Collecting Information
IP:
Port 1 Netmask:
Management Access:
IP:
Port 2 Netmask:
Management Access:
IP:
Port 3 Netmask:
Management Access:
Configuring
Web-based Manager
Use the following procedure to connect to the web-based manager for the first time.
Configuration changes made with the web-based manager are effective immediately without
resetting the FortiAnalyzer unit or interrupting service.
To connect to the web-based manager
1. Connect the Port 1 interface of the FortiAnalyzer unit to Ethernet port of the manage-
ment computer.
Use a cross-over Ethernet cable to connect the devices directly. Use straight-through
Ethernet cables to connect the devices through a hub or switch.
2. Configure the management computer to be on the same subnet as the FortiAnalyzer
Port 1 interface.
To do this, change the IP address of the management computer to 192.168.1.2 and the
netmask to 255.255.255.0.
3. To access the FortiAnalyzer web-based manager, in your browser, go to
https://192.168.1.99 (remember to include the "s" in https://).
4. Type admin in the Name field and select Login.
After connecting to the Web-based manager, you can configure the FortiAnalyzer unit IP
address, DNS server IP address, and default gateway to connect the FortiAnalyzer unit to the
network.
To configure interfaces
1. Go to System > Network > Interface.
2. Select the edit icon for each interface to configure.
3. Set the IP address and netmask for the interface.
4. Select OK.
To configure the Primary and Secondary DNS server IP addresses
1. Go to System > Network > DNS, enter the Primary and Secondary DNS IP addresses
select Apply.
To configure a Default Gateway
1. Go to System > Network > Routing and select Create New.
2. Set Gateway to the Default Gateway IP address and select OK.
Adding an administration password
By default, the admin user does not have a password. To restrict access to the FortiAnalyzer
unit management account, add password for the admin user account.
To add the admin user account password
1. Go to System > Admin.
2. For the admin user, select the Change Password icon.
3. Enter a new password in the New Password box.
4. Reenter the password to Confirm Password box.
5. Select OK.
Training Services
Fortinet Training Services provides classes that orient you quickly to your new equipment, and certifications to verify your knowledge level. Fortinet provides a variety of training pro-
grams to serve the needs of our customers and partners world-wide.
To learn about the training services that Fortinet provides, visit the Fortinet Training Services web site at http://campus.training.fortinet.com.
____ . ____ . ____ . ____
____ . ____ . ____ . ____
____ . ____ . ____ . ____
____ . ____ . ____ . ____
____ . ____ . ____ . ____
____ . ____ . ____ . ____

Factory default settings

User name:
Administrator Account
Password:
IP:
Port 1
Netmask:
Management Access:
IP:
Port 2 Netmask:
Management Access:
IP:
Port 3 Netmask:
Management Access:
To reset the FortiAnalyzer unit to the factory defaults, in the CLI type the command
execute factory reset
Command Line Interface
The FortiAnalyzer unit has serial port. Use the null modem cable to connect it to your man-
agement computer.
To connect to the FortiAnalyzer unit
1. Use a RJ-45 to DB-9 cable to connect the FortiAnalyzer serial port to the management
computer serial port.
2. Start a terminal emulation program (such as HyperTerminal) on the management com-
puter. Use these settings: Baud Rate 9600, Data bits 8, Parity None, Stop bits 1, Flow
Control None.
3. At the login: prompt, type admin and press Enter twice.
(The login prompt is preceded by the server default host name.)
After connecting to the CLI, you can configure the FortiAnalyzer unit IP address, DNS server
IP address, and default gateway to connect the FortiAnalyzer unit to the network.
To configure the FortiAnalyzer unit using the CLI
1. Set the IP address and netmask of the Port1 interface.
config system interface
edit port1
set ip <intf_ip>/<netmask_ip>
end
2. Configure the primary and secondary DNS server IP addresses.
config system dns
set primary <dns-server_ip>
set secondary <dns-server_ip>
end
3. Configure the default gateway.
config system route
edit 1
set device <interface>
set dst <destination_ip>
set gateway <gateway_ip>
end
Shutting down the FortiAnalyzer unit
When powering off the FortiAnalyzer unit, always shut down the unit using the following pro-
cedures before disconnecting the power supply. Not following this procedure can increase
the risk of damaging the FortiAnalyzer hard disk.
To power off the FortiAnalyzer unit
1. Go to System > Dashboard.
2. In the System Operation list, select Shut Down.
3. Once the indicates the shut down procedure has completed, disconnect the
FortiAnalyzer unit from the power source.
Shutting down the FortiAnalyzer unit using the CLI
Enter the following command at the prompt:
execute shutdown
admin
(none)
192.168.1.99
255.255.255.0
ping, https, http, ssh
192.168.2.99
255.255.255.0
ping, https, http, ssh
192.168.3.99
255.255.255.0
ping, https, http, ssh
