WASHING MACHINE SWF-P8IW/XEH SWF-P10IW/XEH SERVICE Manual WASHING MACHINE CONTENTS 1. SPECIFICATIONS 2. OVERVIEW OF THE WASHING MACHINE 3. OVERVIEW OF THE CONTROL PANEL 4. PROCESS TABLE 5. GENERAL REEOR FUNCTION 6. TROUBLE DIAGNOSIS 7. TEST MODE 8. DESIGNATION OF MAIN COMPONENTS 9.
19. When the wash-heater is replaced, check it is inserted in the bracket-heater and screw the nut. If the wash-heater is not inserted in the bracket-heater properly, this may cause the noise and leakage since it is contacted to the drum. SAMSUNG ELECTRONICS CO., LTD...
MODEL SWF-P8 SWF-P10 SWF-P12 220 V 430 W 500 W 550 W 240 V 430 W 500 W 550 W PUMPING 34 W WATER CONSUMPTION 54 (STANDARD COURSE) SPIN REVOLUTION MODEL SWF-P8 SWF-P10 SWF-P12 1000 1200 SAMSUNG ELECTRONICS CO., LTD...
2. Overview of the Washing Machine WATER SUPPLY VALVE CONTROL-PANEL DRAWER ASSY DOOR SENSOR PRESSURE ADJUSTABLE LEG ASSY PUMP POWER CORD BUFFER SPRING WEIGHT-BALANCE DRAIN HOSE PULLEY BELT SHOCK ABSORBER ASSY MOTOR SAMSUNG ELECTRONICS CO., LTD...
Press once to turn the washing machine on, press again to turn the washing machine off. If the washing machine power is left on for longer than 10minutes without any buttons being touched, the power automatically turns off. SAMSUNG ELECTRONICS CO., LTD...
- At the time of initial water supply, if the water temperature is not appropriate, water starts to be drained and it is forced to be drained for 2 min when the abnormal frequency of 25.24KHz is detected. - Display shows ‘E8’. - This error can be cleared by POWER S/W OFF. SAMSUNG ELECTRONICS CO., LTD...
5) As the parts on P.C.B are coated by the urethane, they can not be tested by the test bar of the meter. Check the trouble by the test mode method according to the procedure. SAMSUNG ELECTRONICS CO., LTD...
Page 9
The heating is not executed. - Is the wash heater terminal unplugged? Ω - Is the wash heater normal?(Resistance value : 20.5~21.5 - If above points are not found, the PCB assembly is out of order. Replace it. SAMSUNG ELECTRONICS CO., LTD...
B. Display shows ‘0000’ and the machine starts to measure the dropping time from 600 RPM to 100 RPM for 1minute. C. After setecting the amount of load, it display the data in a hex value. SAMSUNG ELECTRONICS CO., LTD...
1) Capacity : AC 230V/2500W 2) Location : Bottom of TUB 3) Function : Raise the water temperature Thermistor supplied at the wash process. 4) Resistance value : 20.5Ω ~ 21.5Ω 5) Thermo Fuse : 128°C SAMSUNG ELECTRONICS CO., LTD...
5) Part the diaphragm and the wire diaphragm away from the frame-front. 6) Remove the eight screws fixing the frame-front. 7) It’s possible to exchange and service the heater, the pump, the shock-absorber and the door lock s/w. LEVER SAMSUNG ELECTRONICS CO., LTD...
Page 13
4) Remove the motor. Motor Assemble Hole 5. How to Assemble the RELAY Housing. Relay <CAUTION> Insert the Relay Housing to the Relays on the opposite direation each other. RELAY Housing Heat Sink SAMSUNG ELECTRONICS CO., LTD...
17mm. Vice pliers Tool to protect the idle and abrasion of the bolt for the box driver. Other(Driver, Nipper, Long nose) General tools for the after service. JIG for the Tub 1 (Disassemble and Assemble) SAMSUNG ELECTRONICS CO., LTD...
