ENG
Thank you for purchasing this PENTAX
Digital Camera.
When you use this camera for the first time, it
is recommended you read this Quick Guide
first in order to gain a feel for the basic
operation of the camera. Refer to the
separately supplied "Operating Manual" for
further explanation of functions and
advanced operations of the camera.
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X5 and is the answer not in the manual?

Questions and answers

Related Manuals for Pentax X5

Summary of Contents for Pentax X5

  • Page 1 Thank you for purchasing this PENTAX Digital Camera. When you use this camera for the first time, it is recommended you read this Quick Guide first in order to gain a feel for the basic operation of the camera. Refer to the separately supplied “Operating Manual”...
  • Page 2 To users of this camera • Do not use or store this device in the vicinity of equipment that generates strong electromagnetic radiation or magnetic fields. Strong static charges or the magnetic fields produced by equipment such as radio transmitters could interfere with the display, damage the stored data, or affect the product’s internal circuitry and cause camera misoperation.

  • Page 3: Using Your Camera Safely

    • If any irregularities occur during use, such as smoke or a strange odor, stop use immediately, remove the batteries, and contact your nearest PENTAX Service Center. Continuing to use the camera can cause a fire or electric shock. Caution •...
  • Page 4 PENTAX Service Center. Continuing to use the adapter can cause a fire or electric shock. • If water should happen to get inside the AC adapter, consult a PENTAX Service Center. Continuing to use the adapter can cause a fire or electric shock.

  • Page 5: About The Batteries

    • Do not touch or short-circuit the terminal area of the AC plug cord while the cord is plugged in. • Do not handle the power plug with wet hands. This can cause an electric shock. • Do not drop the AC adapter, or subject it to violent impact. This can cause equipment breakdown.
  • Page 6 • The batteries should be inserted correctly, observing (+) and (-) marks on the batteries. Inserting the batteries incorrectly may cause an explosion or fire. • Remove the batteries from the camera immediately if they become hot or begin to smoke. Be careful not to burn yourself during removal. •...

  • Page 7: Care To Be Taken During Handling

    If the camera is subjected to substantial vibrations, shocks or pressure, take your camera to your nearest PENTAX Service Center and have it checked. • The temperature range for camera use is 0°C to 40°C (32°F to 104°F).

  • Page 8: Cleaning Your Camera

    • Do not press the display with excessive force. This could cause it to break or malfunction. • Be careful not to overtighten the tripod screw when using a tripod. Cleaning Your Camera • Do not clean the camera with organic solvents such as thinner, alcohol or benzine.
  • Page 9 • When purchasing an SD Memory Card, check if it has been tested or not on the PENTAX website or the PENTAX Service Center. • Be sure to format SD Memory Cards that are unused or have been used on another camera.

  • Page 10: Checking The Contents Of The Package

    Checking the Contents of the Package Check that your camera came complete with the items listed below. P Camera (X-5) P Lens cap (O-LC129) P Strap (O-ST92) P Software (CD-ROM) S-SW129 P Four AA alkaline batteries P USB cable (I-USB7) P Operating Manual O Quick Guide (this guide)
  • Page 11 Names of Parts and Monitor Indicators Front Flash Strap lug b button 4 button Switches between the display on the back of the camera and the Back viewfinder. Mode dial Zoom lever Shutter release button Power button e-dial Q button Four-way controller Viewfinder Display...

  • Page 12: Battery Level Indicator

    Monitor Indicators Following indicators are displayed in the still picture capture mode. Normal Display in the Still Picture Capture Mode Digital Zoom/Intelligent Zoom Memory status Eye-Fi communication status Built-in memory Focus mode (without card) SD Memory Card Drive mode Card is write-protected Flash mode Shooting 38 38...

  • Page 13: Preparing The Camera For Use

    Preparing the Camera for Use Attaching the Lens Cap and Strap * For instructions, refer to the Operating Manual. Installing the Batteries and SD Memory Card Install the batteries and SD Memory Card as shown in the illustration. Battery/card cover lock lever Battery/ card cover...

  • Page 14: Turning The Camera On

    Turning the Camera On Remove the Lens Cap and Press the Power Button. The camera turns on and is ready to take still pictures. Press the power button again to turn the camera off. Make the Initial Settings. The [Language/ ] screen appears when the camera is turned on for the first time.
  • Page 15 Memo If you accidentally select the wrong Initial Setting language and press the 4 button, press the four-way controller (5), use English the four-way controller (2345) to Hometown select the desired language, and then New York press the 4 button. The [Initial Setting] Settings complete screen appears in the selected language.

  • Page 16: Formatting An Sd Memory Card

    Press the four-way controller (5) Date Adjustment to move the frame to [mm/dd/yy], then use the four-way controller mm/dd/yy Date Format (23) to choose the date format. 01/01/2012 Date 00:00 Time Press the four-way controller (5) Settings complete to move the frame to [24h], then Cancel MENU use the four-way controller (23)

  • Page 17: Taking Pictures

    Taking Pictures Once the camera is ready for use, you can start taking pictures. Holding the Camera Horizontal position Vertical position To prevent camera shake, hold the camera firmly with both hands so the camera does not shake when the shutter release button is pressed. This camera features Shake Reduction function that makes it possible to reduce blur when taking pictures without the use of a tripod or other support.

  • Page 18: Letting The Camera Choose The Optimal Settings

    Letting the Camera Choose the Optimal Settings This camera is equipped with a variety of functions. First, try to take pictures using the simplest shooting mode. Set the mode dial to In b (Auto Picture) mode, the camera selects the optimal shooting mode for the subject.

  • Page 19: Selecting The Flash Mode

    Press the shutter release button 38 38 38 fully. The picture is taken. 09/09/2012 09/09/2012 09/09/2012 1/250 1/250 1/250 F4.6 F4.6 F4.6 14:25 14:25 14:25 Selecting the Flash Mode Press the b button to pop up the flash, then press the four-way controller (4).

  • Page 20: Selecting The Drive Mode

    Selecting the Drive Mode Press the four-way controller (2). Each press of the four-way controller (5) on the Drive Mode selection screen switches modes in the following order. Some modes may be unavailable depending on the capture mode. Standard (single-frame) Continuous Shooting Burst Shooting (L) Burst Shooting (H)

  • Page 21: Selecting The Focus Mode

    Selecting the Focus Mode Press the four-way controller (5). Each press of the four-way controller (5) on the Focus Mode selection screen switches modes in the following order. Some modes may be unavailable depending on the capture mode. Standard Macro 1cm Macro Infinity Manual Focus...

  • Page 22: Selecting A Shooting Mode

    Selecting a Shooting Mode You can choose the appropriate mode for your particular situation from the Capture Mode Palette. Set the mode dial to H Surf & Snow Surf & Snow and press the four-way controller (3). Use the four-way controller (2345) to choose a shooting mode, For bright images such as...

  • Page 23: Deleting Images

    You can play back the captured images on the display. Press the Q button after shooting. 100 - 0038 100 - 0038 0038 The image appears on the display. 09/09/2012 09/09/2012 09/09/2012 14:25 14:25 14:25 Edit Edit Memo • To play back the previous or next image, press the four-way controller (45).

  • Page 24: Playing Back Images

    Playing Back Images Press the 4 button. Memo • You can delete several images selected from the four-/nine-image display. • You can delete all images at once. • You can protect stored images from being accidentally deleted. Selecting a Playback Mode You can choose the playback function you want to use from the Playback Mode Palette.
  • Page 25 For details about how to use the X-5, refer to the Operating Manual. X-5 Operating Manual...
  • Page 26 Information for Users on Collection and Disposal of Old Equipment and Used Batteries 1. In the European Union These symbols on the products, packaging and/or accompanying documents mean that used electrical and electronic equipment and batteries should not be mixed with general household waste. Used electrical/electronic equipment and batteries must be treated separately and in accordance with legislation that requires proper treatment, recovery and recycling of these products.
  • Page 28 23D, Jun Yao International Plaza, 789 Zhaojiabang CHINA CO., LTD. Road, Xu Hui District, Shanghai, 200032, CHINA (http://www.pentax.com.cn) http://www.pentax.jp/english • Specifications and external dimensions are subject to change without notice. OPX500171/ENG Copyright © PENTAX RICOH IMAGING CO., LTD. 2012 FOM 01.09.2012 Printed in Europe...
