRING DIAGRAM Acorn Stairlifts User Manual...
- Page 22 PCB CONNECTIONS FUSE 25A Replace with same type and value Acorn Stairlifts User Manual...
- Page 23 Serial No: Model: Acorn 180 Curved Stairlift Acorn Mobility Services declares that the above referenced product is in conformity with the essential requirements of: Machinery Directive 2006/42/EC; Electromagnetic compatibility directive 2014/30/EU; Low voltage directive 2014/35/EU. Radio equipment directive 2014/53/EU, ETSI EN 300-220-2 V3.1.1...
- Page 24 Notes: Acorn promotes responsible recycling. Do not attempt to dispose of the stairlift yourself Acorn Stairlifts User Manual...
- Page 25 Acorn reserves the right to change specification without prior notice. All measurements are approximate. Images are shown for illustrative purposes only. Product may vary slightly. All information correct at time of going to print. E&OE. COPYRIGHT ©2017 ACORN MOBILITY SERVICES LIMITED All Rights Reserved...
