FeiYu Tech FY-41AP Lite Installation & Operation Manual page 18

NO. Setup instructions
1 Auto-control rudder surface reverse
2 Control gain
3 Ailerons
Elevator
4
Throttle
5
Rudder
6
7 Three-switch mode selection
8 FY-41AP Lite install setting
9 Cruising speed setting
Method two:
Setting FY-41AP Lite via "FYGCS 5.11 for 41&DOS" software
1 ) Please visit the official website: www.feiyu-tech.com. Download the newest setting
software "FYGCS 5.11 for 41&DOS" and the USB driver at the download page which
related to FY–41AP Lite products.
2 ) After successfully install the USB driver, insert the USB-TTL interface cable into
computer USB COM port(don't connect TTL port to any other device ) , the system will
correctly identify the USB -TTL data cable, then you will find there is more than one
port(COM and LPT), the port COM6 in the "Silicon Labs CP210x USB to UART Bridge
(COM6)" is the Virtual serial number.
Inserter a few times for confirmation the virtual serial number. After that, you can use
the new USB data cable normally.
3 ) Install the software
for setting up and configuring FY-41AP Lite also included other functions. For example,
Electronic mapping, Telemetry data monitoring of flight parameters, Flight attitude, Flight
speed, Altimeter, Location, Recording and Playback of telemetry data into Ground
Control Station, Map loading ,etc .
a) Double-click "
b) After installation, double-click "
you can see the following interface.
http://www.feiyu-tech.com
Guilin Feiyu Technology Incorporated Company.
"FYGCS 5.11 for
41&DOS". The software in addition to can use
Page 16
NO. Setup instructions
10 Circling radius setting
11 Farthest flight distance setting
12 Airspeed adjust setting
Rudder mixing mode
13
Initialize gyroscope
14
Initialize airspeed sensor
15
16 Save the settings
17 Exit the Settings interface
" installed by default.
" to open the FYGCS5.11 software,
