Features These air conditioners are equipped with cooling function. Details on this function are provided below; refer to these descriptions when using the air conditioner. Microprocessor Controlled Operation Air Sweep Control • • The interior compartment of the remote control This function moves a flap up and down in the unit contains several features to facilitate air outlet, directing air in a sweeping motion...
Contents Page Features........................2 Product Information ....................3 Alert Symbols ......................3 Installation Location....................4 Electrical Requirements ..................4 Safety Instructions ....................4 Names of Parts ...................... 5 Using the Remote Control Unit ................. 11 Operation with the Remote Control Unit............13 1.
Installation Location We recommend that this air conditioner be installed properly by • qualified installation technicians in accordance with the Installation Instructions provided with the unit. Before installation, check that the voltage of the electric supply in your • home or office is the same as the voltage shown on the nameplate. Do not install this air conditioner where there are fumes or flammable •...
Names of Parts Each air conditioner as shown below consists of an indoor unit and an outdoor unit. You can control the air conditioner with the remote control unit. Ceiling mounted type Recessed type Air outlet intake Air intake Air outlet Drain tube Drain tube Remote...
Page 6
Unit Display and Operation Selector Recessed type Ceiling mounted type OPERATION TIMER Remote control lamp lamp receiver Recessed type Ceiling mounted type Operation selector Finger-hold Air intake grille Air intake grille Air filter Operation selector OI-201-06EG Downloaded from www.Manualslib.com manuals search engine...
Page 7
Unit Display and Operation Selector (continued) INDOOR UNIT REMOTE CONTROL receiver OPERATION lamp Operation selector TIMER lamp REMOTE CONTROL This section picks up infrared signals from the remote control unit receiver (transmitter). Operation selector ON position This position is for operating the air conditioner with the wireless remote control unit.
Page 8
Remote Control Unit (Display) Displayed when main unit sensor is in use Displayed when setting temperature SET TEMP Displayed when transmitting data Displayed when temperature is shown Displayed when the temperature setting is at the upper or lower allowable limit Displayed when setting timer Symbols (3) Set temperature...
Remote Control Unit AIR CONDITIONER Sensor Transmitter AIR CONDITIONER SET TEMP Display (Cover closed) 1HR. TIMER TEMP. 1 HR. TIMER button TEMP. setting buttons ON I /OFF ON/OFF operation button NIGHT NIGHT SETBACK button MODE selector button SETBACK MODE CLOCK Program button TIMER FLAP...
Page 10
Remote Control Unit (continued) PROGRAM button For details, see ‘‘Setting the Timer’’. Press this button to select the mode you want to program. TIMER SELECT button No display : The timer does not operate. : The air conditioner stops at the set time. : The air conditioner starts at the set time.
Using the Remote Control Unit How to Install Batteries ACL button 1. Slide the cover in the direction indicated by the arrow and remove 2. Install two AAA alkaline batteries. Make sure the batteries point in the direction marked in the battery compartment.
Page 12
Using the Remote Control Unit (continued) Mounting the Remote Control Unit Removable mounting Non-removable mounting Wall Wall (Packed in the indoor unit) (Packed in the indoor unit) Mounting on a wall A. Removable mounting 1) Momentarily hold the remote control unit at the desired mounting position.
Operation with the Remote Control Unit 1. Operation AIR CONDITIONER 1HR. TEMP. TIMER STEP 3 ON I /OFF STEP 2 NIGHT SETBACK MODE CLOCK STEP 1 FLAP TIMER STEP 5 SELECT FAN SPEED STEP 4 TIME SET SELECT SENSOR BATTERIES Check that the circuit breaker on the power panel is turned on and that the NOTE operation selector of the indoor unit is in the ON position.
Operation with the Remote Control Unit (continued) Choose the best position in the room for the remote control unit, which • NOTE also acts as the sensor for room comfort and transmits the operating instructions. Once you’ve found this best position, always keep the remote control unit there.
Operation with the Remote Control Unit (continued) 4. Night Setback Mode AIR CONDITIONER 1HR. TEMP. TIMER ON I /OFF NIGHT SETBACK MODE CLOCK FLAP TIMER SELECT FAN SPEED Night Setback Mode is used for saving energy. Press the NIGHT SETBACK button while operation. mark appears in the display.
Special Remarks In the event of power failure, the unit will stop. When the power is • Power failure resumed, the unit will restart automatically after three minutes. during operation The remote control unit sends the setting condition to the air •...
Setting the Timer ON I /OFF NIGHT SETBACK MODE CLOCK FLAP TIMER SELECT FAN SPEED TIME SET SELECT SENSOR BATTERIES 1. How to set the (Example) To set to 9:10 p.m. present time Operation Indication 1. Press the Program button ( ) three The time indication alone CLOCK...
Page 18
Setting the Timer (continued) 3. How to set the ON time (Example) When air conditioner is off, starting operation at 7:10 a.m. Operation Indication 1. Press the Program button ( ) twice. The timer ON and time CLOCK indications flash. The display will change Press the HH button...
Using the 1-Hour OFF Timer 1. 1-Hour OFF Timer This function causes the unit to operate for one hour and then stop, regardless of whether the unit is on or off when this button is pressed. indicator in the display indicates that this function is operating. Setting procedure: Regardless of whether the unit is operating or stopped, press the 1 HR.
Adjusting the Airflow Direction A. Horizontal (Wall mounted type only) The horizontal airflow can be adjusted by moving the vertical vane to the left or right. Indoor unit (Wall mounted type) Left Right Vertical vane B. Vertical Confirm that the remote control unit has been turned on. Press the FLAP 30°...
Care and Cleaning 1. For safety, be sure to turn the air conditioner off and also to disconnect the power before cleaning. 2. Do not pour water or spray detergent on the indoor unit to clean it. This will damage the internal components and may cause an electric shock or fire.
Page 22
Care and Cleaning (continued) How to remove the filter Ceiling mounted type: 1. Remove the bolt screws on the latch using a screwdriver. (After cleaning, be sure to reattach the two bolt screws.) 2. Take hold of two latches on the air intake grille and press it to the rear, and the grille will open downward.
Troubleshooting If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or service center. Trouble Possible Cause Remedy Air conditioner does not 1. Power failure. 1.
Page 24
In Canada SANYO FISHER COMPANY SANYO Canada Inc. A DIVISION OF SANYO NORTH AMERICA CORPORATION 50 Beth Nealson Drive 21605 Plummer Street Toronto, Ontario, Chatsworth, CA 91311 U.S.A. M4H 1M6, Canada Downloaded from www.Manualslib.com manuals search engine...
