Upgrading Beltpack Firmware - Clear-Com FreeSpeak II Integra User Manual

4.3.8

Upgrading beltpack firmware

You can upgrade the FreeSpeak II beltpack firmware by:
• Using a USB connection
• Using an Over The Air upgrade.
4.3.8.1 Upgrading by USB connection
1) Connect the beltpack to a USB port on the computer running the EHX
software.
2) Select Tools > Apply Wireless Firmware Via USB.
3) Browse to the location of the upgrade file, and then select Update
Firmware.
The upgrade file is downloaded to the beltpack or antenna.
Note: You can connect more than one beltpack to the computer if you have multiple
USB ports. The units will be upgraded sequentially.
4.3.8.2 Upgrading beltpack firmware by Over The Air Upgrade
1) Right-click on the Frame in the Layout window, and then select Firmware
> Update Firmware. The Update Firmware Wizard appears.
2) Select Next. The following screen appears:
3) Select the Wireless radio button. There are two further options:
• Automatic – select this option to automatically upgrade the beltpack
Page 42
Figure 4-11 The Update Firmware screen
when it is switched on.
User Guide| FreeSpeak II ® Integra (Matrix version)
