5877 Relay Receiver - Installation Instructions

INTRODUCTION

The 5877 wireless relay module allows control of non-security system devices (such as a garage door opener) by using 5800 series
wireless keys or directly from a compatible control panel.
The module's LED can provide control panel system status if enabled to do so.
OPEN

PLUG IN 12VDC TRANSFORMER

MOUNT
IMPORTANT: If the control panel needs to be enrolled into the module, enroll
before mounting, and place the module near the control panel during the
enrollment process. After enrollment, verify the relay's operation at its
intended location before mounting it.
• Use the double-sided tape
(supplied) to mount the
module.
• Optional screws
(supplied) are
recommended.
NOTE: Mounting
screws must be
used in
installations
where
temperatures
can drop to
32° F (0° C)
or below.
