Digital Monitor AMC-1DBx Series User Manual
9. Press ENTER to navigate to the ethernet information. The bottom two lines of the
display will show the Ethernet MAC. The middle Ethernet Status area contains
other statistics and information including the IP Address, Subnet MASK, IP
Router address and BACnet UDP. The statistics include transmitted and received
octets and packets and counts for Unicast, multicast and broadcast. Additionally
received losses and unsent packets are counted. The middle Ethernet status
area is similar to the following:
AMC-1DB Gas Monitor 2.1
Display Log
IP Address:010.000.000.103
IP Subnet: 255.255.255.000
IP Router: 010.000.000.001
BACnet UDP Port:0xbac0
Octet Received:1434911
RX Packets:15168 Uni:0
RX Multi:0 Broad:15168
Loss no resources:0
Loss int. errors:0
Loss other reasons:0
Octet Sent:0
TX Packets:0 Uni:0
TX Multi:0 Broad:0
Unsent no resources:0
Unsent int. errors:0
Bad Destination:0
---------------------------------
Ethernet MAC:
4c:80:4f:00:00:00
