3 to 47 (GP63)
4 to 45 (GP64)
5 to 44 (GP65)
6 to 43 (GP66)
7 to 42 (GP67)
8 is GND
Embedded Box PC 5000 IO Module PCIe expansion mapping
The PCIe slots on the Embedded Box PC are driven directly from the host PCIe bus. Since it is a generic PCIe expansion, there are
no PCIe device-specific drivers integrated into the Windows 10 Pro OS image. If there is a specific PCIe card used on this slot,
contact the Vendor of that PCIe card to verify if they have Windows 10 Pro drivers.

Windows 10 IoT Enterprise LTSB 2015

Overview
The Embedded Box PC is shipped with Windows 10 IoT Enterprise LTSB 2015. For more information on Windows operating system,
see https://support.microsoft.com/en-us.
Boot up and login
Before configuring the Windows 10 IoT Enterprise LTSB 2015, connect a keyboard, mouse, and monitor to the Embedded Box PC.
1. Turn on the Embedded Box PC and login to Windows.
2. Select regional settings.
3. Select your preferred settings.
4. Create a User Account.
NOTE: Connect to a wireless network if available.
Restoring Windows 10 IoT Enterprise LTSB 2015
Using the recovery OS image on the Boot partition, restore Windows 10 IoT Enterprise LTSB 2015 on the Embedded Box PC to the
factory image.
Before starting the Windows 10 IoT Enterprise LTSB 2015 restore process, connect a keyboard, mouse, and monitor to the
Embedded Box PC:
1. Boot to the desktop.
2. Click the start icon and power icon.
3. Press and hold the Shift key and click Restart.
The system will Boot into the recovery console.
4. Select Troubleshoot.
5. Select Factory Image Restore.
6. Select Next.
Wait until the default factory image is installed on the system.
7. Select Finish.
Windows 10 IoT Enterprise LTSB 2015 basic functions
BIOS update
Download the latest BIOS version from www.dell.com/support. Run the executable in the download package from the local machine.
31
