TECHNICAL MANUAL
T A B L E
I N S T A L L A T I O N S E C T I O N
PART
DESCRIPTION
1
2
2.1
UNPACKING AND INSPECTION ................................................... 2.1
2.2
KEY SERVICE UNIT INSTALLATION ............................................. 2.1
2.3
EXPANSION CABINET INSTALLATION ......................................... 2.1
2.4
GROUNDING ................................................................................ 2.2
2.5
MDF CABLING .............................................................................. 2.4
2.6
POWER CONNECTIONS .............................................................. 2.4
3
3.1
iDCS MEM3 CARD ........................................................................ 3.1
3.2
iDCS MEM4 CARD ........................................................................ 3.1
3.3
2 SLI CARD .................................................................................... 3.1
3.4
SMISC1 CARD ............................................................................... 3.1
3.5
SMISC2 CARD ............................................................................... 3.2
3.6
2 X 4 DLI CARD ............................................................................. 3.2
3.7
S8DLI CARD .................................................................................. 3.2
3.8
2 X 4 SLI CARD ............................................................................. 3.2
3.9
S8SLI CARD .................................................................................. 3.2
3.10
S3TRK CARD ................................................................................. 3.2
3.11
S6TRK CARD ................................................................................. 3.3
3.12
2 E&M 4 DLI CARD ........................................................................ 3.3
3.13
S4BRI CARD .................................................................................. 3.4
3.14
iDCS TEPRI CARD ......................................................................... 3.4
3.15
SPLL DAUGHTER BOARD ............................................................ 3.6
3.16
MODEM CARD .............................................................................. 3.6
3.17
ITMC .............................................................................................. 3.6
O F
C O N T E N T S
.................................................................... 1.1
INSTALLATION
TABLE OF CONTENTS JUNE 2002
PAGE
HOME
PAGE
Table of
Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iDCS 100 and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung iDCS 100

Summary of Contents for Samsung iDCS 100

  • Page 1: Table Of Contents

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL TABLE OF CONTENTS JUNE 2002 Table of Contents T A B L E C O N T E N T S I N S T A L L A T I O N S E C T I O N...
  • Page 2 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL TABLE OF CONTENTS JUNE 2002 Table of Contents POWER UP PROCEDURES CONNECT POWER TO THE SYSTEM .......... 4.1 iDCS MEM3 CARD INDICATIONS ..........4.1 iDCS MEM4 CARD INDICATIONS ..........4.2 PCB VERIFICATION ..............4.2 DEFAULT TRUNK AND STATION NUMBERING ......
  • Page 3 POWER FAILURE TRANSFER (PFT) ..........7.3 VOICE MAIL/AUTO ATTENDANT ..........7.3 7.10 CONNECTING SYSTEM BACKUP BATTERIES TO THE iDCS 100 POWER SUPPLY ..........7.4 INSTALLING KEYSET DAUGHTERBOARDS KDB DLI ..................8.1 KBD SLI ..................8.1 CONNECTING TO THE KDBS............8.1 CHANGING SOFTWARE REPLACING THE EPROMS ............
  • Page 4 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL TABLE OF CONTENTS JUNE 2002 Table of Contents 11.8 ADDING AN S4BRI CARD ............11.3 11.9 ADDING AN SPLL DAUGHTER BOARD........11.4 11.10 ADDING A MODEM CARD ............11.4 INSTALLING A SVMi-8 CARD 12.1...

  • Page 5: Installation Warnings

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL WARNINGS JUNE 2002 Table of Contents INSTALLATION WARNINGS SAFETY PRECAUTIONS To limit the risk of personal injury, always follow these precautions before connecting TELCO circuits: a. Never install telephone wiring during a lightning storm.
  • Page 6 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL WARNINGS JUNE 2002 Table of Contents a. Provided with the current limitations and maximum overcurrent ! ! ! ! protection for telecommunication circuits. b. Reference to the specific power supply or current limiting device provided with the product c.

  • Page 7: Site Requirements

    PART 1 JUNE 2002 Table of Contents PART 1. SITE REQUIREMENTS When planning the installation of the iDCS 100 choose a site that meets the following requirements: Select a location for the key service unit (KSU) that has enough space for easy...
  • Page 8 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 1 JUNE 2002 Table of Contents 14 3/8" 6.5" iDCS Digital 18 1/8" Communications System Expansion Cabinet 5 1/8" MAIN CABINET AND FIGURE 1–1 EXPANSION CABINET UNIT DIMENSIONS...

  • Page 9: Installation Of Basic Ksu And Expansion Cabinet

    2.1 UNPACKING AND INSPECTION After unpacking the KSU, inspect for signs of physical damage. If any damage is detected, do not attempt to install. Contact SAMSUNG TELECOMMUNICATIONS AMERICA, Technical Support Department. Check to see that the KSU carton includes the following items:...

  • Page 10: Grounding

    (see below) earth ground be connected to the system. This is the preferred method of grounding the iDCS 100. It has been observed that the third wire ground may be inferior or can contain noise that may prevent the digital data bus from canceling out noise. This may result in erratic operation of the iDCS 100.
  • Page 11 Again, a good earth ground source is required by the iDCS 100 system. The iDCS 100 system has two ground reference points. One point is via the green wire in the power cord connected to the AC power outlet. This ground connection is provided to meet local electrical codes when the AC ground is required to be common with the earth ground.

  • Page 12: Mdf Cabling

    National Electrical Code to the iDCS 100 system ground lug. This is a more secure ground connection, which can only be disconnected intentionally. These precautions are taken...
  • Page 13 • POWER SUPPLY UNIT (iDCS PWR) The iDCS PWR is the power supply for the iDCS 100 KSU. The iDCS PWR can accommodate a maximum of 48 keysets without an SVMi-8 and 40 keysets with an SVMi-8. The power supply is permanently installed in the KSU, and is protected by a metal cover.
  • Page 14 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 2 JUNE 2002 Table of Contents The -48VDC cable assembly has a male 2 pin connector on the iDCS PWR. Insert this end of the DC cable into the battery (BATT) connector found on the iDCS PWR...
  • Page 15 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 2 JUNE 2002 Table of Contents 12 7/8" 12" MDF SCREWS LOCATION FIGURE 2–1...
  • Page 16 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 2 JUNE 2002 Table of Contents WALL MOUNTING SCREWS WALL MOUNTING SCREWS KSU AND EXPANSION CABINET FIGURE 2–2A WALL MOUNTING...
  • Page 17 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 2 JUNE 2002 Table of Contents EXPANSION CABINET ATTACHMENT SCREWS EXPANSION CABINET FIGURE 2–2B MOUNTING...
  • Page 18 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 2 JUNE 2002 Table of Contents RED/GREEN CABLE RIBBON CABLE RED/GREEN CABLE RIBBON CABLE AND RED/GREEN FIGURE 2–3 CABLE PAIR CONNECTION EXPANSION CABINET TO KSU...
  • Page 19 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 2 JUNE 2002 Table of Contents GROUND WIRE EXPANSION CABINET FIGURE 2–4 GROUND WIRE TO KSU...
  • Page 20 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 2 JUNE 2002 Table of Contents GROUNDING BOTTOM VIEW FIGURE 2–5 KSU GND LUG...
  • Page 21 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 2 JUNE 2002 Table of Contents FIGURE 2–6 CONNECTOR DESIGNATOR...
  • Page 22 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 2 JUNE 2002 Table of Contents RESERVE POWER POWER SUPPLY BATTERY CONNECTOR BLACK CONNECT TO EITHER A OR B – – – – – – – – – – – – OPTION A –...

  • Page 23: Installing Printed Circuit Cards

    Contents PART 3. INSTALLING PRINTED CIRCUIT CARDS Unpack and inspect each card before installing. Check for signs of physical damage. If any damage is detected, do not attempt to install. Contact Samsung Technical Support immediately. 3.1 iDCS MEM3 CARD (Figure 3–2) Make sure that the BACK UP switch is in the OFF position.

  • Page 24: Smisc2 Card

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents 3.5 SMISC2 CARD (Figure 3–5) The Auto Attendant Message Memory backup switch should be turned ON to protect the customer-recorded messages in the event of a power failure. This can be done before or after the card is installed, as the switch is easily accessible.

  • Page 25: S6Trk Card

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents 3.11 S6TRK CARD (Figure 3–8) There are no options to select on this card. Insert the S6TRK card into any universal slot in the KSU or expansion cabinet (see Figure 3–1).

  • Page 26: S4Bri Card

    (Figure 3–11) Removing the Cover Before the iDCS TEPRI card can be installed in the iDCS 100 the card module must first be disassembled to allow the card to fit the slot. To disassemble the iDCS TEPRI card, first remove the ejector tabs by pulling them outward until they snap off. Next, to separate the two halves of the casing, remove the four screws and pull the two halves apart.
  • Page 27 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents iDCS TEPRI CARD DIP SWITCH Switch No. NFAS (24B) NFAS (23B + D) NETWORK USER NORMAL Switch 6 must be OFF Switch 7 must be OFF...

  • Page 28: Spll Daughter Board

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents 3.15 SPLL DAUGHTER BOARD (Figure 3–12) There are no options to select on this card. Insert the SPLL daughter board onto its connectors in the bottom left hand corner of the KSU motherboard (see Figure 3–13).
  • Page 29 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents KSU AND EXPANSION FIGURE 3–1 CABINET SLOT POSITIONS...
  • Page 30 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents iDCS MEM3 CARD FIGURE 3–2 iDCS MEM4 CARD FIGURE 3–3...
  • Page 31 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents 2 SLI CARD FIGURE 3–4...
  • Page 32 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents SMISC 1 AND 2 CARDS FIGURE 3–5...
  • Page 33 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents 2 X 4 DLI CARD AND S8DLI CARD FIGURE 3–6...
  • Page 34 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents 2 X 4 SLI CARD AND S8SLI CARD FIGURE 3–7...
  • Page 35 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents S3TRK CARD AND S6TRK CARD FIGURE 3–8...
  • Page 36 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents 2 E&M / 4 DLI CARD FIGURE 3–9...
  • Page 37 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents S4BRI CARD FIGURE 3–10...
  • Page 38 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents iDCS TEPRI CARD FIGURE 3–11...
  • Page 39 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents SPLL DAUGHTER BOARD FIGURE 3–12...
  • Page 40 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents SPLL DAUGHTER BOARD SPLL INSTALLATION ON FIGURE 3–13 KSU MOTHERBOARD...
  • Page 41 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents MODEM CARD FIGURE 3–14...
  • Page 42 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents MODEM CARD SMISC 1 OR 2 CARD MODEM CARD INSTALLATION ON FIGURE 3–15 SMISC CARD...
  • Page 43 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents ITMC CARD FIGURE 3–16...

  • Page 44: Power Up Procedures

    If this does not correct the problem, unplug the KSU and change power supplies. This in all probability will solve the problem. If it does not, contact Samsung Technical Support. 4.2 iDCS MEM3 CARD INDICATIONS Having verified proper operation of the power supply, visually check the iDCS MEM3 card indications.

  • Page 45: Idcs Mem4 Card Indications

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 4 JUNE 2002 Table of Contents 4.3 iDCS MEM4 CARD INDICATIONS Having verified proper operation of the power supply, visually check the iDCS MEM4 card indications. The LED indications are as follow:...

  • Page 46: Connecting Telco Circuits

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 5 JUNE 2002 Table of Contents PART 5. CONNECTING TELCO CIRCUITS 5.1 SAFETY PRECAUTIONS To limit the risk of personal injury, always follow these precautions before connecting TELCO circuits: a. Never install telephone wiring during a lightning storm.

  • Page 47: Isdn Bri Lines

    M lead of the other system and vice versa. 5.5 ISDN BRI LINES The iDCS 100 requires that an NT1 be connected between the iDCS 100 and the BRI circuit provided by the Telephone Company. This is necessary to convert the circuit from the U type 2 wire interface provided by the Telephone Company to an S/T type 4 wire interface used by the iDCS 100.
  • Page 48 INSTALLATION TECHNICAL MANUAL PART 5 JUNE 2002 Table of Contents PARAMETER OPTIONS IN iDCS 100 Framing type Super Frame (SF) or D4 Extended Super Frame (ESF) Coding type AMI or B8ZS The coding type must be set up in the system to match the T1 span and is contained in...
  • Page 49 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 5 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 FUNCTION CIRCUIT TERM COLOR C.O. TIP SLOT 1 W-BL C.O.
  • Page 50 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 5 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 FUNCTION CIRCUIT TERM COLOR C.O. TIP SLOT 1 W-BL C.O.
  • Page 51 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 5 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 FUNCTION CIRCUIT TERM COLOR C.O. TIP SLOT 1 W-BL C.O.
  • Page 52 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 5 JUNE 2002 Table of Contents 25 PAIR CABLE WITH CONNECTOR TO KSU P1 FUNCTION CIRCUIT TERM COLOR R-SL SLT TIP SLT RING SL-R SLT TIP BK-BL SLT RING BL-BK TELCO-PROVIDED NETWORK ACCESS JACK...
  • Page 53 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 5 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 FUNCTION CIRCUIT TERM COLOR C.O. TIP W-BL C.O. RING...
  • Page 54 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 5 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL TRANSMIT A BL-W...
  • Page 55 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 5 JUNE 2002 Table of Contents TRANSMIT PAIR RECEIVE PAIR CUSTOMER PROVIDED MALE RJ 45 ENDED CABLE CUSTOMER-PROVIDED CUSTOMER SERVICE UNIT TELCO T1 SPAN MDF CONNECTIONS FIGURE 5–7 T1/PRI CIRCUIT TO TEPRI CARD...

  • Page 56: Connecting Station Equipment

    (see Figures 6–1, 6–2, and 6-3). NOTE: Because the iDCS 100 is a self-configuring system, if you connect a 12 button keyset to a DLI port that previously had a 24 button keyset installed, the existing data will be rewritten with 12 button keyset default data (see MMC 723).

  • Page 57: Isdn Bri Stations

    WARNING: Do not attempt to connect commercial AC power to these contacts. 6.6 ISDN BRI STATIONS The iDCS 100 uses an S/T type interface so if the BRI station equipment requires a U type circuit then an NT1 must be connected between the iDCS 100 and the station equipment.

  • Page 58: B Wall-Mounting Keysets With Ultra Base Wedge

    It must be assigned to that station in 309. A maximum of four (4) 64 button modules can be programmed in the iDCS 100 system. A maximum of two (2) 64 button modules per keyset. 6.9 ATTACHING DCS 32 BUTTON AOM AND DCS 64...

  • Page 59: Attaching Idcs 64B Modules To An Idcs Keyset

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 6.10 ATTACHING iDCS 64B MODULES TO AN iDCS KEYSET First remove the base wedge from the iDCS 64B Module and attach the bracket to it with two of the screws provided (see Figure 6-20).
  • Page 60 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO KSU P1 COLOR TERM CIRCUIT FUNCTION W-BL DLI TIP BL-W DLI RING DLI TIP DLI RING ONE PAIR TWISTED...
  • Page 61 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL SLOT 1 DLI TIP...
  • Page 62 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL BL-W W-GN GN-W...
  • Page 63 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO KSU P1 COLOR TERM CIRCUIT FUNCTION W-BL DLI TIP BL-W DLI RING DLI TIP DLI RING ONE PAIR TWISTED...
  • Page 64 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL SLOT 1 DLI TIP...
  • Page 65 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL BL-W W-GN GN-W...
  • Page 66 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO KSU P1 COLOR TERM CIRCUIT FUNCTION R-SL SLT TIP SL-R SLT RING SLT TIP BK-BL ONE PAIR TWISTED SLT RING...
  • Page 67 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL SLOT 1 SLI TIP...
  • Page 68 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL BL-W W-GN GN-W...
  • Page 69 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO KSU P1 COLOR TERM CIRCUIT FUNCTION W-BL DLI TIP BL-W DLI RING DLI TIP DLI RING ONE PAIR TWISTED...
  • Page 70 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL SLOT 1 DLI TIP...
  • Page 71 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL BL-W W-GN GN-W...
  • Page 72 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION W-BL TRANSMIT A BL-W...
  • Page 73 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents HOLES FOR MOUNTING SCREWS NOTE: THE DIRECTORY CARD SLIDE TRAY IS NOT USED WHEN THE KEYSET IS WALL-MOUNTED. FIGURE 6-7 WALL-MOUNTING A KEYSET FIGURE 6–14...
  • Page 74 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents USED FOR ATTACHING AOM OR 64B MODULE WITH CONNECTOR CLIP HOLES FOR MOUNTING SCREWS NOTE: THE DIRECTORY CARD SLIDE TRAY IS NOT USED WHEN THE KEYSET IS WALL-MOUNTED.
  • Page 75 HOME PAGE IDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents WALL-MOUNTING FIGURE 6–16 FIGURE 6-7 AN iDCS KEYSET...
  • Page 76 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents FIGURE 6-7 ATTACHING 24B/12B TO 64BM FIGURE 6–17...
  • Page 77 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents ATTACHING 24B/12B TO AOM FIGURE 6–18...
  • Page 78 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents 7B / SINGLE LINE ULTRA BASE WEDGE AOM ULTRA BASE WEDGE METAL CONNECTOR CLIP 7B/SINGLE LINE ULTRA BASE WEDGE 64BM ULTRA BASE WEDGE METAL CONNECTOR CLIP...
  • Page 79 HOME PAGE IDCS 100 INSTALLATION TECHNICAL MANUAL PART 6 JUNE 2002 Table of Contents FIGURE 6-7 ATTACHING FIGURE 6–20 iDCS 64B MODULE TO AN iDCS KEYSET...

  • Page 80: Connecting Optional Equipment

    American Society of Composers, Authors and Publishers (ASCAP) or another similar organization if copyrighted music is transmitted through the Music on Hold feature. Samsung Telecommunications America, Inc. hereby disclaims any liability arising out of failure to obtain such a license.

  • Page 81: Common Bell

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents The SMISC card also provides a second independently controlled page output voice pair to be used with customer-provided paging equipment. Connect the customer provided paging equipment to the page 2 output pins of the P1 connecting block...

  • Page 82: Pc Programming

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents Use a pin to pin RS232C cable. Only pins 2, 3, 5 and 7 are required (see Figure 7–7). When the printer or optional call accounting device needs to be more than 15 feet away from the KSU, use shielded computer cable.

  • Page 83: Connecting System Backup Batteries To The Idcs 100 Power Supply

    7.10 CONNECTING SYSTEM BACKUP BATTERIES TO THE iDCS 100 POWER SUPPLY The iDCS 100 power supply contains a monitoring circuit to switch the system to customer provided 48VDC batteries when AC power is interrupted. Calls in progress are not disconnected. The power supply circuitry monitors and recharges batteries as needed.
  • Page 84 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO KSU P1 COLOR TERM CIRCUIT FUNCTION Y-BL MOH 1 - MOH 1 + BL-Y MOH 2 - MOH 2 +...
  • Page 85 HOME PAGE IDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents EXT INT SET SWITCH S1 TO INT FOR CHIMES TO BE HEARD ON PORT 371 SET SWITCH S1 TO EXT FOR AN EXTERNAL SOURCE TO BE HEARD ON PORT 371 SETTING JUMPER SWITCH S1 FIGURE 7–2...
  • Page 86 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO KSU P1 COLOR TERM CIRCUIT FUNCTION BK-S RELAY 1 + S-BK RELAY 1 – MUTE Y-BL MOH 1 + BL-Y MOH 1 –...
  • Page 87 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO KSU P1 CUSTOMER-PROVIDED PAGING AMPLIFIER COLOR TERM CIRCUIT FUNCTION BK-S RELAY 1 + S-BK RELAY 1 – Y-BL BL-Y...
  • Page 88 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO KSU P1 COLOR TERM CIRCUIT FUNCTION Y-BL MOH 1 + BL-Y MOH 1 – MOH 2 + MOH 2 –...
  • Page 89 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents SMISC 1 AND 2 CARDS FIGURE 7–6...
  • Page 90 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents SMISC CARD PRINTER RXD 2 TXD 3 GND 5 DTR 4 PIN CONNECTIONS FOR SMISC FIGURE 7–7 CARD TO PRINTER SMISC CARD COM 1 COM 2...
  • Page 91 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents 25 PAIR CABLE WITH MALE CONNECTOR TO BASIC P2 25 PAIR CABLE WITH MALE CONNECTOR TO EXPANSION P5 COLOR TERM CIRCUIT FUNCTION C.O. TIP W-BL SLOT 1...
  • Page 92 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents 25 PAIR CABLE TO KSU CIRCUIT FUNCTION SLT TIP SLT RING SLT TIP ONE PAIR TWISTED SLT RING SHEATHED STATION CABLE 24 OR 26 AWG CONNECT TO ANY CIRCUIT ON 2 SLI CARD, S8SLI CARD OR 2 X 4 SLI CARD.
  • Page 93 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 7 JUNE 2002 Table of Contents RESERVE POWER POWER SUPPLY BATTERY CONNECTOR BLACK CONNECT TO EITHER A OR B – – – – – – – – – – – – OPTION A –...

  • Page 94: Installing Keyset Daughterboards

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 8 JUNE 2002 Table of Contents PART 8. INSTALLING KEYSET DAUGHTERBOARDS 8.1 KDB DLI Before performing this procedure, the line cord must be unplugged from the keyset. The base wedge should then be removed, the keyset should be placed face down on a...
  • Page 95 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 8 JUNE 2002 Table of Contents RETAINING SCREWS RETAINING SCREWS KEYSET BASE FIGURE 8–1...
  • Page 96 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 8 JUNE 2002 Table of Contents MOUNTING SCREWS RIBBON CABLE CONNECTOR INSTALLING KDB FIGURE 8–2 DLI DAUGHTERBOARD...
  • Page 97 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 8 JUNE 2002 Table of Contents OUTPUT JACK KEYSET DAUGHTERBOARD FIGURE 8–3 OUTPUT JACK...
  • Page 98 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 8 JUNE 2002 Table of Contents HOOK PLUG RIBBON CABLE FROM DAUGHTERBOARD INTO RIBBON CABLE CONNECTOR P7 CONNECTING KEYSET FIGURE 8–4 DAUGHTERBOARD TO KEYSET PCB...
  • Page 99 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 8 JUNE 2002 Table of Contents RIBBON CABLE CONNECTOR MOUNTING SCREWS INSTALLING KDB FIGURE 8–5 SLI DAUGHTERBOARD...
  • Page 100 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 8 JUNE 2002 Table of Contents LINE CORD SCROLL OUTPUT JACK HOLD TRSF ANS/ OPER SECOND KEYSET FIRST KEYSET CONNECTING A KEYSET FIGURE 8–6 TO A KDB-DLI LINE CORD OUTPUT JACK SINGLE LINE TELEPHONE...
  • Page 101 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 8 JUNE 2002 Table of Contents CONNECTING A STATION DEVICE FIGURE 8–8 TO A KDB VIA THE MAIN DISTRIBUTION FRAME...

  • Page 102: Changing Software

    (see Figure 9–1). Remove the new EPROMS from their protective packaging and confirm that the legs on the EPROMS are straight. If the legs are not straight, contact Samsung Technical Support for assistance. Carefully insert the new EPROMS in their designated sockets.
  • Page 103 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 3 JUNE 2002 Table of Contents RESET LED1 D3 D2 D1 ODD2 EVN2 ODD1 EVN1 BAR CODE FIGURE 9–1 iDCS MEM3 CARD...

  • Page 104: Installing Caller Id

    PART 10. INSTALLING CALLER ID 10.1 GENERAL INFORMATION In order to install Caller ID on a iDCS 100, you must have the following pieces of iDCS 100 equipment available: A personal computer with the latest version of PCMMC for the iDCS 100 is recommended.
  • Page 105 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 10 JUNE 2002 Table of Contents MMC 119 CID DISPLAY This MMC is used by the end user to determine which piece of Caller ID data is displayed when a call rings at the user’s station.

  • Page 106: Adding Cards To An Existing System

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 11 JUNE 2002 Table of Contents PART 11. ADDING CARDS TO AN EXISTING SYSTEM 11.1 ADDING AN SMISC CARD 1. Check the battery switch on the MEM3 or MEM4 card and make sure it is ON.

  • Page 107: Adding An S3Trk Card

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 11 JUNE 2002 Table of Contents ITEM PORT NUMBER SLI PORT 1 SLI PORT 2 11.3 ADDING AN S3TRK CARD 1. Check the battery switch on the MEM3 or MEM4 card and make sure it is ON.

  • Page 108: Adding A 2 X 4 Card

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 11 JUNE 2002 Table of Contents 11.7 ADDING A 2 X 4 CARD 1. Check the battery switch on the MEM3 or MEM4 card and make sure it is ON. 2. Turn off power to the system and unplug the power cord.

  • Page 109: Adding An Spll Daughter Board

    HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 11 JUNE 2002 Table of Contents 11.9 ADDING AN SPLL DAUGHTER BOARD 1. Check the battery switch on the MEM3 or MEM4 card and make sure it is on. 2. Turn off power to the system and unplug the power cord.
  • Page 110 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 11 JUNE 2002 Table of Contents SPLL DAUGHTER BOARD SPLL INSTALLATION ON FIGURE 11–2 KSU MOTHERBOARD...
  • Page 111 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 11 FEBRUARY 2002 Table of Contents MODEM CARD MODEM CARD SMISC 1 OR 2 CARD MODEM CARD INSTALLATION ON FIGURE 11–3 SMISC CARD...

  • Page 112: Installing A Svmi-8 Card 12.1 System Size With Svmi-8

    8 keysets. This means that when a SVMi-8 card is installed in the iDCS 100 the system can now support a maximum of 32 (or 48 with SPSU2) station devices. This capacity includes keysets, any device connected to a keyset port, SLTs and keyset daughter boards.
  • Page 113 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 12 JUNE 2002 Table of Contents Power Supply. When you have done this then check the MEM3 or MEM4 card and ensure that the memory switch is in the ON position. Next turn the KSU off and remove the SVMi-8 card by gently pulling on the card.

  • Page 114: Installing A Svmi-4 Card

    13.2 UPGRADING THE SVMi-4 TO FOUR PORTS Before it will operate in the iDCS 100, the SVMi-4 must be upgraded to four ports as follows. Upgrading the SVMi-4 card basically means installing an upgrade key into its dedicated socket.
  • Page 115 HOME PAGE iDCS 100 INSTALLATION TECHNICAL MANUAL PART 13 JUNE 2002 Table of Contents Upgrade Key Socket SIO Port Compact Flash Socket Reset Button SVMi-4 CARD FIGURE 13–1...

Table of Contents
