- Page 1 Electricity Meters Residential BS / IEC British Standard 5235 Single Phase Credit Meter User Manual & Technical Specification Date: 20/11/08 Filename: 5235 User Manual Q P u l s e N o : I B 0 4 7 © Landis+Gyr...
-
Page 2: Revision History
The material in this document is the property of Landis+Gyr. Our products are under continual improvement and we reserve the right to make changes without prior notice Landis+Gyr 1 Lysander Drive, Northfields Industrial Estate, Market Deeping, Peterborough PE6 8FB www.landisgyr.com 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... -
Page 3: Table Of Contents
Operating Faults _________________________________________________________ 18 Disconnecting the Meter ___________________________________________________ 18 Repairing the Meter _______________________________________________________ 18 Decommissioning and Disposal __________________________________________ 20 Glossary of Terms and Standards ________________________________________ 21 10.1 Acronyms _______________________________________________________________ 21 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... - Page 4 Page 4 of 21 Issue: 4 5 Table of Contents 10.2 Measurement Units ______________________________________________________ 21 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr...
-
Page 5: Introduction
Introduction Introducing the 5235, single and multi-rate tariff options, Single Phase BS Standard Credit Meter Purpose This document details the functions for the following variants of the 5235 Single Phase Credit Meters, active energy only. Single Rate, kWh meter ... - Page 6 OFGEM. This modelling has shown a reliability of better than 97% over twenty years. The OFGEM approval number for this meter is 986. OFGEM certificates and lifetime reports are available upon request. Please contact sales@landisgyr.com 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr...
-
Page 7: Safety Information
This equipment does not contain a disconnection device. Means for disconnection from the supply must be provided as part of the building installation. Do not work on the equipment unless the 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... - Page 8 The meters must on no account be cleaned with running water or with high-pressure devices. Water penetrating can cause short- circuits. The meter terminal cover should be secured in place before any load is supplied. 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr...
-
Page 9: Operational Functions
Reverse Energy Detection A configurable option within the meter will alternate a warning message on the display should a fraud attempt be made by running current backwards 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... - Page 10 The user applies a magnet to the outside of the meter case and the meter powers up for 20 to 30 seconds. During this time the meter displays the sign on and then displays the energy registers. 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr...
-
Page 11: User Interfaces
The configuration is factory set allowing the meter to operate as a single or two rate meter. Rate switching is achieved by switching neutral or live to the input terminal. See wiring diagram for the D model. 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... - Page 12 Page 12 of 21 Issue: 45 User Interfaces 5235D-L Live switching model 5235D-N Neutral switching model 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr...
-
Page 13: Installation
Meter Element Supply Load Meter type 5235 A and F Meter Element Supply Load Meter type 5235 B 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... - Page 14 Issue: 45 Installation Meter Element Time switch Supply Load Meter type 5235 D - N Meter Element Time switch Supply Load Meter type 5235 D – L 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr...
-
Page 15: Technical Summary
Extended Terminal Cover 338g Dimensions (mm) Standard Terminal Cover H 80 x W 125 x D 36 Extended Terminal Cover H 113 x W 126 x D 41 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... -
Page 16: Dimensions
Page 16 of 21 Issue: 45 Technical Summary Dimensions 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... -
Page 17: Maintenance And Service
It is beyond the scope of this manual to describe in any further detail the procedure. Landis+Gyr sales team would be happy to discuss specific requirements. 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... -
Page 18: Measures In The Event Of Faults
Attach a label, which describes the fault as accurately as possible, to the meter and include name and contact details of person responsible in case of inquiries. 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... - Page 19 Issue: 4 5 Page 19 of 21 Package the meter to ensure no further damage can occur during transit. Send the meter back to Landis+Gyr. 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr...
-
Page 20: Decommissioning And Disposal
Treated as per disposal of Electronic Equipment Metal Components Sorted and delivered to collective recycling point Plastic Components Sorted and delivered for re-granulation if at all possible 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr... -
Page 21: Glossary Of Terms And Standards
(unit of distance) milliohm (unit of resistance) millisecond Newton meter (unit of torque) Degree Celsius (unit of temperature) Rated supply voltage of meter Rated external switch voltage Volt 5235 Single Phase Credit Meter – User Manual & Technical Specification © Landis+Gyr...
