Introduction
The Bathmaster Deltis is a patient bathing device intended to assist a bather into and out of the bath. Designed to make the pleasure of taking a bath safer and
easier, for both user and carer, the Bathmaster Deltis is a fully battery powered, self-contained bath seat which requires no plumbing or electrical installation and is
suitable for use in either domestic or institutional situations.
The bath lift folds compactly, and separates into two parts, enabling it to be carried, transported and stored easily.
The Bathmaster Deltis is easily positioned in any standard bath (Note: There are a few extremely narrow or contoured designs of bath in which a powered bath seat
is not suitable – full details of compatible bath sizes can be found in the Technical Specifications section of these instructions). The frame stands on four suction feet
that may be rotated to suit the curved floor of the bath. Integral 'pull- up' tabs on the suction feet, plus a rear release system, enable the Bathmaster Deltis to be
easily removed from the bath. Replacement components and accessories are available.
In this instruction manual you will find information and instructions on the safe and correct use of your bath lift. Keep all documents in a safe place.
Components
The Bathmaster Deltis includes the following components:
•
White plastic lower seat section with side transfer flaps and four suction feet
•
White plastic backrest with motor and cable
•
Two side flap protectors
•
Hand controller containing battery pack with LED low-battery warning light
and audible bleep
•
Battery recharger with country specific lead and plug
•
User instructions
If any of the above components are missing or damaged, do not use the
Bathmaster Deltis and contact your distributor or Patterson Medical.
Optional accessories are available for those requiring increased comfort or
functionality.
Do the following
•
Before using the Bathmaster Deltis for the first time, read these instructions
and familiarise yourself with the product and the lifting techniques.
Become familiar with the operation of the unit before using it to lower
or raise a person.
•
Retain these instructions for future reference and keep them where people
using the bath lift can have access to them.
•
Ensure the suitability of the unit to lift the individual is assessed. Judging the
suitability of any patient lifting device is the responsibility of the healthcare
professional or the care giver. Some circumstances that must be considered
include the following: size and weight of the individual; his or her upper body
strength, balance, co-ordination, cognition and hip flexibility; their potential to
spasm.
•
Only use the bath lift in baths which comply with the specifications outlined in
the Technical Specifications section of these instructions.
•
Inspect the unit before each use to be sure it is free from damage and
excessive wear. Bi-annual inspections by trained technicians are strongly
recommended (see Maintaining the Unit).
•
Ensure both the bath surface and suction feet are clean, dry and free from
soap and bath oil residue before fitting the Bathmaster Deltis into the bath.
•
If using bath oils or bath salts, do not use a strong solution. A high
concentration may impair the slide function of the lifting scissors.
•
Whilst using the bath lift the user should remain calmly seated. Excessive
movement should be avoided.
•
Use the Bathmaster Deltis only with accessories, hand controllers,
and rechargers that are supplied by Patterson Medical.
•
When the Bathmaster Deltis is being used by a disabled person unaided,
please ensure that an alarm system or telephone is available that could be
used in the event of difficulty or emergency.
Do not do the following
•
Do not exceed the maximum lifting capacity of the unit - Deltis: 140kg
(22stone, 308lbs), Deltis XL: 170kg (26stone, 375lbs).
•
Do not use the Bathmaster Deltis as a support to help you stand or steady
yourself.
•
Do not use the unit on an incline greater than 5°.
•
Do not operate the hand controller whilst the unit is disassembled.
•
Do not use the Bathmaster Deltis if metal parts of the connectors or cables
are exposed.
•
Do not use the Bathmaster Deltis for other uses than which it is designed and
detailed in these instructions.
•
Do not allow children to play with the Bathmaster Deltis, its parts or accessories.
•
During assembly, use or cleaning, be careful not to put your fingers between
any moving parts, especially around the backrest.
•
Do not modify or reconstruct the device.
•
Objects (such as hairbrushes etc.) which are taken into the bath must not be
allowed near the area of the lifting scissors.
•
Do not store the hand controller near heat sources.
9/10/14
14:05
Page 4
Charging the battery
The Bathmaster Deltis is operated using a rechargeable, battery powered, hand
controller. Each hand controller is completely waterproof to a depth of 1m. The
batteries are charged using low voltage rechargers, designed for the
appropriate countries' electricity supply.
The Deltis is powered by a rechargeable Lithium-Ion battery pack fitted inside
the hand controller. A new hand controller comes fully charged and does not
need to be charged before the first use. Optimum battery capacity will be
reached following a few charging cycles. Charging the battery should be done
away from the bathroom and other sources of water. The light on the battery
pack illuminates when the charge is low.
We recommend that you charge your hand controller after every use.
If the light is permanently lit, enough power remains for one complete lift only.
The unit will not lower into the bath. Do not use the unit after the low-battery
light on the hand controller has permanently illuminated. Recharge it
before use.
The hand controller is designed so that it cannot be charged at the same time
as being connected to the Bathmaster Deltis.
The hand controller should be removed from the Bathmaster Deltis, if the unit is
not going to be used for some time. All battery packs are sealed units and
batteries are non-replaceable.
The chargers are not designed for use with non-rechargeable batteries.
Ensure that the connector (see Fig.3) on the hand controller is completely dry
before plugging it into the recharger or the bath lift.
Inspect the charger and the power cord before each use to ensure they are
free from damage.
Do not open the handset as this will void the warranty.
Recharging the hand controller (see Fig.3)
To charge the battery, use the following procedure:
1. Disconnect the cable of the hand controller from the unit.
2. Ensure that the connector is dry.
3. Connect the jack plug on the cable of the hand controller with the socket on
the cable of the charger unit.
4. Connect the charger to a suitable mains socket. Charging is in progress when
the light on the hand controller is on.
5. Charge the hand controller until the red light on the hand controller turns off.
Then disconnect the hand controller by reversing the sequence.
Preparing the unit for use
Before setting up, check parts for any damage in transit and that no parts are
missing.
Fitting the suction feet
•
The suction pads must be free from dirt or grease.
•
Take care to correctly orientate the straps on the suction pads (straps turned
outwards)
•
Screw the front suction pads and rear suction pads (see Fig. 1, component 6)
with the threaded end into the threaded holes on the underside of the base plate.
Fitting Side Flap Protectors (see Fig. 12)
If the bath tub has handles then side flap protectors may be needed.
•
Side flap protectors enable the side flaps to move smoothly up and down
without catching beneath the handles on the bath. Clip the protectors into
place on the handles with the short edges towards the outside of the bath.
•
When fitted correctly, they should rest at the bottom of the edge of the bath.
If necessary they may be trimmed to length. Sharp edges of the trimmed end
can be removed with abrasive paper or a file.
Installing the bath lift
•
Before use, ensure there are no obstructions or projections within the bath
that may prevent the frame from standing securely and squarely on its suction
feet, also that it can be raised and lowered freely without catching under or
on, any part of the bath surface, the taps and adjacent fittings.
•
Only set up the bath lift in baths which comply with the specifications found in
the Technical Specifications section of these instructions.
•
You will need to lift the Bathmaster Deltis and place it into the bath. If you feel
you may have difficulty or are unsure how to lift correctly, please ask
4
