Fastener Torque Values; Ottawa T2 Series 4X2 - Kalmar Ottawa t2 Maintenance Manual

page –
Component
Axle mounting:
Front axle clamp plate bolts
Rear axle clamp plate bolts:
Bolt head
Nut
Rear axle torque link bolts
Cab latch mounting bolts
Cab latch bar plate mounting bolts
Cab pivot pin retainer screws
Cab rear door roller capscrews
Cab suspension:
Assembly mounting bolts
Shock absorber mounting bolts
Cab tilt cylinder mounting bolts
Cab tilt pump mounting bolts
Cab tilt pump relief valve adjusting screw jam nut
Boom cylinder mounting:
Upper mount bolts
Lower mount bolts
Lower mount cross-bar locknuts
Boom pivot cross-bar bolts
Boom pump mounting bolts
Boom pump relief valve adjusting screw jam nut
Steering gear mounting bolts
Wheel lug nuts
0.4 Fastener Torque Values – F. Technical Data
0.4

Ottawa T2 Series 4x2

Following are the specified torque values required for sched-
uled maintenance operations and typical repair and/or adjust-
ment procedures covered in this manual.
Maintenance Manual Ottawa T2 4x2

Fastener Torque Values

Specified Torque Value
210 ft. lbs.
600 ft. lbs.
400 ft. lbs.
380 ft. lbs.
65 ft. lbs.
65 ft. lbs.
35 ft. lbs.
75 in. lbs.
220 ft. lbs.
100 ft. lbs.
200 ft. lbs.
77 in. lbs.
80 in. lbs.
55 ft. lbs.
55 ft. lbs.
600 ft. lbs.
380 ft. lbs.
55 ft. lbs.
15 ft. lbs.
350 ft. lbs.
450-500 ft. lbs.
251
285 Nm
813 Nm
542 Nm
515 Nm
88 Nm
88 Nm
47 Nm
8.5 Nm
298 Nm
136 Nm
271 Nm
8.7 Nm
9 Nm
75 Nm
75 Nm
813 Nm
515 Nm
75 Nm
20 Nm
475 Nm
610-678 Nm
