INSTALLATION GUIDE
CRYSTAL SERIES 460X
Case Specifications
Length: ...................................................................................................... 440mm
Width: ....................................................................................................... 220mm
Height: ...................................................................................................... 464mm
Maximum GPU length: ....................................................................... 370mm
Maximum CPU cooler height: ......................................................... 170mm
Maximum PSU length: ........................................................................ 200mm
Fan locations:
Front: .........................................................................2 x 140/3 x 120mm
Top: ....................................................................................2 x 140/120mm
Rear: ................................................................................................... 120mm
Radiator compatibility:
Front: ............................................................................... 280mm/360mm
Top: ..................................................................................................... 240mm
Rear: ................................................................................................... 120mm
220mm
440mm
Advertisement
Table of Contents
Related Manuals for Corsair 460X
Summary of Contents for Corsair 460X
- Page 1 CRYSTAL SERIES 460X Case Specifications Length: ...................... 440mm Width: ....................... 220mm Height: ...................... 464mm Maximum GPU length: ............... 370mm Maximum CPU cooler height: ............170mm Maximum PSU length: ................ 200mm Fan locations: Front: .................2 x 140/3 x 120mm Top: ..................2 x 140/120mm Rear: ....................
- Page 2 Dust filters Top cover Front I/O Panel (x2 USB 3.0, Headphone, Mic, Power, and Reset) (x7) Expansion slots Removable tempered glass front fascia (x3) SP120 RGB LED fans (460X - RGB) SSD pan head Short fan screws Long fan screws screws...
- Page 3 CRYSTAL SERIES 460X 1. Removing the Side Panels 3. Installing HDDs Remove the thumb screws Step 1 – Place the drive into and pull the side panel off. the 3.5” drive tray. Step 1 Step 2 – Slide the drive...
- Page 4 CRYSTAL SERIES 460X 5. Installing the Power Supply 7. Removing the Front Fascia Install the PSU into the Unscrew the front panel, then lower chamber of the case, gently but firmly pull away from and secure with four screws the chassis.
- Page 5 CRYSTAL SERIES 460X 9. Using RGB Fan Controller (460X - RGB) Frequently Asked Questions 1. Does the polarity matter with the I/O panel’s power See included RGB Fan controller Quick Start Guide for detailed instructions. and reset header? No, only the LED headers.
