  • Page 1 THERA-TRAINER TIGO THERA-VITAL / THERA-LIVE) USER MANUAL English translation of original user manual...
  • Page 2 „Made in Germany“. This user manual will help you get to know your THERA-Trainer better. It will safely guide you through all functions and control options and provide you with tips and information on how to use your new exerciser best.

  • Page 3: Table Of Contents

    STARTING UP THE THERA-TRAINER TIGO ........
  • Page 4 21.7 Recommended protective distances between portable and mobile HF telecommunication devices and THERA-Trainer tigo ......112 WARRANTY ..............112 Art.

  • Page 5: User Guide

    THERA-TRAINER TIGO USER MANUAL USER GUIDE User manual and product are labelled with symbols. The symbols and their func- tions make it easier to use the product safely and efficiently. 1.1 Warning notices Classification of warning notices There are different types of warning notices indicated by the following signal words depending on the type of danger: Caution warns about the risk of material damage.

  • Page 6: Symbols On The Product

    THERA-TRAINER TIGO USER MANUAL 1.4 Symbols on the product User manual Danger due to movable parts Observe the user manual! The THERA-Trainer tigo uses alternating current Manufacturer Protection class II device Date of manufacture Note on damage due to static charging...

  • Page 7: Safety And Dangers

    Do not use THERA-Trainer tigo in wet, humid or hot environment. Have exclusively trained dealers do any repair work. In case of damage, malfunctions, etc. of the THERA-Trainer tigo, contact a trained dealer immediately. Consult the manufacturer before any modification and modify THERA-Trainer tigo exclusively with the manufacturer's approval.
  • Page 8 THERA-TRAINER TIGO USER MANUAL Leave THERA-Trainer tigo at room temperature for 1 hour before using it for the first time. Transport THERA-Trainer tigo exclusively with transport castors on even and stable floors. For safe use of the THERA-Trainer tigo, use self-operated tip-up protection.

  • Page 9: Intended Use

    THERA-TRAINER TIGO USER MANUAL INTENDED USE The THERA-Trainer tigo is a therapy device for improving the mobility of persons whose mobility is limited. The THERA-Trainer tigo is suitable: as an exerciser for the legs or the upper body. for passive (motor-supported) and active (with muscle power) movement training, and for active and passive muscle training in combination.

  • Page 10: Instruction

    Have a dealer, doctor or therapist trained by the manufacturer instruct the assistant. 3.3 Biocompatibility All components and options of the THERA-Trainer tigo the user will touch when using the unit as intended are designed to meet the biocompatibility requirements of the applicable standards.

  • Page 11: Foreseeable Misuse

    For users with a short upper body or a low seated height, it might be necessary to Note use an appropriate configuration of the THERA-Trainer tigo. Before starting the training, consult a doctor, therapist or trained dealer. For users with a body weight of more than 120 kg it is necessary to use special accessories for the THERA-Trainer tigo after consultation with the manufacturer or the trained dealer.

  • Page 12: Scope Of Delivery And Description Of Delivered Equipment

    THERA-Trainer tigo. Depending on the model, the user manual may include options not featured by the THERA-Trainer tigo. If the THERA-Trainer tigo features options not described in the user manual, an appendix will be included. 6.1 Contents of delivery The delivery note contains all necessary information on the scope of delivery.

  • Page 13: Removable Parts

    THERA-TRAINER TIGO USER MANUAL 6.4 Removable parts Removable parts of the THERA-Trainer tigo: Name Article no. Leg support A001-428 Cushion of leg support A001-074 Velcro for leg support 40000553- Velcro for foot rest 40000552- 40000555- Cushion of foot fixing A001-073...
  • Page 14 THERA-TRAINER TIGO USER MANUAL Name Article no. Wristbands for arm rests with bar- A001-427 shaped grips Arm rests for therapy grips A003-724 Wristbands for therapy grips/ A002-440 safety handle Control and display unit with 10.4" A001-423 colour screen incl. touch function Control and display unit with 5.7"...
  • Page 15 THERA-TRAINER TIGO USER MANUAL Name Article no. Printer for training documentation A000-105 Chest belt of cardio-pulse-set A000-559 Main cable: EU H05VV-F 3x0.75mm² 55000024- length=2m Australia H05VV-F 3x0.75mm² A000-956 length=2m USA Hospital Grade SJT 55000281- 3xAWG 18, length=3m CH H05VV-F 3x0.75mm²...

  • Page 16: Model Overview

    THERA-TRAINER TIGO USER MANUAL 6.5 Model overview Basic functio- Type over- Serial num- Serial num- Serial num- Available Available nality view, ber range ber range ber range control and upper body name on type display unit exercise plate 230 V...

  • Page 17: Overview

    THERA-TRAINER TIGO USER MANUAL OVERVIEW (1) Therapy grips (2) Crank (application part Type BF) (3) Upper body exerciser (4) Control and display unit with 10.4" colour screen incl. touch function (5) USB-interface (6) Locking-pin for height adjustment of safety handle/upper body exerciser...

  • Page 18: User Section

    THERA-TRAINER TIGO USER MANUAL USER SECTION Note The user section addresses the user and describes how to use the THERA-Trainer tigo. Art. no.: A002-629_Rev 0 Last update: CW 3/201...

  • Page 19: Training Requirements

    Undergo instruction from trained dealer. Read the user manual. Position THERA-Trainer tigo so that power plug is easily accessible and can be pulled out of socket outlet quickly in case of emergency. Have a doctor or therapist compile a training schedule.

  • Page 20: Fields Of Use

    THERA-TRAINER TIGO USER MANUAL 8.1 Fields of use Use THERA-Trainer tigo as: leg exerciser upper body exerciser THERA-Trainer tigo is especially recommended for: multiple sclerosis (MS) stroke, hemiplegia, apoplexy paraplegia, tetraplegia, bifid spine Parkinson's disease cerebrocranial trauma muscular diseases such as muscular dystrophy...

  • Page 21: Active And Passive Training

    Speed demand: – A certain number of revolutions is set which the THERA-Trainer tigo will keep constant during the entire training session. The user effects a per- formance by active pedalling. Coordinating the speed of the foot rests is not necessary.

  • Page 22: Starting Up The Thera-Trainer Tigo

    To switch on the THERA-Trainer tigo: Plug power plug into socket outlet. Use exclusively power plug supplied by the manufacturer. After the self-test, THERA-Trainer tigo is ready for use. Control and display unit with 2.7'' colour screen will switch to stand-by mode when switched on.

  • Page 23: Self-Operated Tip-Up Protection

    To prevent the chair/wheelchair from tipping over during the training session, attach the tip-up protection as follows: Move chair/wheelchair in training position in front of THERA-Trainer tigo. Push down red lever 4 on tip-up protection 3. Pull out belt 2 by hook 1.

  • Page 24: Securing Feet And Legs

    9.4 Securing feet and legs Foot rests Secure feet in foot rests as follows: Make sure that THERA-Trainer tigo is not in training mode. If necessary, press STOP button of control and display unit twice. Secure feet exclusively when seated.
  • Page 25 The leg support is mandatory for users with paralysis, spasticity or weak legs. Note Apply leg support as follows: Make sure that THERA-Trainer tigo is not in training mode. If necessary, press STOP button of control and display unit twice. Put feet into foot rests.

  • Page 26: Installing Grips And Arm Rests

    THERA-TRAINER TIGO USER MANUAL 9.5 Installing grips and arm rests Press locking bolt 2. Slide therapy grips/arm rest 3 or grip adapter 4 onto crank 1 up to the stop. Release locking bolt. Make sure that locking bolts audibly click into place.

  • Page 27: Locking/Unlocking The Crank

    THERA-TRAINER TIGO USER MANUAL 9.6 Locking/unlocking the crank The cranks are locked when using the THERA-Trainer tigo as a leg exerciser to Note serve as a safety handle for the user. For this purpose, install grip adapter 3. When using the THERA-Trainer tigo as an upper body exerciser, the respective therapy grips or arm rests must be installed and the crank unlocked.

  • Page 28: Securing The Arm

    Use therapy grips with wristbands. Secure arms as follows: Make sure that THERA-Trainer tigo is not in training mode. If necessary, press STOP button of control and display unit twice. Put arm into plugged-in arm rest of upper body exerciser.

  • Page 29: Training With Thera-Trainer Tigo

    – hold therapy grips. Select THERA-Trainer tigo training program on control and display unit. Press START button on control and display unit. 10.1 Leg exercise THERA-Trainer tigo permits active or passive leg exercise.

  • Page 30: Arm Exercise

    Risk of injury through unprotected metal parts! Do not remove foot rests for arm exercise. Warning THERA-Trainer tigo permits active or passive arm exercise. Make sure that arm rests are safely attached to the crank when exercising the upper body.

  • Page 31: Using Control And Display Units

    THERA-TRAINER TIGO USER MANUAL 11 USING CONTROL AND DISPLAY UNITS 11.1 Control and display unit with 5.7" colour screen (1) Buttons Number of revolutions (2) Button Direction of rotation (3) Button Easy entry (4) START button (5) STOP button (6) Switch button Leg/upper body exerciser...

  • Page 32: Control And Display Unit With 10.4" Colour Screen Incl. Touch Function

    THERA-TRAINER TIGO USER MANUAL 11.2 Control and display unit with 10.4" colour screen incl. touch function (1) Buttons Number of revolutions (2) Button Direction of rotation (3) Button Easy entry (4) START button (5) STOP button (6) Switch button Leg/upper body exerciser...
  • Page 33 Press START button: Easy entry function is finished. Press button: THERA-Trainer tigo changes direction. Button Direction THERA-Trainer tigo slows down to 0 rpm and resumes movement in oppo- of rotation site direction with pre-set number of rotations. Black arrow shows current direction of rotation.
  • Page 34 THERA-TRAINER TIGO USER MANUAL Button Number Press button +: THERA-Trainer tigo increases number of revolutions step by of revolutions step. Press button -: THERA-Trainer tigo reduces number of revolutions step by step. Press and hold button: Increase or reduce number of revolutions continuo- usly until maximum or minimum is reached.

  • Page 35: Display Units

    THERA-TRAINER TIGO USER MANUAL 11.3 Display units 14 13 12 11 10 9 8 Display before training session has started Note Display during training session Note (1) Display Training program (2) Display Heart rate limit setting (3) Pulse indicator (4) Power display...
  • Page 36 Icon Group Group therapy online (green): Connection between THERA-Trainer tigo and therapy online/ Mini-PC. offline Group therapy offline (red): No connection between THERA-Trainer tigo and Mini-PC. Bluetooth Indicates a Bluetooth connection. Microphone off Indicates that the microphone is deactivated.

  • Page 37: Control And Display Unit With 2.7" Colour Screen

    THERA-TRAINER TIGO USER MANUAL 11.4 Control and display unit with 2.7" colour screen (1) Display Training parameters (2) Switch button Leg/upper body exerciser (3) Button Easy entry (4) Buttons Training time (5) Buttons Exercising resistance (6) Buttons Number of revolutions...
  • Page 38 Button Direction Press button: Symbol Direction arrow flashes. THERA-Trainer tigo changes of rotation direction. THERA-Trainer tigo slows down to 0 rpm and resumes movement in opposite direction with pre-set number of rotations. Yellow arrow indicates direction of rotation. Art. no.: A002-629_Rev 0...

  • Page 39: Display Units

    USER MANUAL Press STOP button: THERA-Trainer tigo stops current training session. Switch button Leg/upper body Press switch button: THERA-Trainer tigo switches from leg to upper body exerciser exerciser or the other way round. – Symbol Foot lights up: Leg exerciser active.
  • Page 40 THERA-TRAINER TIGO USER MANUAL Explanation of display units Display stand-by If no button of THERA-Trainer tigo has been pressed for more than 10 minu- mode tes, – screen light of control and display unit switches off. – red LED 1 lights up.

  • Page 41: Expert Section

    THERA-TRAINER TIGO USER MANUAL EXPERT SECTION The expert section addresses trained dealers, doctors and therapists and Note describes how to use the THERA-Trainer tigo. Art. no.: A002-629_Rev 0 Last update: CW 3/201...

  • Page 42: Start-Up

    12 START-UP 12.1 Unpacking Unpack THERA-Trainer tigo: Remove THERA-Trainer tigo from packaging. Check THERA-Trainer tigo incl. all accessories/options for transport damage. Check if delivery is complete. Inform supplier or forwarding agent immediately about any damage. 12.2 Installation THERA-Trainer tigo Installation of leg support...
  • Page 43 Caution Use exclusively power plug supplied by the manufacturer. Open protective lid 2. Connect plug 3 to port 1. Plug power plug 4 into socket outlet. THERA-Trainer tigo is ready for use. Art. no.: A002-629_Rev 0 Last update: CW 3/201...

  • Page 44: Switching On Or Off

    To switch on the THERA-Trainer tigo: Plug power plug into socket outlet. Use exclusively power plug supplied by the manufacturer. After the self-test, THERA-Trainer tigo is ready for use. Control and display unit with 2.7'' colour screen will switch to stand-by mode when switched on.

  • Page 45: Transport Thera-Trainer Tigo

    Tilt THERA-Trainer tigo on device base incl. transport castors 3. Pull THERA-Trainer tigo to desired place. Transport THERA-Trainer tigo with flat device base incl. transport castors as fol- lows: Have at least one other person help with moving the THERA-Trainer tigo.

  • Page 46: Operation

    Consult a doctor. Observe emissions (see Electromagnetic emission). Risk of injury due to THERA-Trainer tigo tipping over! Do not use THERA-Trainer tigo for training in transport condition. Warning Risk of injury due to insufficient preparation! Disinfect THERA-Trainer tigo before every training (see Cleaning and disinfection).

  • Page 47: Device Base Unit

    THERA-TRAINER TIGO USER MANUAL 13.2 Device base unit Device base with transport castors Extendable device base for enlarging the base area. Large transport castors for easier transport and positioning. Height of device base, incl. castors: 74 mm Device base flat Recommended for active or sport wheelchairs with fixed footboards.
  • Page 48 USER MANUAL Height adjustment Note THERA-Trainer tigo permits height adjustment between 50 and 150 mm without tools. To reduce the distance between user and foot rests even more, it is possible to set different heights in the front and in the rear.
  • Page 49 To prevent the chair/wheelchair from tipping over during the training session, attach the tip-up protection as follows: Move chair/wheelchair in front of THERA-Trainer tigo. Push down red lever 4 on tip-up protection 3. Pull out belt 2 by hook 1 .

  • Page 50: Foot Fixing/Leg Support

    Fixed crank,110 mm Secure feet in foot rests with crank 3 as follows: Make sure that THERA-Trainer tigo is not in training mode. If necessary, press STOP button of control and display unit twice. Make sure that feet are correctly positioned in foot rests 2.
  • Page 51 USER MANUAL Secure feet in foot rests as follows: Make sure that THERA-Trainer tigo is not in training mode. If necessary, press STOP button of control and display unit twice. Make sure that feet are correctly positioned in foot rests.
  • Page 52 For unassisted, quick and simple securing of feet in foot rests (e.g. in case of para- lysis, spasticity, etc.). Secure feet in foot rests as follows: Make sure that THERA-Trainer tigo is not in training mode. If necessary, press STOP button of control and display unit twice. Press release lever 3 on foot fixing 2.
  • Page 53 The leg support is mandatory for users with paralysis, spasticity or weak legs. Note Apply leg support as follows: Make sure that THERA-Trainer tigo is not in training mode. If necessary, press STOP button of control and display unit twice. Put feet into foot rests.

  • Page 54: Upper Body Exerciser/Safety Handle

    THERA-TRAINER TIGO USER MANUAL 13.4 Upper body exerciser/safety handle Upper body exerciser 1 Permits active or passive exercise for the entire upper body. Changing the different types of therapy grips and arm rests allows the trai- ning to be adapted to fit each user's individual needs.
  • Page 55 THERA-TRAINER TIGO USER MANUAL Setting height of upper body exerciser/safety handle Risk of crushing! Take care not to pinch any fingers when pushing the pipes toge- ther. Warning To adapt upper body exerciser/safety handle individually to body size and sitting position: Loosen locking-pin 2 on pipe 1 by approx.
  • Page 56 Locking/unlocking crank of upper body exerciser Note The cranks are locked when using the THERA-Trainer tigo as a leg exerciser to serve as a safety handle for the user. When using the THERA-Trainer tigo as an upper body exerciser, the respective therapy grips or arm rests must be installed and the crank unlocked.

  • Page 57: Hand/Arm Fixing

    THERA-TRAINER TIGO USER MANUAL 13.5 Hand/arm fixing Grip adapter Material damage due to incorrect use! Do not use grip adapter to support body weight. Caution The grip adapter makes the upper body exerciser a top part with safety handle function.
  • Page 58 USER MANUAL Arm rests Risk of injury due to inadequate distance! To protect thumb against injuries: When using a THERA-Trainer tigo with control and display unit with 10.4'' colour screen, secure thumb on arm rest with velcro. Warning Variants: Arm rests for therapy grips 1...

  • Page 59: Safety Devices

    When the arms are fixed in the upper body exerciser so that manual control is not possible: Stop THERA-Trainer tigo by a loud shout. Set microphone sensitivity in sub menu (see Sub menu Control and display unit with 5.7'' or 10.4'' colour screen).
  • Page 60 SPASTICITY or MAX. MOTOR POWER EXCEEDED or spasm symbol appears on control and display unit. After 5 seconds, THERA-Trainer tigo restarts at a speed reduced by 5 rpm. Set crank direction in sub menu after a spasm was detected (see Sub menu Control and display unit with 5.7'' or 10.4'' colour screen or see Sub menu...

  • Page 61: Using Control And Display Units

    THERA-TRAINER TIGO USER MANUAL 14 USING CONTROL AND DISPLAY UNITS Control and display unit with 5.7" colour screen (1) Buttons Number of revolutions (2) Button Direction of rotation (3) Button Easy entry (4) START button (5) STOP button (6) Switch button Leg/upper body exerciser...
  • Page 62 The operation of control and display units with 5.7'' colour screen is identical to units with 10.4'' colour screen. Functions of control and display units START button Press button: THERA-Trainer tigo starts training session with basic settings. – THERA-Trainer tigo starts at 10 rpm. Press button after interruption (break): Training session is resumed.
  • Page 63 Maximum number of passive revolutions: 60 rpm. Press button: THERA-Trainer tigo changes direction. Button Direction THERA-Trainer tigo slows down to 0 rpm and resumes movement in oppo- of rotation site direction with pre-set number of rotations. Black arrow shows current direction of rotation.
  • Page 64 Setting the training time is exclusively possible during a training session. training time Press button : THERA-Trainer tigo increases training time by minutes. Press button : THERA-Trainer tigo reduces training time by minutes. Press and hold buttons: Increase or reduce training time continuously until maximum or minimum is reached.

  • Page 65: Display Units

    THERA-TRAINER TIGO USER MANUAL 14.1 Display units 14 13 12 11 10 9 8 Display before training session has started Note Display during training session Note (1) Display Training program (2) Display Heart rate limit setting (3) Pulse indicator (4) Power display...
  • Page 66 Indicates entire covered distance in km. tance Remaining Indicates remaining training time. training time Icon Group Group therapy online (green): Connection between THERA-Trainer tigo and therapy Mini-PC. online/offline Group therapy offline (red): No connection between THERA-Trainer tigo and Mini-PC. When symbol Group therapy offline appears: Verify that –...

  • Page 67: Sub Menu Control And Display Unit With 5.7'' Or 10.4'' Colour Screen

    14.2 Sub menu Control and display unit with 5.7'' or 10.4'' colour screen The software of the control and display unit with 5.7'' or 10.4'' colour screen has a sub menu that permits setting several parameters to adapt the THERA-Trainer tigo to the user's individual needs. Calling up the sub menu Press STOP button and button at the same time.
  • Page 68 THERA-TRAINER TIGO USER MANUAL Current section of sub menu Current selection Down/reduce Move down in direction of arrow. In menu items where a value is entered (e.g. motor power), the value entered will reduce. Saving/confirming changes Save settings. In menu items with sub-items, go to next menu item.
  • Page 69 THERA-TRAINER TIGO USER MANUAL 1st level 2nd level Adjustable values, func- Factory settings tions Cardio Training time 1-180 min. 15 min. Biofeedback Symmetry bar Symmetry bar (inactive for upper body Symmetry road training) passive Motor power 2-22 Nm 10 Nm...
  • Page 70 THERA-TRAINER TIGO USER MANUAL Menu structure Control and display unit with 10.4" colour screen incl. touch function 1st level 2nd level Adjustable values, func- Factory settings tions Neuro Training time 1-180 min. 15 min. Direction of rotation auto- on/off matic...
  • Page 71 THERA-TRAINER TIGO USER MANUAL 1st level 2nd level Adjustable values, func- Factory settings tions Isokinetic Training time 1-180 min. 15 min. Biofeedback Symmetry bar Symmetry bar Symmetry road (smiley for upper passive body training) Motor power 2-22 Nm 10 Nm...
  • Page 72 THERA-TRAINER TIGO USER MANUAL 1st level 2nd level Adjustable values, func- Factory settings tions Training time 1-180 min. 15 min. (exclusi- Level of difficulty easy easy vely for leg medium exercise) difficult Motor power 2-22 Nm 10 Nm (2-8 Nm for upper body...
  • Page 73 THERA-TRAINER TIGO USER MANUAL Basic settings in menu section Volume Microphone sensitivity Language Contrast Configuration (trained dealer) Time/date It is possible to set the necessary configuration under menu item Configuration. The configuration requires an access code and is exclusively to be used by trained dealers.
  • Page 74 If the user is working at 30 rpm instead of the set number of revolutions (lead speed) of 15 rpm, the THERA-Trainer tigo will adjust the lead speed to 25 rpm after approx. 10 seconds. If the user becomes passive again, THERA-Trainer tigo conti- nues at 25 rpm.
  • Page 75 To set microphone volume of control and display unit in menu /Microphone sensitivity: A symbol in the status bar indicates the status. 0 (off) – when too loud ambient noise causes the THERA-Trainer tigo to switch off inadvertently 1 - 3 – for very loud ambient noise 4 - 6 –...

  • Page 76: Training Programs/Training

    Required performance level is pre-set. The training program Ortho prescribes the performance level for the exercise in Watts. THERA-Trainer tigo regulates the exercising resistance automatically depen- ding on the number of revolutions, so that the required performance always remains at the selected level.
  • Page 77 Cardio not exceed a certain level. An upper limit for the pulse rate is specified. THERA-Trainer tigo reduces the resistance as soon as the pulse rate reaches the limit. Use this training program exclusively in combination with control and display unit and cardio-pulse-set.
  • Page 78 THERA-TRAINER TIGO USER MANUAL Hedgehog Training program for power distribution of the lower extremities. The training program is exclusively suitable for the leg exerciser. To catch as many balloons and other falling objects as possible and make them burst: Move the hedgehog to the left or to the right by one-sided activity (more acti- vity on the left or right side as required).
  • Page 79 THERA-TRAINER TIGO USER MANUAL Training program for active exercise. The training program is exclusively suitable for the leg exerciser. To overtake vehicles in front of the car: Pedal faster than the pre-set speed (passive number of rotations). The more the pre-set speed is exceeded, the faster the vehicles are overta- ken.
  • Page 80 THERA-TRAINER TIGO USER MANUAL Planet Training program for concentric and excentric exercise. The training program is suitable for both the leg and the upper body exerci- ser. Make sure that spasm detection is deactivated. Concentric exercise (positive dynamic, overcoming): Move spaceship up to avoid other spaceships and planets.

  • Page 81: Biofeedback

    To move the spaceship all the way to the bottom, the user must work against a drive power of 2.0 Nm. Since the spasm detection is deactivated, the THERA-Trainer tigo will react very Note late if a crank locks.
  • Page 82 THERA-TRAINER TIGO USER MANUAL Symmetry bar Bar diagram shows activity distribution between lower extremities. The total of both bars is always 100%. Symmetry road Depending on the power distribution, a bike on the street illustration will move to the left or to the right.
  • Page 83 % of the set motor power is required to move the arms or legs. The value indicated in Nm shows the motor power the THERA-Trainer tigo has to provide. For leg exercise, a motor power of 22 Nm can be reached.
  • Page 84 THERA-TRAINER TIGO USER MANUAL Biofeedback for arm exercise Note Biofeedback illustration Smiley is exclusively for training programs Neuro and Iso- kinetic. The biofeedback is inactive for the training programs Ortho and Cardio. An additional biofeedback Passive is available for arm exercise.
  • Page 85 THERA-TRAINER TIGO USER MANUAL Sleeping smiley: Too low or no arm activity. Art. no.: A002-629_Rev 0 Last update: CW 3/201...

  • Page 86: Training Report

    THERA-TRAINER TIGO USER MANUAL 14.5 Training report After the training session, the THERA-Trainer tigo will show a training report. Requirements: The training session lasted for at least one minute. The training session was started by pressing the START button. Note Training report of training programs Neuro, Ortho, Cardio, Isokinetic and Group therapy.
  • Page 87 Pressing the STOP button will display the training data until – a new training session is started from the standard display by pressing the START button. – THERA-Trainer tigo is restarted (also from stand-by mode). Art. no.: A002-629_Rev 0 Last update: CW 3/201...

  • Page 88: Cardio-Pulse-Set

    Caution Note Observe minimum distance of 1.5 m between THERA-Trainer tigo so that THERA- Trainer tigo with cardio-pulse-set do not influence each other. The polar pulse belt (cardio-pulse-set) prevents exceeding the set heart rate limit (see Heart rate limit) and indicates the user's current pulse rate.

  • Page 89: Printer For Training Documentation

    Observe the enclosed user manual. Bluetooth connection: Range approx. 10 m It is possible to use a single printer for more than one THERA-Trainer tigo at the Note same time. For this purpose, use one Bluetooth transmitter per THERA-Trainer tigo.

  • Page 90: Control And Display Unit With 2.7" Colour Screen

    THERA-TRAINER TIGO USER MANUAL 14.8 Control and display unit with 2.7" colour screen (1) Display Training parameters (2) Switch button Leg/upper body exerciser (3) Button Easy entry (4) Buttons Training time (5) Buttons Exercising resistance (6) Buttons Number of revolutions...
  • Page 91 Press START button: Easy entry function is finished. Press button: Symbol Direction arrow flashes. THERA-Trainer tigo changes Button Direction direction. THERA-Trainer tigo slows down to 0 rpm and resumes movement of rotation in opposite direction with pre-set number of rotations.
  • Page 92 Spasm detection: step 2 – Spasm program: forward Button Exerci- Press button +: Symbol Weight flashes. THERA-Trainer tigo increases exer- sing resistance cising resistance step by step. Press button -: Symbol Weight flashes. THERA-Trainer tigo reduces exercis- ing resistance step by step.

  • Page 93: Display Units

    (4) Display Spasm detection (5) Display Spasticity ON/OFF (6) Display Status bar (7) Display Key sound ON/OFF Explanation of display units If no button of THERA-Trainer tigo has been pressed for more than 10 minu- Display stand-by mode tes, –...

  • Page 94: Sub Menu Control And Display Unit With 2.7" Colour Screen

    THERA-TRAINER TIGO USER MANUAL Display Status Symbol Number of revolutions Symbol Resistance Symbol Training time Symbol Leg exerciser active Symbol Upper body exerciser active Symbol Leg and upper body exerciser active Symbol Direction of rotation Symbol Easy entry active Display Key Key sound ON: Loudspeaker displayed.

  • Page 95: Software Package Cycling

    Required for software package Cycling group therapy . The device establishes a Bluetooth connection to the THERA-Trainer tigo. The Bluetooth connection and the software package Cycling group therapy allow displaying the motion sequences of the THERA-Trainer tigo in different biofeedbacks. Art. no.: A002-629_Rev 0...
  • Page 96 Cycling group therapy. Exclusively available for software version 3.1 or higher. Observe enclosed user manual of software package. When THERA-Trainer tigo has been reset to factory settings: Reinstall training program Group therapy (see Service instruction). Art. no.: A002-629_Rev 0...

  • Page 97: Motor Power/Joint Force

    THERA-TRAINER TIGO USER MANUAL 15 MOTOR POWER/JOINT FORCE 15.1 Motor power Risk of injury due to inappropriate motor power! Before every training session and every time when changing the training program, check motor power setting. Warning The motor power is adjustable individually for every training program and every user.

  • Page 98: Joint Force

    THERA-TRAINER TIGO USER MANUAL Setting motor power to fit the user's individual needs: Limit motor power in sub menu (see Sub menu Control and display unit with 5.7'' or 10.4'' colour screen and see Sub menu control and display unit with 2.7" colour screen).
  • Page 99 THERA-TRAINER TIGO USER MANUAL The diagram shows the joint forces acting on the user in dependence on the motor power setting and radius adjustment. M = torque (power) of the motor = marks of stepless radius adjustment = very small radius, corresponds at 2-stepped radius setting roughly...

  • Page 100: Cleaning And Disinfection

    If any damage is found, do not clean but contact trained dealer. Make sure that the room is sufficiently aired during cleaning or disinfection. Clean surface of THERA-Trainer tigo with a soft and damp cloth. Clean surfaces of THERA-Trainer tigo and cardio-pulse-set by wet disinfec- tion.

  • Page 101: Maintenance And Repair

    The manufacturer recommends performing a safety check after 24 months. Note 17.2 Further use The THERA-Trainer tigo is suitable for further use by a different customer. Before every further use THERA-Trainer tigo Clean and disinfect THERA-Trainer tigo thoroughly (see Cleaning and disin- fection).

  • Page 102: Troubleshooting

    Have main controller board and control and display unit with 2.7’’ colour screen replaced. E039 Pull power plug and plug it back in after approx. 5 s. THERA-Trainer tigo restarts. If error message occurs repeatedly: Contact a trained dealer. E040 Pull power plug and plug it back in after approx.
  • Page 103 Cabling faulty or defective. Contact a trained dealer. E128 THERA-Trainer tigo is overheated. Switch off THERA-Trainer tigo and pull power plug. Let THERA-Trainer tigo cool down for 10 min. If error message occurs repeatedly: Contact a trained dealer. Art. no.: A002-629_Rev 0...

  • Page 104: Control And Display Unit With 5.7''-/10.4'' Colour Screen

    If error message occurs repeatedly: Contact a trained dealer. Error 17 THERA-Trainer tigo is overheated. Switch off TTHERA-Trainer tigo and pull power plug. Let THERA-Trainer tigo cool down for 10 min. If error message occurs repeatedly: Contact a trained dealer.

  • Page 105: General Errors

    Contact a trained dealer. Operating Make sure that START button has been pressed. It is possible that THERA-Trainer THERA-Trainer tigo is in stand-by mode. tigo is not pos- Make sure that power supply cable is intact and correctly con- sible nected.
  • Page 106 If the user does not reduce power and number of revolutions, the error on control and message will appear again. display unit. After three messages, THERA-Trainer tigo will stop the training ses- sion. Art. no.: A002-629_Rev 0 Last update: CW 3/201...

  • Page 107: Technical Data

    THERA-TRAINER TIGO USER MANUAL Error code Troubleshooting "TRAINING THERA-Trainer tigo stops the training session due to upper limits STOPPED for number of revolutions or power being continuously exceeded. THERA-Trainer used too heavily" appears on cont- rol and display unit. 19 TECHNICAL DATA...

  • Page 108: Disposal

    Height: 4.0 cm Note For users with a body weight of more than 120 kg it is necessary to use special accessories for the THERA-Trainer tigo after consultation with the manufacturer or the trained dealer. 20 DISPOSAL To dispose of the THERA-Trainer tigo: Observe country-specific regulations and specifications.

  • Page 109: Notes On Electromagnetic Compatibility

    Directives and manufacturer's declaration - Electromagnetic emissions THERA-Trainer tigo The is designed for operation in an electromagnetic environment as described below. The customer or the user of the THERA-Trainer tigo should make sure that the unit is used in such an environment. Emission measurement...

  • Page 110: Immunity

    Directives and manufacturer's declaration - Immunity to electromagnetic disturbance THERA-Trainer tigo is designed for operation in an electromagnetic environment as described below. The custo- mer or the user of the THERA-Trainer tigo should make sure that the unit is used in such an environment. Immunity...
  • Page 111 Directives and manufacturer's declaration - Immunity to electromagnetic disturbance THERA-Trainer tigo The is designed for operation in an electromagnetic environment as described below. The customer or the user of the THERA-Trainer tigo should make sure that the unit is used in such an environment. Immunity...

  • Page 112: Recommended Protective Distances Between Portable And Mobile Hf Telecommunication Devices And Thera-Trainer Tigo

    THERA-Trainer tigo is designed for operation in an electromagnetic environment as described below. the custo- mer or the user of the THERA-Trainer tigo can help to prevent electromagnetic disturbances by observing the minimum distance between portable and mobile HF telecommunication devices (transmitters) and the THERA-Trainer tigo as indicated below (depending on the output power of the telecommunication device).
  • Page 113 THERA-TRAINER TIGO USER MANUAL NOTES Art. no.: A002-629_Rev 0 Last update: CW 3/201...
  • Page 114 THERA-TRAINER TIGO USER MANUAL NOTES Art. no.: A002-629_Rev 0 Last update: CW 3/201...
  • Page 115 THERA-TRAINER TIGO USER MANUAL NOTES Art. no.: A002-629_Rev 0 Last update: CW 3/201...
  • Page 116 MANUFACTURER: THERA-Trainer ® a trademark of medica Medizintechnik GmbH Blumenweg 8 88454 Hochdorf Germany Phone: +49 7355-93 14-0 Fax: +49 7355-93 14-15 E-mail: info@thera-trainer.de Internet: www.thera-trainer.de Art. no.: A002-629_Rev 0 Last update: CW 3/201 For declarations of conformity, see www.thera-trainer.de...
